Summary of Contents for Helmholz 700-158-3DP02
- Page 1 Quick Start Guide DP/PN Coupler (V2) Version as of FW 2.00 www.helmholz.com...
-
Page 2: Table Of Contents
Contents 1. Safety instructions 2. Introduction 3. Function of the DP/PN Coupler 4. Connection 5. Install GSD/GSDML file 6. Project planning of the PROFIBUS side 7. Project planning of the PROFINET side 8. Web interface of the DP/PN Coupler 9. LED status information 10. -
Page 3: Introduction
2. Introduction This document explains the initial commissioning of the DP/PN Coupler (700-158-3DP02, V2). SCAN QR CODE Further information can be found in the manual. You can find this at www.helmholz.com or scan the QR code directly. TO GET DP/PN Coupler... -
Page 4: Connection
4. Connection The RJ45 “X1 P1” and “X1 P2” socket is for the connection of the PROFINET network. Note: The housing has no connection to earth. Please connect the funcitional earth DP/PN Coupler Terminal (FE) correctly with the reference potential. The sub-D socket is for the connection of the PROFIBUS network. -
Page 5: Install Gsd/Gsdml File
5. Install GSD/GSDML file Please download the GSD and GSDML files from www.helmholz.com or scan the QR code. SCAN QR CODE For the PROFIBUS side, the GSD file (“HELM1130.gsd”), for the PROFINET side, the GSDML file (“GSDML-V2.34-Helmholz-DP-PN-coupler-______.xml”) is required. TO GET... - Page 6 The DP/PN Coupler can be found in the hardware catalog under “Other field devices -> PROFIBUS-DP -> Gateway -> HELMHOLZ -> DP/PN Coupler V2”. Connect the PROFIBUS network of the PROFIBUS CPU with the DP/PN Coupler.
- Page 7 6.3 Parameters of the PROFIBUS side Data validity diagnosis: Sending a diagnostic message to the PLC if the data is Diagnostic failure PS1/PS2: Send a diagnostic message to the PLC if the power not valid. supply fails at PS1 (left side) or PS2 (right side). Data validity display DIA: The validity of the data is displayed in the least significant bit (bit 0) of the first input byte.
-
Page 8: Project Planning Of The Profinet Side
7. Project planning of the PROFINET side The DP/PN Coupler can be found in the hardware catalog under “Other field devices -> PROFINET IO -> Gateway -> Helmholz GmbH & Co. KG -> Helmholz DP/PN Coupler”. Select the entry “DP/PN Coupler V2“. - Page 9 7.1 Parameters of the PROFINET side Diagnostic PS1/PS2 failure: Sending of a diagnostic message to the PLC in the event Diagnostic data validity: Sending of a diagnostic message to the PLC when the of a power supply failure to PS1 (left side) or PS2 (right side). data is not valid.
- Page 10 The MAC address of the device can be found on the device front of the DP/PN coupler. The Helmholz IPSet tool, which can be downloaded at no charge from the Hemholz website, can also be used to set the PROFINET name.
-
Page 11: Web Interface Of The Dp/Pn Coupler
The web interface of the DP/PN coupler provides an overview of the status and the configuration of the device, as well as the possibility to perform a firmware update. Please download the current firmware from www.helmholz.com or scan the QR code. SCAN... -
Page 12: Led Status Information
9. LED status information PB (PROFIBUS) PN (PROFINET) SF (red) Configuration correct Configuration correct There is no configuration, the PROFINET configuration does not There is no configuration, the PROFIBUS configuration does not agree with agree with the PROFIBUS configuration, or a diagnosis exists. the PROFINET configuration, or a diagnosis exists. -
Page 13: Technical Data
10. Technical data Order no. 700-158-3DP02 Article name DP/PN Coupler Scope of delivery DP/PN Coupler, Quick Start Guide PROFINET interface - Protocol PROFINET IO Device as defined in IEC 61158-6-10 - Transmission rate 100 Mbps full duplex - Number of configurable slots... - Page 14 Quick Start Guide DP/PN Coupler...
- Page 15 Quick Start Guide DP/PN Coupler...
- Page 16 Our customers are at the center of everything we do. We welcome all ideas and suggestions. Helmholz GmbH & Co. KG | Hannberger Weg 2 | 91091 Großenseebach | Germany | Phone +49 9135 7380-0 | Fax +49 9135 7380-110 | info@helmholz.de | www.helmholz.com...
