Please read the following manual carefully before the first use and keep it for future reference.
Scuba diving is treated as an extreme sport and requires proper training and certification. Using scuba
equipment, ACCU 12V 18Ah included, by an untrained and inexperienced person without proper certification
may cause health damage and even risk of death.
Tech specification
The set includes:
- 1 x ACCU 12V 18Ah
- 1 x dedicated charger
- 1 x RCA port cap
Technical details:
- 12V
- 18Ah
- Li-Ion 12V battery pack
- max power consumption from both ports: 200W
Purpose of use
ACCU 12V 18Ah is dedicated for underwater heating systems with max voltage 12V using compatible connection system
through E/O cord and for compatible underwater light heads equipped with light-for-me RCA or E/O (through additional
light-for-me RCA-E/O cord) connection. Make sure the used heating system and/or underwater light head are compatible
before connecting them to ACCU 12V 18Ah. The manufacturer does not take any liability for any damage caused by
connecting ACCU 12V 18Ah to incompatible heating system and/or underwater light head.
Charging
ACCU 12V 18Ah is equipped with two RCA ports marked as DIRECT (direct connection to the battery pack) and SWITCH
(connected to the battery pack through a switch).
!
!
Charging is done through the DIRECT port only. Connecting charger
to the SWITCH port can cause battery pack damage.
Prior to starting the charging process make sure that ACCU 12V 18Ah is dry. Then disconnect the device connected to the
DIRECT RCA port or unscrew the cap and dry this port as well with a clean tissue.
Make sure the ACCU's switch is in OFF position - it must stay OFF throughout the whole charging process. Use only the
charger provided with the set. Before plugging the charger in, check its condition thoroughly; in case of noticing any
mechanical damage to the charger, cut or broken cable or any other fault which may influence its proper work, do not use
the charger.
In order to start the charging process plug the charger's RCA connector into the DIRECT port, then plug the charger to the
mains. The charger will go through a self-test (power red diode on, all 4 green diodes flash one by one) and then will start
the charging process, which is indicated by green diodes flashing. Each solid green diode indicates 25% charge of the
battery pack. The charging process is finished when all the four green diodes are on. Unplug the charger from the mains
LIGHT FOR ME
user's manual
ACCU 12V 18Ah
1/4
Advertisement
Related Manuals for Light-For-Me ACCU 12V 18Ah
Summary of Contents for Light-For-Me ACCU 12V 18Ah
- Page 1 SWITCH port can cause battery pack damage. Prior to starting the charging process make sure that ACCU 12V 18Ah is dry. Then disconnect the device connected to the DIRECT RCA port or unscrew the cap and dry this port as well with a clean tissue.
- Page 2 fixed / serviced by an authorised service point before next dive. The ACCU 12V 18Ah should be stored in a dry room with its battery pack charged. The ACCU should not be left for a longer time with low charge level of its battery pack.
- Page 3 Burn times Burn times of ACCU 12V 18Ah depends on the total power drawn by the connected devices. The maximum power that can be drawn from both ports is 200W. The below table shows max burn times of ACCU 12V 18Ah with Santi™ heating systems and underwater light heads LIGHT-FOR-ME.
- Page 4 Troubleshooting Problem Solution Charge the ACCU according to the manual. Make sure the heating system / Switch is on ON position, the underwater light head are connected to the proper RCA port. Check the heating system / light head condition of connected device - if necessary contact its manufacturer. If all is does not work.
