Solid State Relays
Accessories.POWER

Type RHS... Heatsink Assemblies

RHS45A
Heatsink assembly with DIN-rail
adapter for 1-phase SSRs. Type
RHS45A is a complete heatsink
kit not including the SSR.
40x40 mm fan may be mounted
onto the heatsink.
6.0
5.0
4.0
3.0
2.0
0
10
20
30
Power in W
RHS45B
Heatsink assembly with DIN-rail
adapter for 1-phase SSRs. Type
RHS45B is a complete heatsink
kit not including the SSR.
40x40 mm fan may be mounted
on to the heatsink.
6.0
5.0
4.0
3.0
2.0
0
10
20
30
Power in W
5-2
Gross Automation (877) 268-3700 · www.carlogavazzisales.com · sales@grossautomation.com
A
40
50
60
A
40
50
60
Specifications are subject to change without notice (22.11.01)
103
103

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RHS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CARLO GAVAZZI RHS Series

  • Page 1 Solid State Relays Accessories.POWER Type RHS... Heatsink Assemblies RHS45A Heatsink assembly with DIN-rail adapter for 1-phase SSRs. Type RHS45A is a complete heatsink kit not including the SSR. 40x40 mm fan may be mounted onto the heatsink. Power in W RHS45B Heatsink assembly with DIN-rail adapter for 1-phase SSRs.
  • Page 2 Heatsink Assemblies (cont.) RHS90 Heatsink assembly with DIN-rail adapter for 1-phase SSRs. Type RHS90 is a complete heatsink kit not including the SSR. A 60x60 mm fan may be mounted onto the heatsink. Power in W RHS100 Heatsink assembly with DIN-rail adapter for 1-phase SSRs.
  • Page 3 Heatsink Assemblies (cont.) RHS112 Heatsink assembly with DIN-rail adapter for 1-phase and 3-phase SSRs. Type RHS112 is a com- plete heatsink kit not including the SSR. A 60x60 mm fan may be mounted onto the heatsink. Power in W RHS300 - 5 K/W Heatsink assembly with DIN-rail adapter for 3-phase SSRs.
  • Page 4 RHS... Heatsink Assemblies (cont.) Fan Kit RHS 301 F 115, RHS 301 F 230 Not including the SSR and the RHS 301 heatsink assembly shown on the drawing. R th S-A 0.25 K/W. Not included Note: High-quality fan with full metal bearings.
  • Page 5 RHS... Heatsink Assemblies (cont.) Type RHS 301 Heatsink assembly for 1-phase and 3-phase SSRs. 2 screws M4 x 6 mm 4 x Selftapping screws M4 x 9.5 mm DlN rail adapter Type RHS 00 1 single-phase relay not included 2 screws M5 x 8 mm Heatsink 2 washers Ø...
