SIMATIC Ident
RFID systems
Spacer for MDS D126 / D426
Compact Operating Instructions
The spacer is used for fast mounting of the transponders MDS D126 and MDS D426 on metal.
By using the spacer, the transponders can be replaced quickly and simply.
Spacer for
MDS D126 / D426
Ordering data
Table 1 Ordering data for MDS D126 / D426 spacer
Spacer
MDS D126 / D426
© Siemens Ⓟ2011
A5E03770490-01, 11/2011
Characteristics
Temperature range
Material
Color
Dimensions
Order number
6GT2690-0AL00
-25 °C ... +85 °C
PA 6.6 - GF30
black
59 mm x 30.5 mm (D x H)
1
Advertisement
Related Manuals for Siemens MDS D126
Summary of Contents for Siemens MDS D126
- Page 1 Spacer for MDS D126 / D426 Compact Operating Instructions The spacer is used for fast mounting of the transponders MDS D126 and MDS D426 on metal. By using the spacer, the transponders can be replaced quickly and simply. Spacer for...
- Page 2 Flush-mounting on metal = 25 mm = 50 mm Figure 2 Flush installation of the MDS D126 / D426 in metal with spacer Note on mounting/removing transponders Note the following points when mounting/removing transponders. ● Transponders must be mounted/removed at room temperature.
- Page 3 Technical specifications Table 2 Technical specifications MDS D126 / D426 spacer Distance between transporter and installation surface 25 mm Remounting cycles At least 10 Spacer ● Dimensions (D x H) ● 59 (±0.2) mm x 30.5 (±0.3) mm ● Color ●...
