Page 1 ORDER NO. VED0612375C0 DLP Based Projector PT-D10000U PT-D10000E PT-DW10000U PT-DW10000E © 2006 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying distribution is a violation of law.
Page 2 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 3: Table Of Contents
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E CONTENTS Page Page 1 Safety Precautions 12.14. Removal of S-P.C.Board 1.1. General Guidelines 12.15. Removal of SL-P.C.Board 1.2. Leakage Current Check 12.16. Removal of K-Module 1.3. UV Precaution and UHM Lamp Precautions 12.17. Removal of B/Q-Module 2 Specifications 12.18.
Page 4 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.22. B-Module (2/2) 17.4. G-P.C.Board (Component Side) 17 Circuit Boards 17.5. S-P.C.Board 17.1. A-P.C.Board (Foil Side) 18 Terminal guide of ICs and transistors 17.2. A-P.C.Board (Component Side) 19 Exploded Views 17.3. G-P.C.Board (Foil Side)
Page 5: Safety Precautions
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 1 Safety Precautions 1.1. General Guidelines · For continued safety, no modification of any circuit must be attempted. · Unplug the power cord from the power outlet before disassembling this projector. · Use correctly the supplied power cord and must ground it.
Page 6: Specifications
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 2 Specifications...
Page 7 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 8: Function For Safety
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 3 Function for Safety 3.1. Temperature Detection inside the Lamp Unit This projector has 2 bimetals contacting the lamp units to protect the lamps. If the temperature of one of the lamp units exceeds 150°C, the bimetals will operate to turn off the power.
Page 9: Setting To Serviceman Mode
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 4.1. Setting to Serviceman Mode Press the MENU button. The MAIN MENU screen will be displayed. Select “OPTION2” using the buttons and press the ENTER button. The OPTION2 screen will be displayed. Select “PASSWORD” using the buttons and press the ENTER button.
Page 10: Resetting To User Mode
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 4.2. Resetting to User Mode Press the MENU button. The MAIN MENU screen will be displayed. Select “OPTION2” using the buttons and press the ENTER button. The OPTION2 screen will be displayed. Select PASSWORD using the buttons and press the ENTER button.
Page 11 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Sets the VCO and the charge pump. 4.3.2. Additional Functions for OPTION2 · MAX AVAILABLE LAMP Sets the maximum number of lamps that can be used. Usually, set it to "4". · AIR FILTER CLEANING CLEANING menu is added into AIR FILTER CLEANING.
Page 12 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E The display contents of SELF CHECK are as follows. 4.3.3. Addition of EXTRA OPTION · LIGHT OUTPUT Adjusts brightness with Dynamic Iris. It darkens as the value becomes small. · CUT OFF Sets whether to display each color of Red, Green and Blue.
Page 13 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E [DEFAULT] [D7700] [L6600] [USER] Be able to allocate arbitrary input switching functions into the pins 3-7. Be able to allocate POWER into the pin 2. Be able to allocate SHUTTER into the pin 8.
Page 14: Self-Diagnosis Display
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E · COLOR FILTER NONE: Default setting INSTALLED: When installing the color filter that expands the color region · UNIFORMITY Sets the value of color unevenness correction. · FRONT LAMP LED ON: Default setting OFF: Prohibits a green lighting.
Page 15 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Error-code Contents Shutdown Error display condition Remarks Lamp 1 going out Lamp goes out after turning on. LAMP monitor blinks 3 times in Lamp 2 going out red. Lamp 3 going out Lamp 4 going out...
Page 16 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Error-code Contents Shutdown Error display condition Remarks Flash ROM error The circuit around CPU on A-P.C.Board is abnormal. RAM error FPGA expansion error Lens shift error The circuit for lens position detection is abnormal.
Page 17: Using The Serial Terminals
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 6 Using the Serial Terminals THe main unit is equipped with SERIAL terminals located in its terminal section on the side, and this terminal is compliant with RS- 232C/RS-422. Also a serial output terminal is provided to enable plural projector control.
Page 18: Pin Assignments And Signal Names
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 6.2. Pin Assignments and Signal Names RS-232C RS-422 6.3. Communication Conditions (Factory Setting) 6.4. Procedure of Communication Condition Settings Press the MENU button. The MAIN MENU screen will be displayed. Select OPTION2 using the...
Page 19: Control Commands
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Press the ENTER button. The OPTION2 screen will be displayed. Select RS232C using the buttons. Press the ENTER button. The RS-232C screen will be displayed. Select SERIAL IN using the buttons. Press buttons to switch SERIAL IN.
Page 20 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Note To connect the computer to the SERIAL terminal, prepare an adequate communication cable that fits to your personal computer.
Page 21: Using A Wired Remote Control
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 7 Using a Wired Remote Control 7.1. Connection Example When multiple main units are connected as part of the system, connect to units with a M3 stereo mini jack cable (sold separately) to simultaneously control multiple main units with a single remote control through the REMOTE1 IN/OUT terminal. It is effective to use the wired remote control in the environment in which an obstacle stands in the light path or where devices are susceptible to outside light.
Page 22: Support For Service
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 8 Support for Service 8.1. Supporting Methods We will support according to the following methods. Supporting methods Applied parts K-Module PC-Module PF-Module NN-Module FH-Module B/Q-Module (For specified components, supplies them discretely.) CL-P.C.Board J-P.C.Board J2-P.C.Board...
Page 23: Parts Location
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 10 Parts Location 10.1. Electrical Parts Location 10.2. Electromechanical Parts Location...
Page 24: Replacement Of Lamp Unit
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 11 Replacement of Lamp Unit Cautions · Wait until the lamp is cooled sufficiently before replacing the lamp unit. · Make sure that all four lamp units are installed. · Replace of the lamp unit should be carried out by a qualified technician.
Page 25: Indication Of Lamp Monitor
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 11.3. Indication of Lamp Monitor...
Page 26: Disassembly Instructions
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 12 Disassembly Instructions 12.1. Flowchart for Disassembly To assemble, reverse the disassembly procedures.
Page 27: Removal Of Upper Case
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 12.2. Removal of Upper Case While pressing the projection lens cover lock buttons, pull the cover forward to remove it. Unscrew the 2 screws and remove the front case. Loosen the 1 screw until it idles and open the lamp unit cover.
Page 28: Removal Of A-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 12.3. Removal of A-P.C.Board Remove the G-P.C.Board according to the section 12.6. "Removal of G-P.C.Board". Unscrew the 4 screws and remove the FH-Module. Note: · The FH-Module is connected onto the A-P.C.Board with the connector.
Page 29: Removal Of Fh-Module
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 3 screws and remove the front cover. Unscrew the 1 screw and remove the CL-P.C.Board. 12.5. Removal of FH-Module Remove the upper case according to the section 12.2. "Removal of Upper Case".
Page 30 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 4 screws and remove the signal processing block. While pressing to shut each hook of the 3 resinous stands, remove the NN-Module. Unscrew the 19 screws and remove the connection terminals...
Page 31: Removal Of J-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 5 screws and remove the G-P.C.Board. Note: · The G-P.C.Board is connected onto the A-P.C.Board with the connector. Work carefully when removing it. 12.7. Removal of J-P.C.Board Remove the A-P.C.Board according to the section 12.3.
Page 32: Removal Of L1-/L2-/L3-/L4-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Remove the upper case according to the section 12.2. "Removal of Upper Case". Unscrew the 3 screws and remove the J2-P.C.Board. 12.9. Removal of L1-/L2-/L3-/L4-P.C.Board · The procedure is described as an example of L2-P.C.Board.
Page 33: Removal Of Nn-Module
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 2 screws and remove the L2-P.C.Board. 12.10. Removal of NN-Module Remove the upper case according to the section 12.2. "Removal of Upper Case". While pressing to shut each hook of the 3 resinous stands, remove the NN-Module.
Page 34: Removal Of R2-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 2 screws and remove the front case. Unscrew the 2 screws and remove the R-P.C.Board. 12.12. Removal of R2-P.C.Board Loosen the 1 screw until it idles and open the lamp unit cover.
Page 35: Removal Of R3-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 12.13. Removal of R3-P.C.Board Loosen the 1 screw until it idles and open the lamp unit cover. Unscrew the 2 screws and remove the R3-P.C.Board. 12.14. Removal of S-P.C.Board Remove the upper case according to the section 12.2. "Removal of Upper Case".
Page 36: Removal Of Sl-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 4 screws and remove the S-P.C.Board. 12.15. Removal of SL-P.C.Board Remove the upper case according to the section 12.2. "Removal of Upper Case". Unscrew the 2 screws and remove the SL-P.C.Board.
Page 37 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Remove the upper case according to the section 12.2. "Removal of Upper Case". Loosen each of 3 screws until they idle, remove the lamp units 1 and 2. Unscrew each of 1 screw and release each of 1 lamp unit terminal of Ballast-1 and Ballast-2.
Page 38 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 6 screws and remove the ballast fan mesh. Unscrew the 3 screws and separate the Ballast-1 and Ballast-2. Unscrew the 2 screws and remove the ballast fan. Unscrew the 3 screws and separate the ballast PFC cases 1 and...
Page 39: Removal Of Pf-Modele
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 4 screws and remove the B/Q-Module. 12.18. Removal of PF-Modele Remove the ballast PFC cases 2 according to the steps 1 through 8 in the section 12.17. "Removal of B/Q-Module". Unscrew the 4 screws and remove the PF-Module.
Page 40 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 3 screws and remove the PC block. Unscrew the 4 screws and remove the PC case cover. Unscrew the 4 screws and remove the PC-Module.
Page 41: Removal Of Projection Lens
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 12.20. Removal of Projection Lens While pressing the projection lens cover lock buttons, pull the cover forward to remove it. While holding down the projection lens lock button, turn the projection lens counterclockwise, and then pull it off.
Page 42: Removal Of Iris Unit
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Loosen the 3 screws until they idle and remove the lamp unit 2. Note: · When installing the lamp unit in the main unit, place it in a specified position and press the back of the lamp unit (arrow positions shown in right figure), and confirm the lamp unit is inserted securely.
Page 43: Removal Of Analysis Block
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 3 screws and remove the iris unit. 12.23. Removal of Analysis Block Remove the upper case according to the section 12.2. "Removal of Upper Case". Unscrew the 4 screws and remove the rear metal fittings.
Page 44 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew each of 1 screw and release 4 lamp unit terminals in total of the 4 ballasts. Unscrew the 2 screws and remove the dynamic iris cover. Unscrew the 3 screws and remove the iris unit.
Page 45 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Unscrew the 8 screws and remove the color prism block and analysis block. (10) Unscrew each of 2 screws and remove the 4 lamp duct blocks. (11) Unscrew the 4 screws and separate the analysis block and color...
Page 46: Removal Of Color Prism Block
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 12.24. Removal of Color Prism Block Remove the color prism block (with lamp case) according to the section 12.23. "Removal of Analysis Block". Unscrew each of 3 screws and remove the 4 lamp cases.
Page 47 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Remove the projection lens according to the section 12.20. "Removal of Projection Lens". Remove the upper case according to the section 12.2. "Removal of Upper Case". Unscrew the 4 screws and remove the DMD duct block.
Page 48: Removal Of Analysis Mirror
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 12.26. Removal of Analysis Mirror Note: · Before attempting the removing, shift the lens to the foremost position. Remove the DMD block and liquid cooling unit according to the section 12.25. "Removal of DMD Block and Liquid Cooling Unit".
Page 49: Troubleshooting
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 13 Troubleshooting The alphabets (A, PC, etc.) in the left box of the inspection items indicate the names of P.C.Boards or modules to be checked.
Page 50 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 51 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 52 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 53 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 54 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 55 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 56 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 57 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 58 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 59 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 60 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 61 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 62 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 63 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 64 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 65 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 66 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 67 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 68 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 69: Interconnection Block Diagram
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 14 Interconnection Block Diagram 14.1. Interconnection Block Diagram (1/4) Interconnection Block Diagram (1/4) CL-P.C.Board P.C.Board P.C.Board G-P.C.Board PC-Module R-P.C.Board S-P.C.Board K-Module P.C.Board P.C.Board P.C.Board...
Page 70 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 14.2. Interconnection Block Diagram (2/4) Interconnection Block Diagram (2/4) J3-P.C.Board J2-P.C.Board G-P.C.Board L1-P.C.Board L2-P.C.Board Q-Module Q-Module B-Module B-Module E-P.C.Board E-P.C.Board B/Q-Module B/Q-Module...
Page 71 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 14.3. Interconnection Block Diagram (3/4) Interconnection Block Diagram (3/4) A-P.C.Board L3-P.C.Board L4-P.C.Board Q-Module Q-Module B-Module B-Module E-P.C.Board E-P.C.Board B/Q-Module B/Q-Module...
Page 72: Interconnection Block Diagram (4/4) (Pt-D10000U/E)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 14.4. Interconnection Block Diagram (4/4) (PT-D10000U/E) Interconnection Block Diagram (4/4) (PT-D10000U/E) J-P.C.Board FH-Module A-P.C.Board FG-Module FR-Module FB-Module...
Page 73 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 14.5. Interconnection Block Diagram (4/4) (PT-DW10000U/E) Interconnection Block Diagram (4/4) (PT-DW10000U/E) J-P.C.Board FH-Module A-P.C.Board FR-Module FG-Module FG-Module...
Page 74 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 75: Block Diagram
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 15 Block Diagram 15.1. Power Supply (1/2) Power Supply (1/2) Bimetal COLD 3.3V PC-Module DC/DC Bimetal STB15V CONVERTOR G-P.C.Board F011 3.3V LINE FILTER STB5V Power Cord STB5V F021 For switches AC IN LINE...
Page 76: Power Supply (2/2)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 15.2. Power Supply (2/2) Power Supply (2/2) DC380V D101 Q9606 Q9610 Q9603 Q9614 Q9615 450V 85V or less more IC101 Q102, Q103 CONTROL CIRCUIT I sense IGNITER BLOCK VOLTAGE STEP-DOWN FEED BACK Q9607...
Page 77: Signal Processing (1/2)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 15.3. Signal Processing (1/2) Signal Processing (1/2) IC2002 IC3008 IC3003 RTFV VIDEO DECODER, S-VIDEO IC3001 A/D CONVERTER, VIDEO RESET VIDEO X3001 (20.25 MHz) IC3002 IC3006 SDRAM FPGA IC3007 S/VIDEO IC3015 RGBCLKP PWRDN A/D CONVERTER...
Page 78: Signal Processing (2/2) (Pt-D10000)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 15.4. Signal Processing (2/2) (PT-D10000) Signal Processing (2/2) (for PT-D10000*) A-P.C.Board X4302 IC4302 100 MHz IC4301 LVDS FORMATTER RECEIVER POCLK CONTROL IC2005 IC5001 IC4309 FLASH BUFFER RDRAM MEMORY IC4306 IC4304 0.95 IP CONVERTER,...
Page 79 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 15.5. Signal Processing (2/2) (PT-DW10000) Signal Processing (2/2) (for PT-DW10000*) IC4007 IC4008, IC4009 A-P.C.Board IC5106 LVDS RLDRAM RECEIVER REBOOTZ IC4002 RESET FPGA RLDRAM POCLK TERM. REG IC4003 IC2005 IC5001 Q4002 RLDRAM RESET IC4005 0.95...
Page 80: Control And Driving System (1/2)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 15.6. Control and Driving System (1/2) Control and Driving System (1/2) POSITION DET • SW LENS NN-Module SHUTTER IC3701 IC3706 P.C.Board 128M INVERTORS SDRAM 3703 3704 RXD_LAN P.C.Board IC3703 IC3710 TXD_LAN NETWORK SDA_LAN...
Page 81 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 15.7. Control and Driving System (2/2) Control and Driving System (2/2) LIQUID LIQUID COOLING COOLING BALLAST BALLAST LAMP LAMP RADIATOR FAN 3 FAN 4 FAN 3 FAN 4 PUMP (G) PUMP (B) LH-Module...
Page 82 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 83: Schematic Diagram
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16 Schematic Diagram...
Page 84: P.c.board (1/11)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.1. A-P.C.Board (1/11) A-P.C.Board TXN/A1VKC8 (1/11)
Page 85 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.2. A-P.C.Board (2/11) A-P.C.Board TXN/A1VKC8 (2/11)
Page 86 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.3. A-P.C.Board (3/11) A-P.C.Board TXN/A1VKC8 (3/11)
Page 87 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.4. A-P.C.Board (4/11) A-P.C.Board TXN/A1VKC8 (4/11)
Page 88 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.5. A-P.C.Board (5/11) A-P.C.Board TXN/A1VKC8 (5/11)
Page 89 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.6. A-P.C.Board (6/11) A-P.C.Board TXN/A1VKC8 (6/11)
Page 90: P.c.board (7/11)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.7. A-P.C.Board (7/11) A-P.C.Board TXN/A1VKC8 (7/11)
Page 91 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.8. A-P.C.Board (8/11) A-P.C.Board TXN/A1VKC8 (8/11)
Page 92 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.9. A-P.C.Board (9/11) A-P.C.Board TXN/A1VKC8 (9/11)
Page 93 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.10. A-P.C.Board (10/11) A-P.C.Board TXN/A1VKC8 (10/11)
Page 94 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.11. A-P.C.Board (11/11) A-P.C.Board TXN/A1VKC8 (11/11)
Page 95 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.12. G-P.C.Board (1/5) G-P.C.Board TNPA3941 (1/5)
Page 96: P.c.board (2/5)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.13. G-P.C.Board (2/5) G-P.C.Board TNPA3941 (2/5)
Page 97 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.14. G-P.C.Board (3/5) G-P.C.Board TNPA3941 (3/5)
Page 98 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.15. G-P.C.Board (4/5) G-P.C.Board TNPA3941 (4/5)
Page 99 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.16. G-P.C.Board (5/5) G-P.C.Board TNPA3941 (5/5)
Page 100 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.17. J-P.C.Board J-P.C.Board TNPA3940...
Page 101: J2/J3/L1/L2/L3/L4-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.18. J2/J3/L1/L2/L3/L4-P.C.Board J2-P.C.Board TNPA4122 L1-P.C.Board TNPA3946 L2-P.C.Board TNPA3947 L3-P.C.Board TNPA3948 J3-P.C.Board TNPA4123 L4-P.C.Board TNPA3949...
Page 102: R2/R3/Sl/Cl-P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.19. R/R2/R3/SL/CL-P.C.Board R-P.C.Board TNPA3939 R2-P.C.Board TNPA4072 R3-P.C.Board TNPA4124 SL-P.C.Board TNPA4125 CL-P.C.Board TNPA4126...
Page 103: P.c.board
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.20. S-P.C.Board S-P.C.Board TNPA3938...
Page 104: Module (1/2)
PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.21. B-Module (1/2) B-Module TXN/B1VKC8 (1/2) Module Replacement Only supplied components IC9601-03, Q9601-12 Q9614-15, D9601-2, D9604-09, D9611-14, D9616-29, D9650-53, R9601, R9630-34, R9636-40, R9653, R9693, C9603, C9610, C9617-19, T9604, S9602, TXJ/L2VKC8...
Page 105 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 16.22. B-Module (2/2) B-Module TXN/B1VKC8 (2/2) Module Replacement Only supplied components IC9601-03, Q9601-12 Q9614-15, D9601-2, D9604-09, D9611-14, D9616-29, D9650-53, R9601, R9630-34, R9636-40, R9653, R9693, C9603, C9610, C9617-19, T9604, S9602, TXJ/L2VKC8...
Page 106 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 107 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 17 Circuit Boards 17.1. A-P.C.Board (Foil Side) A-P.C.Board TXN/A1VKC8 (Foil Side) A-P.C.Board (Foil Side) IC2000 IC2611 IC3010 IC2002 IC2612 IC3011 IC2003 IC2615 IC3012 IC2005 IC2617 IC3013 IC2007 IC2618 IC3017 IC2505 IC2619 IC3019 IC2508...
Page 108 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 17.2. A-P.C.Board (Component Side) A-P.C.Board TXN/A1VKC8 (Component Side) A-P.C.Board (Component Side) IC2001 IC2512 IC3001 IC2006 IC2513 IC3002 IC2009 IC2514 IC3003 IC2010 IC2515 IC3004 IC2501 IC2516 IC3008 IC2503 IC2613 IC3009 IC2504 IC2614 IC3015 IC2506...
Page 109 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 17.3. G-P.C.Board (Foil Side) G-P.C.Board TNPA3941 (Foil Side) G-P.C.Board (Foil Side) IC6001 IC6012 IC6511 IC6002 IC6013 IC6512 IC6003 IC6501 IC6513 IC6004 IC6503 IC6514 IC6005 IC6504 IC6516 IC6007 IC6505 IC6519 IC6008 IC6506 IC6521 IC6009...
Page 110 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 17.4. G-P.C.Board (Component Side) G-P.C.Board TNPA3941 (Component Side) G-P.C.Board (Component Side) IC6014 IC6518 IC6502 IC6523 IC6507 TRANSISTOR Q6005 Q6514 Q6006 Q6516 Q6501 Q6517 Q6502 Q6812 ADDRESS INFORMATION...
Page 111 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 17.5. S-P.C.Board S-P.C.Board TNPA3938 S-P.C.Board TNPA3938 (Foil Side) (Component Side) S-P.C.Board (Component Side) IC9001 IC9002 IC9003 IC9004 IC9005 ADDRESS INFORMATION...
Page 112 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 113 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 18 Terminal guide of ICs and transistors...
Page 114 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 19 Exploded Views...
Page 115 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 116 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 117 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 118 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 119 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E...
Page 120 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E 20 Replacement Parts List Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description THEA162 SPACER [MECHANICAL PARTS] THEC084N D-SUB SCREW THEC096 SCREW D4CDY4930001 TEMP SENSOR THEC097...
Page 121 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TPDF1828 ACCESSORY CARTON TXFPC99QDJZ CARTON PT-D10000U TPDF1882 FRONT PAD TXFPC99QDLZ CARTON PT-D10000E TPEH335 SET COVER TXFPC99QDHZ CARTON...
Page 122 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description TXZEE01VKC8 ANALYSIS BLOCK PT-D10000U/E IC2604 C0JBAR000415 TXZEE01VKC9 ANALYSIS BLOCK PT-DW10000U/E IC2605 C0JBAR000415 TXZEE02VKC8 ANALYSIS MIRROR IC2609 C0JBAR000415...
Page 123 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description IC6518 C0GAK0000007 Q3009 B1ADCF000063 TRANSISTOR IC6519 C0FBBD000183 Q3010 XP0460100L TRANSISTOR IC6521 C0DBAKH00003 Q3011 XP0460100L TRANSISTOR IC6522 C0DBAKH00003...
Page 124 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description Q9606 TYPQ9606VKC8 TRANSISTOR D3050 EZAEG2A50AX DIODE Q9607 B1CERQ000036 TRANSISTOR D3051 EZJZ0V171AA VARISTOR Q9608 2SB0710AWL TRANSISTOR D3052 EZJZ0V171AA...
Page 125 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description D9618 MA2Z72000L DIODE L6511 J0JCC0000168 FILTER D9619 MA2Z72000L DIODE L6512 J0JHC0000078 FILTER D9620 MA2Z72000L DIODE L6513 J0JCC0000168...
Page 126 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description FL2533 J0HAAB000040 FILTER FL6047 J0HAAB000036 FILTER FL2534 J0HAAB000040 FILTER FL6048 J0HAAB000036 FILTER FL2535 J0HAAB000040 FILTER FL6049 J0HAAB000036...
Page 127 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R2006 D1HG33080001 RESISTOR R2150 ERJ2GE0R00X M 0 OHM, 0.063W R2007 D1HG1528A002 RESISTOR R2155 EXB28V472J RESISTOR ARRAY R2008...
Page 128 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R2232 ERJ3GEYJ680 M 68 OHM,J,1/16W R2569 EXB38V220J RESISTOR ARRAY R2233 ERJ3EKF1000 M 100 OHM, 1/16W R2570 ERJ3GEYJ220...
Page 129 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R2653 EXB38V220J RESISTOR ARRAY R2728 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R2654 EXB38V220J RESISTOR ARRAY R2729 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R2655...
Page 130 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R2805 ERJ3GEYJ562 M 5.6KOHM,J,1/16W R3003 ERJ6ENF1500 M 150 OHM, 1/10W R2806 ERJ3GEYJ562 M 5.6KOHM,J,1/16W R3004 ERJ3EKF1500 M 150 OHM, 0.063W...
Page 131 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R3089 ERJ3GEYJ330 M 33 OHM,J,1/16W R3168 ERJ3GEYJ331 M 330 OHM,J,1/16W R3090 EXB38V330J RESISTOR ARRAY R3169 ERJ3GEYJ331 M 330 OHM,J,1/16W...
Page 132 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R3256 EXB38V330J RESISTOR ARRAY R3335 D1HG33080001 RESISTOR R3257 ERJ3GEYJ101 M 100 OHM,J,1/16W R3336 ERJ6GEY0R00 M 0 OHM,J,1/10W...
Page 133 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R6032 ERJ6GEYJ221 M 220 OHM,J,1/10W R6130 ERJ3GEYJ220 M 22 OHM,J,1/16W R6033 ERJ6GEYJ221 M 220 OHM,J,1/10W R6132 ERJ3GEYJ220...
Page 134 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R6595 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R6710 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R6596 ERJ3GEYJ473 M 47K OHM,J,1/16W R6711 ERJ3GEYJ472 M 4.7KOHM,J,1/16W...
Page 135 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C2004 ECJ2FF1A106Z C 10UF, 10V C2086 ECJ0EF1C104Z C 0.1UF, 16V C2005 F2G1E4R70007 CAPACITOR C2087 ECJ1VF1A105Z C 1UF, Z, 50V...
Page 136 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C2518 ECJ1VF1C104Z C 0.1UF, Z, 16V C2599 ECJ1VB1A105K CAPACITOR C2521 ECJ1VF1C104Z C 0.1UF, Z, 16V C2600 ECJ1VB1A105K...
Page 137 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C3020 F2G1A101A029 CAPACITOR C3123 ECJ1VB1H103K C 0.01UF, K, 50V C3021 ECJ1VC1H680J CAPACITOR C3124 ECJ1VB1H103K C 0.01UF, K, 50V...
Page 138 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C3197 EEFUD0J101R CAPACITOR C3272 ECJ1VB1A105K CAPACITOR C3198 ECJ1VF1C104Z C 0.1UF, Z, 16V C3273 ECJ1VB1A105K CAPACITOR C3199 ECJ1VF1C104Z C 0.1UF, Z, 16V...
Page 139 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C6520 F1L1C226A007 CAPACITOR C6621 ECJ1VF1C104Z C 0.1UF, Z, 16V C6521 F1L1C226A007 CAPACITOR C6801 F1L1C226A007 CAPACITOR C6522 ECJ1VF1C104Z C 0.1UF, Z, 16V...
Page 140 PT-D10000U / PT-D10000E / PT-DW10000U / PT-DW10000E Ref. Part No. Part Name & Remarks Description K1KA20AA0178 CONNECTOR K1KA04AA0104 4P CONNECTOR K1KA03AA0104 3P CONNECTOR K1KA02AA0104 2P CONNECTOR K1KA05A00466 5P CONNECTOR K1KA05AA0104 5P CONNECTOR K1KA03AA0263 3P CONNECTOR K1KA04AA0083 4P CONNECTOR K1KA14A00135 CONNECTOR...

This manual is also suitable for:

Pt-d10000e Pt-dw10000u Pt-dw10000e

Panasonic PT-D10000U Service Manual

1 Safety Precautions

2 Specifications

3 Function for Safety

4 Serviceman Mode

5 Self-Diagnosis Display

6 Using the Serial Terminals

7 Using a Wired Remote Control

8 Support for Service

10 Parts Location

11 Replacement of Lamp Unit

12 Disassembly Instructions

Troubleshooting

15 Block Diagram

16 Schematic Diagram

Quick Links

Related Manuals for Panasonic PT-D10000U

Summary of Contents for Panasonic PT-D10000U

This manual is also suitable for:

Table of Contents
