RVR Solar PJ2000M User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PJ2000M
User Manual
Manufactured by
Italy

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PJ2000M and is the answer not in the manual?

Questions and answers

Related Manuals for RVR Solar PJ2000M

Summary of Contents for RVR Solar PJ2000M

  • Page 1 PJ2000M User Manual Manufactured by Italy...
  • Page 2 PJ2000M - User Manual Versione 3.1 © Copyright 1993-2002 R.V.R. Elettronica SpA Via del Fonditore 2/2c - 40138 - Bologna (Italia) Telefono: +39 051 6010506 Fax: +39 051 6011104 Email: info@rvr.it Web: www.rvr.it All rights reserved Printed and bound in Italy. No part of this manual may be reproduced,...
  • Page 3 Notification of intended purpose and limitations of product use This product is a FM transmitter intended for FM audio broadcasting. It utilises operating frequencies not harmonised in the intended countries of use. The user must obtain a license before using the product in intended country of use.
  • Page 4 This page intentionally left blank...

  • Page 5: Table Of Contents

    6.1 Introduction 6.2 Unpacking 6.3 Installation 7. Maintenance 7.1 Introduction 7.2 Safety Consideration 7.3 Ordinary Maintenance 7.4 Equipment’s Card Replacement 7.5 Equipment Replacement 8. PJ2000M Adjustment 8.1 Adjustment Procedure 8.2 System Compensation 8.3 Trouble Shooting User Manual Rev. 3.0 - 26/04/01...
  • Page 6 PJ2000M Pagina lasciata intenzionalmente in bianco This page was intentionally left blank Rev. 3.0 - 26/04/01 User Manual...

  • Page 7: Preliminary Instructions

    PJ2000M 1. Preliminary instructions This manual is written as a general guide for those having previous knowledge and experience with this kind of equipment. It is not intended to contain a complete statement of all safety rules which should be observed by personnel in using this or other electronic equipment.
  • Page 8 PJ2000M Pagina lasciata intenzionalmente in bianco This page was intentionally left blank 2 / 18 Rev. 3.1 - 20/11/02 User Manual...

  • Page 9: Warranty

    PJ2000M 2. Warranty Any product of R.V.R. Elettronica is covered by a 12 (twelve) month warranty. For components like tubes for power amplifiers, the original manufacturer’s warranty applies. R.V.R. extends to the original end-user purchaser all original manufacturers warranties which are transferable and all claims are to be made directly to R.V.R. per indicated procedures.
  • Page 10 PJ2000M DO NOT RETURN UNITS WITHOUT OUR AUTHORIZATION AS THEY WILL BE REFUSED. a Be sure to enclose a written technical report where mention all the problems found and a copy of your original invoice establishing the starting date of the warranty.

  • Page 11: First Aid

    PJ2000M 3. First Aid The personnel employed in the installation, use and maintenance of the device, shall be familiar with theory and practice of first aid. 3.1 Treatment of electrical shocks 3.1.1 If victim is not responsive follow the A-B-C's of basic life support •...

  • Page 12: If Victim Is Responsive

    PJ2000M 3.1.2 If victim is responsive • Keep them warm Keep them as quiet as possible • Loosen their clothing (a reclining position is recommended) • Call for medical help as soon as possible • 3.2 Treatment of electrical Burns 3.2.1 Extensive burned and broken skin...

  • Page 13: General Description

    The PJ2000M comprises two PJ1000M MosFet amplifiers connected with an HC2- 2 hybrid combiner. The PJ2000M is housed in a 19” rack-mountable frame, 20U high, of which 5U are free and may be used for an exciter or other equipment.

  • Page 14: Electrical Description

    The HC2-2 Hybrid Combiner has the function of a driver power divider coming from the exciter and of a combiner of the amplifiers power output, to generate the antenna final output. The diagram of the connections beetween the components of the PJ2000M is shown in Figure 2. Figure 2 [1] HC2-2 OUT 1 PJ1000M “B”...

  • Page 15: Technical Specifications

    PJ2000M 5. Technical Specifications The electrical and the phisique specifications of the PJ2000M are given below. For details about the components of the amplifier (PJ1000M) and the hybrid combiner (HC2) see the relative manuals. 5.1 Dimensional and Environmental Specifications Rack Dimensions 565.0 mm (22,24”) x 850.0 mm (33,46”) x...
  • Page 16 PJ2000M Pagina lasciata intenzionalmente in bianco This page was intentionally left blank 10 / 18 Rev. 3.1 - 20/11/02 User Manual...

  • Page 17: Installation Procedure

    6.3 Installation After all the connections have been made between the individual devices, it is necessary to perform the following operations to install the PJ2000M: With the help of Figure 2, verify that all the connections are in perfect condition.
  • Page 18 PJ2000M Increase the exciter output power in order to have 2000W power on the PJ2000M. Switch the meter selector of the HC2-2 to the RFL position and verify that the meter needle is at zero. Note: To verify the correct balancing of the two PJ1000M modules, do switch the meter selector of the HC2-2 to UNBAL position and verify that the power isn't more than 20W.

  • Page 19: Maintenance

    FIRST LEVEL MAINTENANCE 7.3 Ordinary Maintenance The only regular maintenance needed by PJ2000M, is the periodic substitution of the blowers, and the cleaning of dust filters and any dust accumulated inside the amplifier. The time between overhauling of the blowers depends upon several environmental factors, temperature, humidity, dust pollution etc.

  • Page 20: Equipment Replacement

    PJ2000M 7.5 Equipment Replacement If it’s necessary to replace a power amplifier or the hybrid coupler, it is advisable to perform the adjustment of the sytem. Refer to chapter 8 for directions. 14 / 18 Rev. 3.1 - 20/11/02 User Manual...

  • Page 21: Pj2000M Adjustment

    PJ2000M 8. PJ2000M Adjustment 8.1 Adjustment Procedure NOTE: Before any adjustment operation (such as a dummy load substitution or an interconnection cable replacement) switch off the system. To obtain a correct configuration it is necessary to perform the following operations: Verify that the two PJ1000M amplifiers have the same gain (for the same input they have the same output power), and verify the output is 1000W or more.

  • Page 22: System Compensation

    PJ2000M 11) Increase the exciter output power in order to have 2000W power on the PJ2000M, if the output power is less than 2000W proceed with the compensation of the system. 8.2 System Compensation On the coupler instrument, select the Forward power measurement mode.

  • Page 23: Trouble Shooting

    PJ2000M Figure 4 Adjust the variable capacitors (3) and (4), relative to the second amplifier relative to the second amplifier output, to maximize the power level measured by the Coupler’s instrument. Repeat steps 6 and 7 until the system power reaches its maximum.
  • Page 24 PJ2000M Verify the integrity of the connection cables between the outputs of the two PJ1000M amplifiers and the HC2-2 Hybrid Combiner (absence of short circuits and correct connector mating). Verify the correct connection of the interconnection cables between modules. 18 / 18 Rev.
