HPE Apollo 2000 Gen10 Chassis
Maintenance and Service Guide
Abstract
This guide describes identification and maintenance procedures, diagnostic tools,
specifications and requirements for hardware components and software. This guide is for an
experienced service technician. Hewlett Packard Enterprise assumes that you are qualified in
the servicing of computer equipment, trained in recognizing hazards in products, and are
familiar with weight and stability precautions.
Part Number: 879111-006
Published: August 2019
Edition: 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Apollo 2000 Gen10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hewlett Packard Enterprise Apollo 2000 Gen10

Summary of Contents for Hewlett Packard Enterprise Apollo 2000 Gen10

  • Page 1 This guide describes identification and maintenance procedures, diagnostic tools, specifications and requirements for hardware components and software. This guide is for an experienced service technician. Hewlett Packard Enterprise assumes that you are qualified in the servicing of computer equipment, trained in recognizing hazards in products, and are familiar with weight and stability precautions.
  • Page 2 Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    Contents Illustrated parts catalog................6 System components........................6 SAS expander module spare part..................6 Drive backplane spare parts....................6 Fan spare parts........................7 PDB assembly spare part....................7 Flexible Slot power supply spare parts................7 Chassis ear assembly spare parts..................7 System cable spare parts....................8 Server options..........................8 PDB cover and energy pack holder spare parts..............
  • Page 4 Troubleshooting..................53 NMI functionality..........................53 Troubleshooting resources......................53 Diagnostic tools..................54 Product QuickSpecs........................54 UEFI System Utilities........................54 Selecting the boot mode ....................54 Secure Boot........................55 Launching the Embedded UEFI Shell ................55 Intelligent Provisioning........................ 56 Intelligent Provisioning operation..................57 HPE Insight Remote Support......................57 HPE InfoSight for servers ......................
  • Page 5 HPE 1600W Flex Slot Platinum Hot-plug Low Halogen Power Supply......89 HPE 1800W–2200W Flex Slot Platinum Hot-plug Power Supply ........90 Websites....................91 Support and other resources...............92 Accessing Hewlett Packard Enterprise Support................. 92 Accessing updates........................92 Customer self repair........................93 Remote support.......................... 93 Documentation feedback......................

  • Page 6: Illustrated Parts Catalog

    Illustrated parts catalog System components Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts information, see the Hewlett Packard Enterprise PartSurfer website. Item Description SAS expander module spare part on page 6 Drive backplane spare parts on page 6...

  • Page 7: Fan Spare Parts

    Description Spare part number 12 LFF drive backplane 879837-001 16 NVMe drive backplane 879841-001 16 SFF + 8 NVMe drive backplane 879839-001 24 SFF drive backplane 879842-001 Fan spare parts Customer self repair on page 11: Optional Description Spare part number Fan for fan bays 1 to 8 879832-001 Dual-rotor fan 9–10 for the 1800 W–2200 W power supply...

  • Page 8: System Cable Spare Parts

    2U server NVMe cable PDB pass-through board cable P01291-001 RCM FFC (flexible flat cable) P01292-001 Server options Hewlett Packard Enterprise continually improves and changes product parts. For complete and current supported parts information, see the Hewlett Packard Enterprise PartSurfer website. Illustrated parts catalog...

  • Page 9: Pdb Cover And Energy Pack Holder Spare Parts

    Item Description PDB cover spare part Energy pack holder for a chassis using the 1800 W-2200 W power supply Energy pack spare part on page 9 Energy pack holder for a chassis using an 800 W or 1600 W power supply RCM module spare part on page 9 PDB cover and energy pack holder spare parts Customer self repair on page 11: Mandatory...
  • Page 10 Description Spare part number RCM module 800361-001 Illustrated parts catalog...

  • Page 11: Customer Self Repair

    CSR part whether a defective part must be returned to Hewlett Packard Enterprise. In cases where it is required to return the defective part to Hewlett Packard Enterprise, you must ship the defective part back to Hewlett Packard Enterprise within a defined period of time, normally five (5) business days.
  • Page 12 Votre garantie limitée Hewlett Packard Enterprise peut inclure un service de garantie "pièces seules". Dans ce cas, les pièces de rechange fournies par Hewlett Packard Enterprise ne sont pas facturées. Dans le cadre de ce service, la réparation des pièces CSR par le client est obligatoire. Si vous demandez à...
  • Page 13 In caso di necessità si può richiedere l'assistenza telefonica di un addetto del centro di supporto tecnico Hewlett Packard Enterprise. Nel materiale fornito con una parte di ricambio CSR, Hewlett Packard Enterprise specifica se il cliente deve restituire dei component. Qualora...
  • Page 14 NOTA: Algunos componentes de Hewlett Packard Enterprise no están diseñados para que puedan ser reparados por el usuario. Para que el usuario haga valer su garantía, Hewlett Packard Enterprise pone como condición que un proveedor de servicios autorizado realice la sustitución de estos componentes.
  • Page 15 Para este servicio de garantía exclusivo de componentes, es obligatoria la sustitución de componentes por parte del usuario (CSR). Si solicita a Hewlett Packard Enterprise que realice la sustitución de estos componentes, tendrá que hacerse cargo de los gastos de desplazamiento y de mano de obra de dicho servicio.
  • Page 16 OBSERVAÇÃO: Algumas peças da Hewlett Packard Enterprise não são projetadas para o reparo feito pelo cliente. A fim de cumprir a garantia do cliente, a Hewlett Packard Enterprise exige que um técnico autorizado substitua a peça. Essas peças estão identificadas com a marca "No" (Não), no catálogo de peças ilustrado.
  • Page 17 Customer self repair...
  • Page 18 Customer self repair...
  • Page 19 Customer self repair...

  • Page 20: Removal And Replacement Procedures

    Removal and replacement procedures Required tools The following tools might be required to perform some procedures: • T-10 Torx screwdriver • T-15 Torx screwdriver Safety considerations Before performing service procedures, review all the safety information. Electrostatic discharge Be aware of the precautions you must follow when setting up the system or handling components. A discharge of static electricity from a finger or other conductor may damage system boards or other static- sensitive devices.

  • Page 21: Server Warnings And Cautions

    Get help to lift and stabilize the product during installation or removal, especially when the product is not fastened to the rails. Hewlett Packard Enterprise recommends that a minimum of two people are required for all rack server installations. If the server is installed higher than chest level, a third person may be required to help align the server.

  • Page 22: Rack Warnings

    Rack warnings WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that: • The leveling jacks are extended to the floor. • The full weight of the rack rests on the leveling jacks. • The stabilizing feet are attached to the rack if it is a single-rack installation.

  • Page 23: Power Down The Server

    Power down the server Before powering down the server for any upgrade or maintenance procedures, perform a backup of critical server data and programs. IMPORTANT: When the server is in standby mode, auxiliary power is still being provided to the system.

  • Page 24: Remove The Server Blank

    Remove the server blank CAUTION: To prevent improper cooling and thermal damage, do not operate the chassis unless all bays are populated with a component or a blank. CAUTION: To avoid damage to the server or server blank: • Always support the bottom of the server or server blank when removing it from the chassis. •...

  • Page 25: Remove The Chassis From The Rack

    5. Use the release lever to pull the server out of the chassis. • 1U server • 2U server Remove the chassis from the rack Hewlett Packard Enterprise recommends removing the external chassis components before removing the chassis from the rack as a fully populated chassis is heavy. Removal and replacement procedures...
  • Page 26 Procedure Power down the servers. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. Disconnect all peripheral cables from the servers and chassis. If installed, remove the front bezel. Label the drives before removing them.

  • Page 27: Remove The Access Panel

    12. Place the chassis on a sturdy, level surface. Remove the access panel WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning any installation, removal, or replacement procedure.

  • Page 28: Removing And Replacing The Pdb Cover

    Removing and replacing the PDB cover Prerequisites Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available. Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b.

  • Page 29: Move The Fan Cages

    To replace the component, reverse the removal procedure. Move the fan cages Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. 3. Disconnect all peripheral cables from the servers and chassis. 4.

  • Page 30: Remove The 1800 W-2200 W Power Supply Fan Assembly

    Remove the 1800 W–2200 W power supply fan assembly Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. 3. Disconnect all peripheral cables from the servers and chassis. 4.

  • Page 31: Power Up The Server

    To replace the component, reverse the removal procedure. Power up the server The SL/XL chassis firmware initiates an automatic power-up sequence when the servers are installed. If the default setting is changed, use one of the following methods to power up each server: •...
  • Page 32 5. To remove an SFF hot-plug drive, do the following: a. Press the Do Not Remove button. b. Slide the drive out of the bay. 6. To remove an NVMe hot-plug drive, do the following: An NVMe drive is a PCIe bus device. Devices attached to a PCIe bus cannot be removed without allowing the device and the bus to complete and cease signal/traffic flow.

  • Page 33: Removing And Replacing The Sas Expander Module

    Removing and replacing the SAS expander module Procedure 1. Power down the servers. 2. If installed, remove the front bezel. 3. Remove the blanks or drives present above and below the SAS expander module (in the drive bays 12 and 13). •...

  • Page 34: Removing And Replacing The Rcm Module

    Removing and replacing the RCM module Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. 3. Disconnect all cables from the RCM module. 4.
  • Page 35 CAUTION: Mixing different types of power supplies in the same chassis might: • Limit or disable some power supply features including support for power redundancy. • Cause the system to become unstable and might shut down. To ensure access to all available features, all power supplies in the same chassis should have the same output and efficiency ratings.
  • Page 36 3. For an AC power supply, do the following: a. Disconnect the power cord from the power supply. b. Remove the power supply. Removal and replacement procedures...
  • Page 37 4. For a DC power supply, do the following: a. Slide the power supply out of the bay just enough to access the ground cable screw. b. Detach the ground (earthed) cable from the power supply. c. Remove the terminal block connector from the power supply. Removal and replacement procedures...

  • Page 38: Removing And Replacing A Fan From The Fan Cage

    d. Remove the power supply. To replace the component, reverse the removal procedure. Removing and replacing a fan from the fan cage Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b.
  • Page 39 6. Remove the access panel on page 27. 7. Remove the fan: a. Disconnect the fan signal cable. b. Detach the tapes securing the fan signal cable. 8. Pull the fan out of the cage. To replace the component, reverse the removal procedure. Removal and replacement procedures...

  • Page 40: Removing And Replacing The 1800 W-2200 W Power Supply Dual-Rotor Fan 9-10

    Removing and replacing the 1800 W–2200 W power supply dual-rotor fan 9–10 Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. 3. Disconnect all peripheral cables from the servers and chassis. 4.

  • Page 41: Removing And Replacing An Energy Pack Or Energy Pack Holder

    Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. 3. Disconnect all peripheral cables from the servers and chassis. 4. Remove the servers. 5.
  • Page 42 Disconnect all peripheral cables from the servers and chassis. Remove the servers. Remove the chassis from the rack on page 25. Remove the access panel on page 27. Remove the PDB cover. CAUTION: The latches on the energy pack holder are flexible. However, to avoid damaging the holder, do not apply too much pressure on these latches when installing or removing the energy pack from the chassis.
  • Page 43 10. Remove the energy pack from the holder. • Energy pack removal in a chassis using a 800 W or 1600 W power supply • Energy pack removal in a chassis using the 1800 W–2200 W power supply Removal and replacement procedures...

  • Page 44: Removing And Replacing The Pdb Assembly

    To replace the component, reverse the removal procedure. Removing and replacing the PDB assembly CAUTION: If you are replacing the PDB assembly in an Apollo r2800 Gen10 system that has a customized drive bay mapping set up, take note of this customized configuration. You will reconfigure the drive bay mapping after the installation of the new PDB assembly.
  • Page 45 10. Disconnect all cables from the PDB. 11. Push aside the drive backplane cables to locate the RCM FFC connector on the front end of the PDB. 12. Disconnect the RCM FFC from the PDB. 13. Remove the PDB assembly screws. 14.

  • Page 46: Removing And Replacing The Fan Power Cable Assembly

    To replace the component, reverse the removal procedure. Removing and replacing the fan power cable assembly Procedure 1. Power down the servers. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. 3.

  • Page 47: Removing And Replacing The Rcm Ffc

    To replace the component, reverse the removal procedure. Removing and replacing the RCM FFC Prerequisites Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available. Procedure Power down the servers. Remove all power: a. Disconnect each power cord from the power source. b.

  • Page 48: Removing And Replacing The Chassis Ear Assembly

    Remove the access panel on page 27. Remove the PDB cover. If installed, remove the energy pack assembly. 10. If installed, remove the 1800 W–2200 W power supply fan assembly. 11. Remove the PDB assembly. 12. Detach and remove the RCM FFC from the chassis. To replace the component, reverse the removal procedure.
  • Page 49 If you are removing the right chassis ear assembly, remove the serial number/iLO information pull tab. Retain the pull tab for installation in the new right chassis ear assembly spare. Remove the servers. Remove the chassis from the rack on page 25. Remove the access panel on page 27.

  • Page 50: Removing And Replacing The Drive Backplane

    11. If you are removing the right chassis ear assembly, disconnect the front I/O cable from the drive backplane. 12. Remove the front I/O cable cover. 13. Pull the front I/O cable out of the chassis, and then detach the cable from the chassis wall. 14.
  • Page 51 Procedure Power down the servers. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the chassis. Disconnect all peripheral cables from the servers and chassis. Remove the servers. If installed, remove the front bezel. Label the drives before removing them.
  • Page 52 Retain the component for future use. 15. If you are removing the 16 SFF + 8 NVMe or the 24 SFF drive backplane, remove the backplane screws, and then remove the backplane. To replace the component, reverse the removal procedure. Removal and replacement procedures...

  • Page 53: Troubleshooting

    Integrated Management Log Messages and Troubleshooting Guide for HPE ProLiant Gen10 and HPE Synergy provides IML messages and associated troubleshooting information to resolve critical and cautionary IML events. To access the troubleshooting resources, see the Hewlett Packard Enterprise Information Library (http:// www.hpe.com/info/gen10-troubleshooting). Troubleshooting...

  • Page 54: Diagnostic Tools

    Product QuickSpecs For more information about product features, specifications, options, configurations, and compatibility, see the product QuickSpecs on the Hewlett Packard Enterprise website (http://www.hpe.com/info/qs). UEFI System Utilities The UEFI System Utilities is embedded in the system ROM. Its features enable you to perform a wide range of configuration activities, including: •...

  • Page 55: Secure Boot

    Procedure 1. From the System Utilities screen, select System Configuration > BIOS/Platform Configuration (RBSU) > Boot Options > Boot Mode. 2. Select a setting. • UEFI Mode (default)—Configures the system to boot to a UEFI compatible operating system. • Legacy BIOS Mode—Configures the system to boot to a traditional operating system in Legacy BIOS compatibility mode.

  • Page 56: Intelligent Provisioning

    loaders. The Shell also provides CLI-based commands you can use to obtain system information, and to configure and update the system BIOS. Prerequisites Embedded UEFI Shell is set to Enabled. Procedure 1. From the System Utilities screen, select Embedded Applications > Embedded UEFI Shell. The Embedded UEFI Shell screen appears.

  • Page 57: Intelligent Provisioning Operation

    HPE Insight Remote Support Hewlett Packard Enterprise strongly recommends that you register your device for remote support to enable enhanced delivery of your Hewlett Packard Enterprise warranty, HPE support services, or Hewlett Packard Enterprise contractual support agreement. Insight Remote Support supplements your monitoring...

  • Page 58: Hpe Infosight For Servers

    For more information, see Insight Remote Support and Insight Online Setup Guide for ProLiant Servers and BladeSystem c-Class Enclosures on the Hewlett Packard Enterprise website. Insight Remote Support is available as part of Hewlett Packard Enterprise Warranty, HPE support services, or Hewlett Packard Enterprise contractual support agreement.
  • Page 59 Using one of multiple methods, you can run HPE SSA before launching the host operating system. In offline mode, users can configure or maintain detected and supported devices, such as optional Smart Array controllers and integrated Smart Array controllers. Some HPE SSA features are only available in the offline environment, such as setting the boot controller and boot volume.

  • Page 60: Component Identification

    Component identification System components Item Description RCM module (optional) Power supply Chassis 2U server node 1U server node Server blank Front panel components HPE Apollo r2200 Gen10 Chassis Component identification...
  • Page 61 Item Description LFF hot-plug drives Serial number/iLO information pull tab on page 62 HPE Apollo r2600 Gen10 Chassis Item Description SFF hot-plug drives Serial number/iLO information pull tab on page 62 Nonremovable bezel blank HPE Apollo r2800 Gen10 Chassis with 16 NVMe drives Item Description NVMe drives...

  • Page 62: Serial Number/Ilo Information Pull Tab

    Item Description SFF hot-plug drives Serial number/iLO information pull tab on page 62 SAS expander module Serial number/iLO information pull tab The serial number/iLO information pull tab is double-sided. One side shows the server serial number and the customer asset tag label. The other side shows the default iLO account information and QR code label.
  • Page 63 Item Description Status Definition Solid amber System in standby No power present Health LED (Server 2) Solid green Normal Flashing green iLO is rebooting Flashing amber System degraded Flashing red System critical Health LED (Server 1) Solid green Normal Flashing green iLO is rebooting Flashing amber System degraded...

  • Page 64: Front Panel Led Power Fault Codes

    Item Description Status Definition Flashing blue • 1 flash per second = Remote management or firmware upgrade in progress • 4 flashes per second = iLO manual soft reboot sequence initiated • 8 flashes per second = iLO manual hard reboot sequence in progress Deactivated Power On/Standby button and...

  • Page 65: Uid Button Functionality

    The UID button can be used to display the Server Health Summary when the server will not power on. For more information, see the latest HPE iLO 5 User Guide on the Hewlett Packard Enterprise website. SAS expander module LEDs The SAS expander module is only available in the HPE Apollo r2800 Gen10 Chassis with 24 SFF drive model.

  • Page 66: Power Supply Led

    Item Description Server 4 Server 3 Power supply 2 RCM module (optional) Power supply 1 Server 2 Server 1 2U system Item Description Server 3 Power supply 2 RCM module (optional) Power supply 1 Server 1 Power supply LED Component identification...

  • Page 67: Fan Bay Numbering

    Status Definition Solid green The power supply is operating normally. One or more of the following conditions exists • Power is unavailable • Power supply failure • Power supply is in standby mode • Power supply error Fan bay numbering •...

  • Page 68: Apollo R2200 Gen10 Chassis And Apollo R2600 Gen10 Chassis Drive Bay Numbering Using The Onboard Sata Port Connection In Ahci Mode

    When the backplane is connected to the SAS expander daughter card, all drive boxes are treated as a single box 1. This means that the drive bay numbering is continuous. Apollo r2200 Gen10 Chassis and Apollo r2600 Gen10 Chassis drive bay numbering using the onboard SATA port connection in AHCI mode •...

  • Page 69: Apollo R2600 Gen10 Chassis Drives Numbering Using A Smart Array Type-P Connection Or Onboard Sata Port Connection In Smart Array Sw Raid Mode

    ◦ Server 3 – Drive bays 3-5, 3-6 ◦ Server 4 – Drive bays 4-1, 4-2 Apollo r2600 Gen10 Chassis with 2U servers • Each 2U server supports 12 drives. • NVMe drive is supported in: ◦ Server 1 – Drive bays 1-5, 1-6, 1-9, 1-10 ◦...

  • Page 70: Apollo R2800 Gen10 Chassis Bay Numbering

    ◦ Server 1 – Drive bays 1-5, 1-6, 2-1, 2-2 ◦ Server 3 – Drive bays 3-5, 3-6, 4-1, 4-2 • If the 2U server drives are connected to an HPE Smart Array type-p controller, NVMe drive is only supported in: ◦...

  • Page 71: Drive Leds And Buttons

    RESTful API (the iLO Redfish API conformant) to assign the drives to specific server nodes for customized drive allocations to match specific workloads. For more information, see the Drive bay mapping section in the HPE iLO user guide on the Hewlett Packard Enterprise website (http:// www.hpe.com/support/ilo-docs).

  • Page 72: Hot-Plug Drive Led Definitions

    Item Status Definition Flashing green The drive is doing one of the following: • Rebuilding (1 flash per second) • Performing a RAID migration • Performing a strip size migration • Performing a capacity expansion • Performing a logical drive extension •...

  • Page 73: Nvme Ssd Led Definitions

    Item LED Status Definition The drive is doing one of the following: Flashing green • Rebuilding • Performing a RAID migration • Performing a strip size migration • Performing a capacity expansion • Performing a logical drive extension • Erasing •...

  • Page 74: Nvme Ssd Button Actions

    Item LED Status Definition The drive is doing one of the following: Flashing green • Rebuilding • Performing a RAID migration • Performing a stripe size migration • Performing a capacity expansion • Performing a logical drive extension • Erasing Flashing amber/ The drive is a member of one or more logical drives and predicts the green...

  • Page 75: Rcm Module

    Item Button Action Do Not Remove Press to open the release lever. Power Press to request PCIe ejection. Removal request can be denied by the: • RAID controller (one or more of the logical drives could fail) • Operating system RCM module RCM module components Item...

  • Page 76: Rcm Module Leds

    RCM module LEDs Item Description Status Definition 1 and 4 iLO activity LED Green or flashing green Network activity No network activity 2 and 3 iLO link LED Green Linked to network No network connection PDB assembly boards Item Description RPS link board PDB (power distribution board) PDB pass-through board...

  • Page 77: Cabling

    Cabling Cabling guidelines The cable colors in the cabling diagrams used in this chapter are for illustration purposes only. Most of the server cables are black. Observe the following guidelines when working with server cables. Before connecting cables • Note the port labels on the PCA components. Not all of these components are used by all servers: ◦...

  • Page 78: Front I/O Cabling

    • Remove cables that are no longer being used. Retaining them inside the server can restrict airflow. If you intend to use the removed cables later, label and store them for future use. Front I/O cabling Apollo r2200 Gen10 Chassis Cable color Description Orange...

  • Page 79: System Power Cabling

    Cable color Description Orange Left front I/O cable Blue Right front I/O cable System power cabling Apollo r2200 Gen10 Chassis Cable color Description Orange Power cable for servers 1 and 2 Blue Power cable for hot-plug drives Gold Power cable for servers 3 and 4 Cabling...
  • Page 80 Apollo r2600 Gen10 Chassis Cable color Description Orange Power cable for servers 1 and 2 Blue Power cable for hot-plug drives Gold Power cable for servers 3 and 4 Apollo r2800 Gen10 Chassis Cable color Description Orange Power cable for servers 1 and 2 Blue Power cable for hot-plug drives Gold...

  • Page 81: Pdb Pass-Through Board Cabling

    PDB pass-through board cabling Fan cabling Fan power cabling Cable color Description Orange Fan power cable for fans 1, 2, 5, and 6 Blue Fan power cable for fans 3, 4, 7, and 8 Cabling...

  • Page 82: Fan Signal Cabling

    Fan signal cabling Energy pack cabling Energy pack cabling in a chassis using an 800 W or 1600 W power supply Cabling...

  • Page 83: Rcm Cabling

    Energy pack cabling in a chassis using the 1800 W–2200 W power supply RCM cabling Cabling...

  • Page 84: Specifications

    Specifications Environmental specifications Specification Value Temperature range — Operating 10°C to 35°C (50°F to 95°F) Non-operating -30°C to 60°C (-22°F to 140°F) Relative humidity (noncondensing) — Operating 8% to 90% 28°C (82.4°F), maximum wet bulb temperature Non-operating 5% to 95% 38.7°C (101.7°F), maximum wet bulb temperature All temperature ratings shown are for sea level.

  • Page 85: Power Supply Specifications

    Apollo r2600 Gen10 Chassis Specifications Value Dimensions — Height 8.76 cm (3.45 in) Depth 83.87 cm (33.02 in) Width 44.80 cm (17.64 in) Weight (approximate values) — Weight (maximum) 36.20 kg (79.81 lb) Weight (minimum) 12.70 kg (28.00 lb) Apollo r2800 Gen10 Chassis with 16 NVMe drives Specifications Value Dimensions...

  • Page 86: Hpe 800W Flex Slot Platinum Hot-Plug Low Halogen Power Supply

    • HPE 800W Flex Slot Platinum Hot-plug Low Halogen Power Supply on page 86 • HPE 800W Flex Slot Universal Hot-plug Low Halogen Power Supply on page 87 • HPE 800W Flex Slot -48VDC Hot-plug Low Halogen Power Supply on page 88 •...

  • Page 87: Hpe 800W Flex Slot Universal Hot-Plug Low Halogen Power Supply

    Specification Value Rated steady-state power 800 W at 100 VAC to 127 VAC input 800 W at 100 VAC to 240 VAC input 800 W at 240 VDC input for China only Maximum peak power 800 W at 100 VAC to 127 VAC input 800 W at 100 VAC to 240 VAC input 800 W at 240 VDC input for China only HPE 800W Flex Slot Universal Hot-plug Low Halogen Power Supply...

  • Page 88: Hpe 800W Flex Slot -48Vdc Hot-Plug Low Halogen Power Supply

    HPE 800W Flex Slot -48VDC Hot-plug Low Halogen Power Supply Specification Value Input requirements — Rated input voltage -40 VDC to -72 VDC -48 VDC nominal input Rated input current 22.1 A at -40 VDC input 18.2 A at -48 VDC input, nominal input 12.0 A at -72 VDC input Rated input power (W) 874 W at -40 VDC input...

  • Page 89: Hpe 1600W Flex Slot Platinum Hot-Plug Low Halogen Power Supply

    CAUTION: This equipment is designed to permit the connection of the earthed conductor of the DC supply circuit to the earthing conductor at the equipment. If this connection is made, all of the following must be met: • This equipment must be connected directly to the DC supply system earthing electrode conductor or to a bonding jumper from an earthing terminal bar or bus to which the DC supply system earthing electrode conductor is connected.

  • Page 90: Hpe 1800W-2200W Flex Slot Platinum Hot-Plug Power Supply

    HPE 1800W–2200W Flex Slot Platinum Hot-plug Power Supply Specification Value Input requirements Rated input voltage 200 VAC to 240 VAC 240 VDC for China only Rated input frequency 50 Hz to 60 Hz (Not applicable to 240VDC) Rated input current 10.0 A at 240 VAC 8.2 A at 240 VDC for China Only Maximum rated input power...

  • Page 91: Websites

    Single Point of Connectivity Knowledge (SPOCK) Storage compatibility matrix www.hpe.com/storage/spock Storage white papers and analyst reports www.hpe.com/storage/whitepapers For additional general support websites, see Support and other resources. Product websites HPE Apollo 2000 Gen10 chassis support page http://www.hpe.com/info/Apollo2000-Gen10-Chassis-UG-en HPE Apollo 2000 Gen10 chassis user documents http://www.hpe.com/info/Apollo2000-Gen10-docs Websites...

  • Page 92: Support And Other Resources

    Accessing Hewlett Packard Enterprise Support • For live assistance, go to the Contact Hewlett Packard Enterprise Worldwide website: http://www.hpe.com/info/assistance • To access documentation and support services, go to the Hewlett Packard Enterprise Support Center website: http://www.hpe.com/support/hpesc Information to collect •...

  • Page 93: Customer Self Repair

    Customer self repair Hewlett Packard Enterprise customer self repair (CSR) programs allow you to repair your product. If a CSR part needs to be replaced, it will be shipped directly to you so that you can install it at your convenience.

  • Page 94: Acronyms And Abbreviations

    Acronyms and abbreviations AHCI Advanced Host Controller Interface Customer Self Repair Converged Network Adapter FHHL Full Height Half Length FC HBA Fibre Channel Host Bus Adapter HPE APM HPE Apollo Platform Management HPE SSA HPE Smart Storage Administrator Integrated Lights-Out Integrated Management Log International Organization for Standardization Internal faceplate-to-processor...
  • Page 95 power distribution unit POST Power-On Self-Test RBSU ROM-Based Setup Utility Rack Consolidation Management RoHS Restriction of Hazardous Substances serial attached SCSI SATA serial ATA small form factor Service Pack for ProLiant UEFI Unified Extensible Firmware Interface unit identification universal serial bus Acronyms and abbreviations...
