- Page 1 EGE-CMP-442 4x2 Component Video Matrix...
-
Page 3: Table Of Contents
EGE-CMP-442 4x2 Component Video Matrix CONTENTS 1. Introduction ..................................2. Features 3. Package Contents ............... 4. Operation Controls and Functions ..........4.1 Front Panel ................................4.2 Rear Panel ............... 4.3 Remote Control 4.4 RS-232 Protocol ..............4.4.1 Pin Definition .............. -
Page 4: Introduction
4x2 Component Video Matrix 1. Introduction EGE-CMP-442 is a high performance Component + L/R Audio Matrix with remote control. It offers you maximum convenience in HDTV audio/video signal distribution when you have multiple sources and displays to connect together. Each of the four HDTV audio/video sources can be directed to any one of the two outputs, so two displays can show 2 identical or 2 different sources at the same time. -
Page 5: Operation Controls And Functions
EGE-CMP-442 4x2 Component Video Matrix 4. Operation Controls and Functions 4.1. Front Panel Remote control sensor. Power Switch & LED Indicator: The LED will illuminate when the power is turned on. Input Select/Indicators for Output A: Press the "OUT A" button repeatedly to switch to your desired source. One of the four LEDs will illuminate to indicate which input source is being selected, and routed to the display. -
Page 6: Remote Control
EGE-CMP-442 4x2 Component Video Matrix 4.3 Remote Conltrol Power: Press the button to turn on/off the unit. Input Select for Component/Audio OUT A: Press 1, 2, 3 or 4 to select the desired input source for Component/Audio OUT A. Input Select for Component/Audio OUT B: Press 1, 2, 3 or 4 to select the desired input source for Component/Audio OUT B. -
Page 7: Commands
EGE-CMP-442 4x2 Component Video Matrix CONNECTING AND OPERATING 4.4.2. Commands 1) Connect the HDMI input source (such as HD-DVD/ PS3 /STB etc.) into transmitter over HDMI cable. COMMAND ACTION 2) Connect the output of transmitter and input of receiver over CAT5E or CAT6 cable. -
Page 8: Connection And Installation
EGE-CMP-442 4x2 Component Video Matrix 6. Connection and Installation... - Page 9 EGE-CMP-442 4x2 Component Video Matrix Cypress Matrix Series: Product Description CHMX-22 2x2 HDMI Matrix CHMX-24 2x4 HDMI Matrix CHMX-42 4x2 HDMI Matrix CHMX-44 4x4 HDMI Matrix CHMX-22AS 2x2 HDMI Matrix CCMX-42 4x2 Component Matrix w/audio CCMX-44 4x4 Component Matrix w/audio...
- Page 10 www.egerate-store.com...
