- Page 1 EGE-UHDAUD-AMP Integrated Zone Amplifier with HDBaseT Capability...
- Page 3 E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use.
- Page 4 E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: •...
-
Page 5: Table Of Contents
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability CONTENTS 1. Introduction .............1 2. Applications ............1 3. Package Contents ..........1 4. System Requirements ..........1 5. Features..............2 6. Operation Controls and Functions .......3 6.1 Front Panel ............3 6.2 Rear Panel............4 6.3 RS-232 Pin Assignment........5... -
Page 6: Introduction
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 1. INTRODUCTION The HDBaseT 4K UHD with Digital Presentation Amplifier can accept analog and digital audio from 3.5Ø line in, L/R RCA, HDMI, optical and coaxial inputs and output synchronously to L/R speaker, HDMI and HDMI over CAT5e/6/7 Receiver. -
Page 7: Features
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 5. FEATURES • Supports Digital to Analog audio Conversion (DAC) and Analog to • Digital audio Conversion(ADC) • Supports input sampling rate up to 96kHz and output at 48kHz •... -
Page 8: Operation Controls And Functions
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel SERVICE MENU EXIT POWER HDBaseT™ 4K UHD with Digital Presentation Amplifier Service: Connect with USB flash driver for firmware update only. OLED: Display current input source selection and volume setting. -
Page 9: Rear Panel
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.2 Rear Panel RS-232 LINE IN IR IN IR OUT COAX. RCA IN CAT5e/6/7 OUT CAT5e/6/7 IN AUDIO-CAT HDMI OUT HDMI IN DC 24V OPT. -
Page 10: Rs-232 Pin Assignment
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.3 RS-232 Pin Assignment Remote Control Assignment Assignment Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1... -
Page 11: Ir Cable Pin Assignment
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.4 IR Cable Pin Assignment IR Blaster Power IR Blaster Signal IR Receiver IR Signal Power Grounding... -
Page 12: Remote Control
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.5. Remote Control Power: Press this button to turn on the device or to set it to standby mode. MENU Vol +/-: Press these buttons to adjust the volume. -
Page 13: Oled Menu
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.6 OLED Menu Audio In Display Set IP Config Function Select Reset to Default EDID Mode Video Set Line IN RCA IN Optical Audio Select... -
Page 14: Telnet & Rs-232 Command
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.7 Telnet & RS-232 Command Command Description Parameter DISPLAY LIST OF COMMANDS, CODE ENTRY IS CASE SENSITIVE DISPLAY LIST OF COMMANDS, CODE HELP ENTRY IS CASE... - Page 15 E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability Command Description Parameter SET THE GATEWAY SGATEWAY ADDRES SET THE HTTP SHTTPPORT [1-65535] [80] COMMUNICATION PORT SET THE TELNET STELNETPORT [1-65535] [23] COMMUNICATION PORT Note:...
-
Page 16: Telnet Control
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.8 Telnet Control To access the telnet control under MS windows, click ‘Start’ menu and type “cmd” in the search field then press enter. Under Mac OS X, go to Go Application Utilities... - Page 17 E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability Press “Help” or “?” then hit enter to bring up all available commands. Note: Any commands will not be executed unless followed by a carriage return.
-
Page 18: Webgui Control
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 6.9 WebGUI Control On a PC/Laptop that is connected to an active network system, open a web browser and type device’s IP address (available from LCM monitor) on the web address entry bar. -
Page 19: Connection Diagram
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 7. CONNECTION DIAGRAM Display RS-232 Equipped PC or Notebook 60° 60° 1.5m 1.5m DVD or Blu-ray Player RS-232 Equipped 60° 60°... -
Page 20: Specifications
E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability 8. SPECIFICATIONS Video Bandwidth 300MHz/9Gbps Ethernet Speed 100Mbps Input ports 1x HDMI, 1xCAT5e/6/7, 1 x Optical, 1 x Coaxial, 1 x 3.5Ø Line in, 1 x R/L RCA, 1 x D-Sub 9pin (RS-232), 1 x RJ-45 (LAN), 1 x Keypad, 1 x IR, 1 x AUDIO-CAT Output ports... - Page 21 E G E - U H D A U D - A M P Integrated Zone Amplifier with HDBaseT Capability Amplifier Performance: • 2 X 45 W @4Ohm < 0.5% THD+N • 2 X 25 W @8Ohm < 0.5% THD+N •...
