Page 1: Parts List
1UP USA SPORTUBE BRACKET SERIES 1 & SERIES 2 Parts List 1) U-Bracket Assembly 4) 5/16-18 Fastener 2) Post Assembly 5) Post Lock 3) Bottom Clamp 6) Tensioning Handle In The Box: • Two SporTube Brackets • Hardware Bag... -
Page 2: Installation Instructions
Installation Instructions Step 1: • Position the Post Assembly so the two 5/16-18 Fasteners are on each side of the Cross Bars • Using the included Allen key, tighten the Bottom Clamp and Post Assembly together o Be sure that the metal side faces down •... - Page 3 Step 3: • Slide the U-Bracket Assembly onto Post Assembly. Step 4: • Slide Post Lock through the holes found on the Post Assembly and U-Bracket Assembly and tighten Post Lock into place. • Using Tensioning Handle, tighten U-Bracket Assembly down over the SporTube. •...
- Page 4 Do not use a Series 2 SporTube Bracket on Series 1 SporTube. Manufactured by: Together, we’ll do epic things. 1up USA.com LLC | 1005 Commerical Drive | Dickeyville, WI 53808 Ph 608.568.7261 | email@1up-usa.com Questions or comments? Contact our support team via email at email@1up-usa.com...
