HH Electronics Vector VRC-210 User Manual

Full range enclosures with a detachable mixer
Hide thumbs
Table of Contents

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

FULL RANGE ENCLOSURES
WITH A DETACHABLE MIXER
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vector VRC-210 and is the answer not in the manual?

Questions and answers

Related Manuals for HH Electronics Vector VRC-210

Summary of Contents for HH Electronics Vector VRC-210

  • Page 1 FULL RANGE ENCLOSURES WITH A DETACHABLE MIXER USER MANUAL...
  • Page 2 PEAK PEAK SUPPLY VOLTAGE AND FUSE RATING: 220-240V~ 50/60Hz T3.15A L 250V MAXIMUM POWER CONSUMPTION - 500 WATTS LEVEL LEVEL LEVEL LEVEL LEVEL MASTER VOLUME © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 3: Power And Speaker Connections

    MAXIMUM POWER CONSUMPTION - 300 WATTS Only replace the fuse with the type stated! Always switch off and disconnect the power cord when not in use. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 4: User Interface

    18. LIMITER LED: This will illuminate when the Limiter is active. The limiter will protect the output stage from potential overload. 19. POWER LED: This will illuminate when the unit is powered up. 20. MASTER VOLUME: Controls the overall level of your VRC-210 system. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 5: Media Player

    Only one VRC-210 can be paired to your Bluetooth capable device at once, so remember to de-select if you plan to use a different VRC-210 device next time. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 6 BASS BASS BASS LIMITER SIGNAL LH SPEAKER EFFECT EFFECT EFFECT EFFECT DOWN SELECT POWER PEAK PEAK PEAK PEAK LEVEL LEVEL LEVEL LEVEL LEVEL MASTER VOLUME © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 7 BASS BASS BASS LIMITER SIGNAL EFFECT EFFECT EFFECT EFFECT DOWN SELECT POWER PEAK PEAK PEAK PEAK LH SPEAKER LEVEL LEVEL LEVEL LEVEL LEVEL MASTER VOLUME © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 8: Specification

    21.9" x 25" x 14.4" , 0.129 M3 Packed weight : 19.7Kg, 43.4 lbs In the interest of continued development, HH Electronics reserves the right to amend product specification without prior notification. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 9: Block Diagram

    6.35MM UNBALANCED JACK 3.5MM STEREO JACK MALE MALE FEMALE FEMALE 1 GROUND 2 HOT 3 COLD (FRONT VIEW) (FRONT VIEW) (REAR VIEW) (REAR VIEW) +(HOT) RIGHT LEFT © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 10: Hints And Tips

    Be aware of total power usage. Overloading a mains socket is potentially dangerous, Ÿ and likely to cause a power out during use. Keep power and signal cables apart. Ÿ © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 11 TRANSLATIONS © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 12 Ne remplacez le fusible que par le modèle spécifié! MAXIMUM POWER CONSUMPTION - 300 WATTS Veuillez toujours arrêter l'appareil et débrancher le câble d'alimentation lorsque vous ne l'utilisez pas. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 13: Panneau De Commande

    20. MASTER VOLUME: Contrôle le volume général de votre système VRC-210. © 2019 HH Electronics Ltd © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD. Designed and Engineered in the UK by HH Electronics LTD.

  • Page 14: Lecteur Audio

    Seul un VRC-210 peut être appairé avec votre appareil BlueTooth à la fois. Veuillez le désélectionner si vous pensez utiliser un VRC-210 différent la fois suivante. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 15 MAXIMUM POWER CONSUMPTION - 300 WATTS con las mismas especificaciones! ¡Solamente remplazar el fusible por o con las mismas especificaciones! Siempre apague y retire el cable cuando no en uso. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 16: Panel De Control

    19. Indicador POWER: Este indicador LED se ilumina para indicar que la unidad esta encendida. 20. Control MASTER VOLUME: Controla el volume general de tu Sistema VRC-210. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 17: Reproductor De Medios

    Solamente un sistema VRC-210 puede ser apareado al mismo tiempo con su dispositivo Bluetooth. Entonces no se olvide de desparear si planea usar otra fuente. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 18 Somente substitua o fusível por outro MAXIMUM POWER CONSUMPTION - 300 WATTS das mesmas especificações. Sempre apague e retire o cabo de força quando não em uso. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.

  • Page 19: Painel De Controle

    19. Indicador POWER: Este indicador LED se ilumina para indicar que a unidade está ligada. 20. Controle MASTER VOLUME: Controla o volume geral de seu sistema VRC-210. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 20 Apenas um sistema VRC-210 pode ser pareado ao mesmo tempo com seu dispositivo Bluetooth. Então não se esqueça de desparear se planeja usar outra fonte no mesmo. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 21 Ersetzen Sie nur die Sicherung durch den angegebenen Typ! MAXIMUM POWER CONSUMPTION - 300 WATTS verwendet wird. Schalten Sie das Netzkabel immer aus und trennen Sie es, wenn es nicht © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 22 18. LIMITER LED: Dies leuchtet, wenn der Limiter aktiv ist. Der Limiter schützt die Ausgabestufe vor einer möglichen Überlastung. 19. POWER LED: Dies leuchtet, wenn das Gerät eingeschaltet ist. 20. MASTER VOLUME: Steuert das Gesamtniveau Ihres VRC-210-Systems. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 23 Ihr HH Vector ist jetzt mit Ihrem Bluetooth-Gerät verbunden und kann über die PLAY/PAUSE, PREVIOUS, NEXT & LOOP BUTTONS gesteuert werden. Nur ein VRC-210 kann gleichzeitig mit Ihrem Bluetooth-fähigen Gerät gekoppelt werden. © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 24 MAXIMUM POWER CONSUMPTION - 300 WATTS 只能使用指定类型的保险丝！ 100~110V电压选择 不使用时，请务必关闭电源并断开电源线。 SUPPLY VOLTAGE AND FUSE RATING: 100-110V~ 50/60Hz T3.15A L 250V MAXIMUM POWER CONSUMPTION - 300 WATTS © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 25 13. FX处理器：包含16种高质量效果，此处理器为您的信号链增添了专业感。使用DOWN / UP按 钮选择所需的效果，然后使用SELECT按钮确认。 14.主FX电平：此控件允许快速整体调整FX电平，而不必单独调整输入FX发送的控件（8）。 15. MIX OUT：提供将VRC-210连接到其他设备（例如附加的放大器/扬声器设置或录音设备）的 便捷方法。 16.幻象电源：需要时，打开所有麦克风通道的幻象电源。请注意，幻象只能应用于复合口输入 的XLR接口。 幻象电源只能与电容话筒一起使用。 17. MASTER EQ：2频段有源EQ，用于调节频率信号。将两个控件都设置为0是一个很好的开始。 18. LIMITER LED：当Limiter启用时，该灯将点亮。限幅器将保护输出级免受潜在的过载。 19. POWER LED：当设备通电时，该灯点亮。 20. MASTER VOLUME：控制VRC-210系统的整体音量。 © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 26 微型SD卡，USB记忆棒-插入后会⾃动检测-如果在已经连接USB记忆棒的情况下插入微型SD卡，则微 型SD卡将成为“实时”⾳频源。 5.上⼀个：按下以跳到上⼀首曲⽬。 6.下⼀个：按此按钮跳到下⼀⾸曲⽬。 7. LOOP：使⽤此选项可以启⽤/禁⽤循环播放模式。当将此按钮与SD卡或USB记忆棒⼀起使⽤时， 有3个选项： ALL-按⽇期顺序播放设备根⽬录上的所有曲⽬，然后播放⼦文件夹。 ONE-重复播放⼀个曲⽬（使⽤NEXT按钮（8） ）循环播放到所需的曲⽬。 FOD-播放当前活动文件夹中的所有曲⽬。 8.播放/暂停：使⽤此控件可以播放或暂停⾳乐。 连接到外部蓝牙设备： A .通过MODE按钮（4）选择Bluetooth。 B .在⽀持蓝牙的设备上，确保启⽤了蓝牙。向下浏览可⽤设备列表-搜索：“ HH VECTOR”并选 择。⽆需密码。 C .如果设备现在已连接到蓝牙设备，就可以使⽤“播放/暂停”，“上⼀个”，“下⼀个”和“循 环”按钮进⾏控制。 ⼀次只能将⼀个VRC-210与⽀持蓝牙的设备配对，因此，如果您下次打算使⽤其他VRC-210设备，请 记住取消选择。 © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 27 © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 28 © 2019 HH Electronics Ltd Designed and Engineered in the UK by HH Electronics LTD.
  • Page 29 hhelectronics hhelectronics Model number: hhelectronics Serial number: Place of purchase: Date of purchase: www.hhelectronics.com REVISION 1.00...
