Comfortex Somfy Installation & Care Instructions

Sheer horizontal motorized shading

Advertisement

Quick Links

Sheer Horizontal Shadings
MOTORIZED SHADING
Somfy
Installation & Care Instructions
152046 G
1/18/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Somfy and is the answer not in the manual?

Questions and answers

Jim
January 21, 2025

Pushing red button only jogs twice can’t precede with directions

1 comments:
Mr. Anderson
May 14, 2025

The Comfortex Somfy motor jogs twice when the red (PROGRAM) button is pushed because that action is used to pair or program the motor with a remote or channel. Jogging twice confirms the programming action, such as adding a new remote or changing settings.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Comfortex Somfy

  • Page 1 Sheer Horizontal Shadings MOTORIZED SHADING Somfy Installation & Care Instructions 152046 G 1/18/2016...
  • Page 2: Getting Started

    GETTING STARTED A few simple tools are required: - Measuring tape - Power drill, drill bits ⁄ ” Hex head and/or Phillips driver bit - Pencil PN: CS5402 PN: 20201012 PN: CS1000 PN: CS2000 PN: KIT9108 PN: CS5094 PN: CS5492 Additional fasteners other than those sent with your shading may be required depending on the mounting surface.
  • Page 3 STEP 2: SELECT YOUR BATTERY WAND MOUNTING LOCATION The position of the battery wand must be determined before installing the shade in the window. Make sure that the wire is long enough to reach from the battery wand to the motor (at the right end of the head rail). Extension wires are available if needed.
  • Page 4: Step 3: Bracket Installation

    STEP 3: BRACKET INSTALLATION Shadings are shipped with the required number of brackets Shading Width # of Brackets for proper installation. End brackets should be located Up to 40” approximately 3” from either end. Depending on the width >40” - 72” of the shading, additional brackets may be necessary, evenly >72”- 84”...
  • Page 5 EXTENSION BRACKETS (OPTIONAL) 2” Optional extension brackets are used to project the back of the ⁄ ” ⁄ ” shading up to 2 from the mounting surface. Attach the mounting bracket to the extension bracket with the nut and bolt provided. Outside Mount with Extension Brackets Minimum 2”...
  • Page 6 STEP 5: CONNECT POWER SOURCE - BATTERY WAND/TRANSFORMER BATTERY WAND Plug the battery wand cable into the motor cable. Note: Make sure that the motor cable will not interfere with the operation of the shading as this could cause damage to the shading. The cable may be secured with tape, but DO NOT staple.
  • Page 7: Operation

    OPERATION Operate your shading with the included Somfy Hand Held Transmitter, DecoFlex Wall Switch or Scroll Wheel Remote. Your remote has been programmed to control your shading. The upper and lower limits have been set and should not need to be adjusted. The intermediate position has also been set. If you are not satisfied with the pre-set positions of your shad- ing, you may adjust by following Advanced Programming steps A,B or C.
  • Page 8 ADJUSTING MOTOR LIMITS ADJUSTING YOUR SHADINGS PRE-SET LOWER POSITION with The pre-set lower limit of your sheer horizontal shading should allow your shading to go to the fully lowered position your vanes positioned horizontally (view through). Only adjust this lower position if the shading is not travelling to this location when the DOWN button is pressed and released.
  • Page 9: Setting Favorites

    SETTING FAVORITES The MY position of your Sheer horizontal Shading should bring your shading to the fully lowered position with the vanes closed for privacy mode. Only adjust this MY position if the shading is not travelling to this location when the MY button is pressed and released or if a different MY (favorite) position is desired.
  • Page 10: Creating A Group

    CREATING A GROUP Step 1: Identify the shadings you want to put in a group. Be sure that each shading is operated on its own remote (Telis 1) or on its own channel (Telis 4) and then identify the remote or channel that you want to be your group channel.
  • Page 11: Level The Bottom Rail (If Necessary)

    LEVEL THE BOTTOM RAIL (IF NECESSARY) If the fabric is moving to one side as the shading is raised (skewing), first check that the installation brackets are level. Shim to level, if necessary. If the brackets are level it may be necessary to adjust the bottom rail weight. To release the weight clip, insert a flat blade screwdriver into the weight clip and turn clockwise.
  • Page 12: Cleaning And Care

    SHADING REMOVAL Partially lower the shading and insert a flat head screwdriver as shown. Twist the screwdriver until the head rail disengages from the bracket. As you release the brackets, support the head rail to keep it from falling. CLEANING AND CARE The shading fabric is easy to care for.
  • Page 13 REPROGRAM FROM FACTORY SETTING Step 1: Using a paperclip, press and hold the PROGRAM BUTTON, located on the end of the motor casing (hole above motor and receiver wires) until shading jogs 3 times, then release button. All remotes and limits will be erased (motor is now set to factory mode).
