Maximum charging current:
To configure total charging
current for solar and utility
02 chargers.
(Max. charging current =
utility charging current +
solar charging current)
03 AC input voltage range
05 Battery type
Auto restart when overload
06
occurs
09 Output frequency
Maximum utility charging
current
Note: If setting value in
program 02 is smaller than
11
that in program in 11, the
inverter will apply charging
current from program 02 for
utility charger.
Setting voltage point back
to utility source when
12
selecting "SBU priority" or
"Solar first" in program 01.
Solar energy provides power to the
loads as first priority.
If solar energy is not sufficient to power
all connected loads, battery energy will
SBU priority
supply power to the loads at the same
time.
Utility provides power to the loads only
when battery voltage drops to either
low-level warning voltage or the setting
point in program 12.
10A
20A
40A
50A (default)
Wide (default) If selected, acceptable AC input voltage
range will be within 90-280VAC.
Narrow If selected, acceptable AC input voltage
range will be within 170-280VAC.
AGM(Default) Flooded
User-defined If "User-Defined" is selected, battery
charge voltage and low DC cut-off
voltage can be set up in program 26, 27
and 29.
Restart disable Restart enable
(default)
50Hz (default) 60Hz
10A 20A (default)
Available options in 1200VA model:
11.0V 11.3V
11.8V 12.0V
12.5V 12.8V
7
30A
11.5V (default)
12.3V
