2
1 cFP-RLY-425
2 Captive Screws
3 cFP Controller Module
Mounting the System Upright
To ensure maximum cooling efficiency, mount the Compact
FieldPoint system so that the I/O module vents are at the top and
bottom as shown in Figure 2.
© National Instruments Corp.
3
1
Figure 1. Installing the cFP-RLY-425
4
2
4 Screw Holes
5 cFP Backplane
3
5
4
cFP-RLY-425
