Bradley Terreon TDB3108 Installation Manual

54" circular deep bowl washfountain with touchtime control. extra height 54" circular classic washfountain with 9" deep bowl and touchtime control
Hide thumbs Also See for Terreon TDB3108:
Table of Contents

Advertisement

Quick Links

Download this manual
TDB3108 with
TouchTime
Control
®
TDB3108 Juvenile Height with
TouchTime
Control
®
TDB3108 TAS Height with
TouchTime
Control
®
WF3208 with
TouchTime
215-1577 Rev. B; ECN 13-00-001
© 2013 Bradley
Page 1 of 19
4/3/2013
Control
®
Installation
TDB3108
Terreon
54" Circular Deep Bowl
®
Washfountain with TouchTime
Control
WF3208
Terreon
Extra Height 54" Circular
®
Classic Washfountain with 9"
Deep Bowl and TouchTime
Control

Table of Contents

Pre-Installation Information ....................................... 2
Circular Washfountain Dimensions ....................... 3-4
Rough-In Information ................................................. 5
Installing the Drain ..................................................... 5
Bowl/Pedestal Mounting and Assembly ..................... 6
Installing Drain Spud in Bowl ..................................... 7
TouchTime
Assembly ......................................... 8-11
®
Valve and Tubing Connections ................................. 12
Electrical Connections ............................................. 13
Water Supply and Adjust Temperature ..................... 13
Cleaning and Maintenance ................................ 14-15
Soap Valve Parts List ............................................... 16
Valve Assemblies ..................................................... 18
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1.800.BRADLEY
bradleycorp.com
®
®
Fax: 262.253.4161

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Terreon TDB3108 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bradley Terreon TDB3108

Summary of Contents for Bradley Terreon TDB3108

  • Page 1: Table Of Contents

    Sprayhead Parts List and Troubleshooting ....17 Valve Assemblies ............. 18 Vernatherm Parts List and Troubleshooting ..... 19 215-1577 Rev. B; ECN 13-00-001 P.O. Box 309, Menomonee Falls, WI 53052-0309 © 2013 Bradley Phone: 1.800.BRADLEY Fax: 262.253.4161 Page 1 of 19 4/3/2013...

  • Page 2: Pre-Installation Information

    • 1-1/2" vent or tie pipe on types vented through washfountain column (see Step 1 for lengths required) • 110 VAC GFI power source for 110/24 VAC UL Class II transformer supplied • OPTIONAL: Bradley recommends installing an electrical cutoff switch to the unit. This feature allows no accidental water delivery during regular maintenance and service.

  • Page 3: Circular Washfountain Dimensions

    23-1/2"* 30"* (597) 10"* (762) (254) 51-1/4"* (1303) 23-1/2"* 39-1/8"* 19-1/2" (597) (994) (495) 35-1/2" (902) 19-1/2" (495) 35-1/2" (902) * Add 2" (51) for TAS height unit 54" (1372) Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...
  • Page 4 (864) 47-1/4" (1200) 23-1/2" (597) 55-3/4" 34" (1416) (864) 10" (254) 19-1/2" 43-3/4" (495) 23-1/2" (1111) (597) 37-1/2" (953) Model TDB3208 is not ADA Compliant 19-1/2" (495) 37-1/2" (953) 54" (1372) Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 5: Rough-In Information

    Washfountain Assemble the drain to the dimension for the bowl size of the washfountain 4" you are installing. (102) 4" (102) Types A, O with Tie Pipe Bracket Option Types B, H Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 6: Bowl/Pedestal Mounting And Assembly

    Drain 1/4" Washers and Wing Nuts (4) Places Mate thread rods with slotted holes in pedestal using locator ribs. Using 1/4" wing nuts and washers, secure bowl to pedestal in four places. Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 7: Installing Drain Spud In Bowl

    Tighten the spud and lock nut against the bowl. Bowl Secure the strainer to drain spud with the Washer (142-068) screws provided. Locknut (161-021) Connect spud (or B Trap or Tie Pipe Bracket) to drain. Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 8: Assembly

    Deep Bowl ® (S45-055) (Part No. Varies with color of bowl. Contact your local Bradley Rep for assistance) 1/2" Supply Tube Access Panel Pedestal Assembly (186-1456) (S17-242) Valve Assembly (S50-368) (A shown) Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...
  • Page 9 (S83-179) supply lines (pass them through holes in cover down through support column) and connect to Tie Bar stops using suitable fittings. Standard Support Tube (S57-005) Sprayhead TAS/Juvenile Support Tube (S05-054) (S57-006) Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...
  • Page 10 Terreon Deep Bowl ® Vented Trap (Part No. Varies with color of bowl. (111-024) Contact your local Bradley Rep for assistance) Access Panel (186-1191) Pedestal Assembly (S17-242) Valve Assembly (S50-368) (B shown) Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...
  • Page 11 FOR B UNIT: Install 1/2" nominal copper supply Assembly (S83-179) lines (pass through holes in cover and through support column) and connect supply lines to stops using suitable fittings. Support Tube Sprayhead Standard (S57-005) (S05-054) TAS/Juv (S57-006) Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 12: Valve And Tubing Connections

    Attach flexible hose to thermostatic mixing valve, two places. Insert the filter washers (provided) into the swivel nut at the end of the supply Volume Control hoses and connect to the stop/check Valve valves. S02-045 Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 13: Electrical Connections

    Clean sprayhead if necessary. Adjust the volume control to control the flow of water. Thermostatic Mixing Valve Assembly Attach pedestal access panel and kick plate with hardware provided. Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...
  • Page 14 Soap thickness is determined by a measurement called viscosity. Soap viscosity should be between 100 cps (centerpoise) and 2500 cps for all Bradley soap dispensers. Thinner soaps are perceived by the users as being “watered down” so users tend to take more than they need, resulting in waste.

  • Page 15: Cleaning And Maintenance

    Solid Surface cleaner and polish to refresh and protect the Terreon Solid Surface material. ® Bradley recommends additional care and maintenance for the darker colored Terreon, for complete instructions on this additional maintenance see Bradley document #1505. Do not use strong acid or alkaline chemicals and cleansers to clean Terreon. If theses chemicals come in contact with the Terreon surface wipe them off immediately and rinse with soapy water.

  • Page 16: Soap Valve Parts List

    If none is present, it will be necessary to drill out the bearing hole with a 1/2" or 5/8" drill. The plastic container Soap Valve - Powdered S09-010A configuration forms a natural template for locating the bearing hole. Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 17: Sprayhead Parts List And Troubleshooting

    3. The voltage reading should indicate 24 VAC ± 10%. If you are unable to obtain a proper voltage reading, the transformer is not working properly and needs to be replaced. Contact your Bradley representative to order a replacement transformer.

  • Page 18: Valve Assemblies

    — 118-033 Valve Body — — 124-001BD Fiber Washer 125-001BC O-Ring 1-1/6 - 14 NPT 119-060 Valve Core 152-038 Roll Pin 121-016 Bonnet — 121-016A Bonnet — — 1/2 - 14 NPT Bradley • 215-1577 Rev. B; ECN 13-00-001 4/3/2013...

  • Page 19: Vernatherm Parts List And Troubleshooting

    Cause Solution Limited water flow Dirt and debris Remove and clean strainer. If strainer needs to be replaced, order Bradley part no. 173-028. have built up in the Check the piston for smooth movement. valve or strainer. 1. Remove the valve’s cap and thermostat.
