Elkay LJNED10 2AQ Series Installation, Care & Use Manual

Installation/Care/Use Manual
Fully-Recessed Barrier-Free Water Cooler
Note: Danger! Electric shock hazard. Disconnect power before servicing unit.
Installer
To assure you install this model easily and correctly, PLEASE READ THESE
SIMPLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK
YOUR INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL
AND OTHER APPLICABLE CODES. After installation, leave these instructions
inside the fountain for future reference.
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER
LINES IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY
FROM THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN,
CREATING AN ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL
CONTENT OF THE WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS
INDICATED. ANY DRAIN FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO
ELECTRICALLY ISOLATE THE FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
OPERATION OF QUICK CONNECT FITTINGS
OPERATION OF QUICK CONNECT FITTINGS
SIMPLY PUSH IN SIMPLY PUSH IN TUBE IS SECURED TUBE IS SECURED
TUBE TO ATTACH
TUBE TO ATTACH
A A B B
LJNED10_2AQ
USES HFC-134A REFRIGERANT
IMPORTANT
PUSH IN COLLET
PUSH IN COLLET
IN POSITION
TO RELEASE TUBE
IN POSITION TO RELEASE TUBE
C C
PUSHING TUBE IN BEFORE
PUSHING TUBE IN BEFORE
PULLING IT OUT HELPS TO
PULLING IT OUT HELPS TO
RELEASE TUBE
RELEASE TUBE
BASIN
FIG. 1
PAGE 1
19
FIG. 2
1000002311 (Rev. D - 05/16)
