The AC850 Battery Charger is a four-port unit for charging the BAT850 NiMH Rechargeable
Battery Pack, used with the PRO850 Wireless Intercom. AC850 maximum charging time is 3
hours, for a fully discharged battery pack. To operate the AC850, follow the instructions below.
Figure 1.

SETUP

Figure 2.
•
Plug the connector on the power adapter cable into the receptacle on back of the AC850 as
shown in Figure 2.
•
Plug the female connector on the AC cord into the power adapter as shown in Figure 3.
•
Plug the other end of the AC cord into an electrical outlet.
A red POWER light adjacent to each of the four charging ports should come on when the power
cord is plugged in. The POWER lights will remain on as long as the unit is plugged in.
HM ELECTRONICS, INC.
OPERATING INSTRUCTIONS
Power
adapter
AC 850 Battery Charger
14110 Stowe Drive, Poway, CA 92064 USA

Battery Charger

AC cord
Figure 3.
AC850
HME# 400548
Rev −
7/26/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC850 and is the answer not in the manual?

Questions and answers

Related Manuals for HME AC850

Summary of Contents for HME AC850

  • Page 1: Battery Charger

    Figure 2. Figure 3. • Plug the connector on the power adapter cable into the receptacle on back of the AC850 as shown in Figure 2. • Plug the female connector on the AC cord into the power adapter as shown in Figure 3.

  • Page 2: Specifications

    Fully charged battery packs can be left in the charging port indefinitely without harm. The green READY light will remain on until the battery pack is removed from the port. SPECIFICATIONS AC850 Battery Charger: Power Input 15VDC, under 50 watts maximum Operating Temperature * 32°F - 104°F (0°C –...
