- Page 1 Roller Shades MOTORIZED SHADE Simplicity Installation & Care Instructions 152140 J 1/13/2016...
-
Page 2: Getting Started
GETTING STARTED A few simple tools are required: - Measuring tape - Power drill, drill bits ⁄ ” Hex head and/or Phillips driver bit - Pencil PN: CS5002(W or BLK) CS5008 (W or BLK) CS5529 CS5530 Additional fasteners other than those Depends on size of PN: CS5402 PN: CS1101... - Page 3 OUTSIDE MOUNT The minimum mounting height for outside mounted shades is ” ” Make sure the brackets are level and aligned. Attach using two screws. Outside Mount Minimum 1” surface SPACER BLOCKS (OPTIONAL) ⁄ ” Each spacer block projects brackets away from mounting surface.
- Page 4 SHADES WITH NO HEAD RAIL The installation brackets are always mounted so that the Idler Side Bracket Motor Side bracket inner surfaces face each other. T-Hook Brackets must be in line and level. Shim brackets on inside mounts if necessary. The head rail must be level for the shade Foot to operate properly.
- Page 5 STEP 3: SHADE INSTALLATION SHADES WITH HEAD RAIL Center the shade in the window opening and push the head rail into the mounting brackets as shown. Push the rail back until it is fully engaged SHADES WITH NO HEAD RAIL Once the brackets are secured and level, the fabric roll can be inserted.
-
Page 6: Operation
STEP 4: CONNECT POWER SOURCE - BATTERY WAND/TRANSFORMER BATTERY WAND Plug the battery wand wire into the motor wire. TRANSFORMER Plug the transformer wire into the motor wire. Secure the wire behind the shade and along the window casing as required. - Page 7 ADJUST MOTOR LIMITS ON PRIMARY REMOTE (IF DESIRED) The lower and upper limits have been set at Channel the factory. If you need to make adjustments Display to the limits, follow the instructions below. Please Note: When clearing the factory set Stop limits, both the upper and lower limits will Down...
-
Page 8: Advanced Programming
ADVANCED PROGRAMMING REPLACE ORIGINAL REMOTE OR ADD ADDITIONAL REMOTE 1. Press the SETTING button on the motor until the shade jogs once. Release the button immediately after the first jog - this should be not more than 3 seconds. 2. Repeat this step for all shades that will be controlled by a Setting single channel. - Page 9 SKEW ADJUSTMENT (IF NECESSARY) If the shade does not raise evenly, first make sure the mounting brackets are mounted level with each other. If the shade is level and it still skews, operate the shade to the full down position. Prepare a strip of masking tape Place tape at this end approximately 5”...
-
Page 10: Cleaning And Care
SHADE REMOVAL If you need to remove your shade, follow the instructions below. Partially lower the shade and insert a flat head screwdriver as shown. Twist the screwdriver until the head rail disengages from the bracket. As you release the brackets, support the head rail to keep it from falling.
