2010-2T-19 Rack Mount Kit Installation Sheet
EN CA CS DA DE ES
1
EN: Installation Sheet
Description
The 2010-2T-19 Rack Mount kits let you install compatible
addressable control panels into standard 19-inch racks. Size
compatibility is shown in Table 1, below.
Table 1: Kit and panel size compatibility
Kit
Size
2010-2T-19-S
Small
2010-2T-19
Large
[1] Back cabinet.
© 2012 UTC Fire & Security. All rights reserved.
FI
FR HU
IT
LT NL NO PL
Panel dimensions (W × H × D) [1]
400 × 282 × 102 mm
440 × 533 × 111 mm
PT RO RU SK SV TR
2
Installation
The kit is supplied with flat head, countersunk screws for easy
installation.
You'll also need eight additional screws. Use screws specified
as compatible by the rack vendor. The mounting screws must
support up to 25 kg.
See the Specification table below for the number of rack
units (U) required to complete the installation. One rack
unit (1U) is equal to 1.75 in. (44.45 mm).
To install the rack mount kit:
1.
Remove the panel door.
2.
Secure the kit to the rack with eight screws, ensuring
correct orientation, as shown in Figure 1.
1 / 16
P/N 3102033-ML • REV 01 • ISS 02JUL12
