- Page 1 Air Activated Tube Tester 5373 Series For Tube ID Range 0.28”-1.23” (7.1mm-31.3mm) Tube & Pipe Cleaners Tube Testers Tube Plugs Tube Removal Tube Installation Operating and Maintenance Instructions www.elliott-tool.com...
- Page 2 5373 Air Activated Tube Tester...
-
Page 3: Table Of Contents
Table Of Contents Introduction ......................4 Operation Instructions ..................5 5373-1 Plugging Gun Illustration ................8 5372-2 Injection Gun Illustration ................9 Parts List ......................10 Seals & Support Tubes ..................11 5373 Air Activated Tube Tester... -
Page 4: Introduction
If this is a repeat purchase, you can rest assured that the same value you have received in the past will continue with all of your purchases, now and in the future. The 5373 Series Air Activated Tube Tester has been designed for the following types of equipment: Heat Exchangers... -
Page 5: Operation Instructions
The operators should always wear safety glasses or a face shield when testing with the 5373 or any type of pressure test guns. If the tubes have been acid cleaned please check with Elliott Customer Service regarding the compatibility of the test gun seals with the cleaning agent. Different types of elastomer seals are available as replacements. - Page 6 OPERATING INSTRUCTIONS (CONT.) Testing Procedure: Never actuate the injection gun unless the seal assembly is installed within the proper ID tube as the washers could be forced into the seal ID. The 5373 Tube Testing Guns come as a set. This set is comprised of: an air injection gun and a plugging gun.
- Page 7 OPERATING INSTRUCTIONS (CONT.) Installing Replacement Seals: Replacement seals for the 5373 guns are supplied with the corresponding size washers. Always replace the seals and washers on both guns at the same time. (See chart on page 9 for seal selection.) Remove the locknut (1) from the end of the support tube (4) and set it aside.
-
Page 8: 5373-1 Plugging Gun Illustration
5373-1 PlUGGING GUN IllUSTRATION 5373 Air Activated Tube Tester... -
Page 9: 5372-2 Injection Gun Illustration
5372-2 INjECTION GUN IllUSTRATION 5373 Air Activated Tube Tester... -
Page 10: Parts List
PARTS lIST Item No. Qty. Description Part No. Lock Nut .28" - .48" [7.1mm - 12.2mm] 5373LN1 .49" - .83" [12.4mm - 21.1mm] 5373LN2 .84" - 1.23" [21.3mm - 31.2mm] 5373LN3 2 sets Seal Set w/ Washers (See Chart on Page 9) Backup Washer Set .28"... -
Page 11: Seals & Support Tubes
SEAlS AND SUPPORT TUbES Seals & Washers Sets for 5373 Tube Tester Wall Tube O.D. Inches (mm) Gauge 1 (25.4) 1-1/8 1-1/4 1-3/8 1-1/2 (BWG) (12.7) (15.88) (19.05) (22.2) (28.58) (31.75) (34.9) (38.1) 5373-270 5373-400 5373-530 5373-650 5373-780 5373-900 5373-1050 5373-1150 10-11 5373-340 5373-440... - Page 12 Contact Us Elliott Tool offers a complete line of precision tube tools to meet your needs. Locally Supported By: Contact us or your local support. Elliott Tool Technologies, Ltd. 1760 Tuttle Avenue Dayton, Ohio 45403-3428 www.elliott-tool.com/support Phone: +1 937 253 6133 • +1 800 332 0447 Fax: +1 937 253 9189 www.elliott-tool.com...
