- Page 1 LED LCD TV OWNER' S MANUAL MODEL: LE50K6500DUA LE55Q6500DUA L E 5 8 K 6 5 0 0 D U A LE65K6500DUA Please READ this manual carefully before operating your TV, and retain it for future reference...
-
Page 2: Table Of Contents
Contents 1. Safety and warnings..............2-3 2. Introduction................4 3. Base stand assembly..............5 4. Wall Mount Installation............6 5. Installation................7-10 6. Remote Control..............11 7. Operation................12-18 8. APP Store................19-27 8.1 Start Up................19 8.2 Top.................. 19 8.3 Apps.................20 8.4 Free Apps detail page............ -
Page 3: Safety And Warnings
SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTION 1) Read these instructions. CAUTION 2) Keep these instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN! 3) Heed all warnings. CAUTION 4) Follow all instructions. TO REDUCE THE RISK OF ELECTRIC SHOCK, DO 5) Do not use this apparatus near water. NOT REMOVE COVER (OR BACK).NO USER 6) Clean only with dry cloth. - Page 4 SAFETY AND WARNINGS High voltages are used in the operation of this television Never stand on, lean on, or suddenly push the television or receiver. Do not remove the cabinet back from your set. its stand. You should pay special attention to children. Refer servicing to qualified service personnel.
-
Page 5: Introduction
INTRODUCTION Accessories Main features ① Used as Television, display terminal, PC display； Infrared Remote Controller....1 ② High luminance, wide viewing angle； Battery(AAA)........2 ③ Can store Air and Cable TV programs； ④ HDMI interface； User’ s M anual.......1 ⑤ Multi-Media player (USB); Main parameter Viewing Picture Size (Diagonal) 50 inch... -
Page 6: Base Stand Assembly
BASE STAND ASSEMBLY 1. Place the TV with the display side down on a flat surface. Use a cloth to protect the display. Locate the 2PCS of bottom bracket into the gap in the bottom of the TV. 2. Lock 4PCS screws below and check each screw is firmly tightened. M4X14MM(50",58"65") M6X18MM(55") Note: This stand is not a swivel stand. -
Page 7: Wall Mount Installation
WALL MOUNT INSTALLATION Step One: Use the expansion bolts( 4*36PWA ) to fix the wall mount brackets into the wall. wall Step Two: Fix the wall mount screws (M6x12mm/4pcs) into the rear side of the LCD TV,using the tongue of 8kgf.cm. -
Page 8: Installation
INSTALLATION INSTALLATION Front panel 1: Remote control sensor. 2: Indicator LED: RED STANDBY. 3: Key board ≤8m Bottom Navigation menu 10LA TV Status Middle key Pull Up/Down Pull Left/Right On analog and digital TV, the channel In the absence of audio playback state, No dispaly in TV Open the navigation menu can be switched on and off. - Page 9 INSTALLATION ANTENNA Note: Aerial connections: F(male). Input impendance: 75 unbalanced. STEPS: Be sure both the TV and computer are set to Power off. 1.Connect VGA and audio cable. 2.Connect the power cord. 3.Power on the TV, switch to PC mode. 4.Power on the PC.
- Page 10 INSTALLATION PRESET MODE (PC) V.Freq.(Hz) H.Freq.(KHz) RESOLUTION 800*600 37.88 1024*768 48.36 1360*768 47.7 1280*768 47.3 1920*1080 67.5 NOTE: PC V.Freq.(Hz) not more than 60Hz. PRESET MODE (HDMI) V.Freq.(Hz) H.Freq.(KHz) RESOLUTION 800*600 37.88 1024*768 48.36 47.7 1360*768 1280*768 47.3 1920*1080 67.5 3840*2160 67.5 3840*2160...
- Page 11 INSTALLATION AV EQUIPMENT This TV provides group of AV ,one group of YPbPr for convenient connection to VCR, DVD or other video equipment. Please refer to the owner's manual of the equipment to be connected as well. You can use the input terminals on TV set rear as follows. YPbPr AV1 IN PC AUDIO...
-
Page 12: Remote Control
REMOTE CONTROLLER Press to open the first app of your favorite apps. Fav.APP ( Please customize your favorite apps first.) Press to turn the sound on or off. (Mute) Press to open the shortcut menu of tool. TOOL Press to adjust the volume level. VOL +/- Press to display the channel information. -
Page 13: Operation
TV OPERATION Basic Operation Power supply to switch on/off this Unit. Before switch on, ensure that all connections will be proper correct.Press the Key at the bottom of the panel of this Unit to turn on this Unit.Press the Key to show Menu and select Power Logo to turn off this Unit.When the power indicator turns red, this Unit accesses standby state. -
Page 14: Sound Menu
TV OPERATION Zoom Mode Press ◀/▶ button to select Auto/4:3/16:9/Zoom1/Zoom2/Just scan. Press ◀/▶ button to select On or Off. 2. Sound MENU 1). Press the MENU button and then press ◀/▶ button to select the Sound menu and then press the OK button. 2). -
Page 15: Lock Menu
TV OPERATION 1). Press the MENU button and then press ◀/▶ button to select the Channel menu and Press the OK button. 3.2 Auto Tuning 2). Press ▲/▼ button to select Program Edit and press OK to Press ◀/▶ button to select submenu Search Type, ATV,DTV, Confirm. -
Page 16: Setting Menu
TV OPERATION 6. Setting MENU Note: The default password is 0000. if you forget the password, Press the MENU button and then press ◀/▶ button to select the you can input the super password:9443. Setting menu and then press the OK button. Press▲/▼... - Page 17 TV OPERATION HDMI_CEC APP Function Description: Fav.APP: Customized favorite app, Open APP by shortcut. Press the MENU button and then press ◀/▶ button to select the In any source or application, press the Fav.APP button to Setting menu and then press the OK button. quickly open the first added application;...
- Page 18 TV OPERATION Wire network Apps List Menu Insert the Ethernet cable ,and select Auto get IP address to There are some Apps, you can choose your like application, connect the Ethernet. and press OK button to open it. Wireless Network Select the WIFI ,and press the password to connect.
- Page 19 TV OPERATION -18-...
-
Page 20: App Store
APP STORE APP STORE 1.Start up In the app lists to find out the below app store icon, click it to open application store. Each time the boot will automatically detect whether the device network is connected or not. Each time the start will automatically detect whether the store have authorized or not. If authorized, will directly lead to app store home page. -
Page 21: Apps
APP STORE 3.Apps Put remote controller cursor on apps columns and click confirm to enter into lists to check categories as "Video, Life, Education, Tool, Game". Check each category app list Use remote control to put cursor in one item and click confirm to enter into lists of apps in one category, it will present app icon, application name, application size, free app, paid app as following screenshot: 4.Free app detail page... -
Page 22: Download
APP STORE The left area shows the application name, version, application size,download, application description, control and language: Action button: Download: When the application was not downloaded, the button will display as "Download", user can click the button to download app; If "Pause"... -
Page 23: Uninstall
APP STORE (3.4) Uninstall:If you need to uninstall the application, you can click the "Uninstall"button and will popup "Do you want to Uninstall this app?", Click OK will load of app successfully as shown in Figure 3.5; (3.5) 5.Buy application Use the remote control to select an application icon Press the OK key to enter the appropriate application details. - Page 24 APP STORE Action button: Buy: Click Buy If logged in, the page will pop up payment interface as shown below: If not login, when click buy will lead to login account and then to purchase. Use remote controller to click "Check Out with Paypal" will pop up Paypal payment plug-in as in the following screenshot: There are two methods for paying, with payapal and bank card.
-
Page 25: Search
APP STORE Use the remote control to select pay with card, then click OK will pop up another interface, you need to enter card number, expires and cvv data information as shown below: Enter info and then click done to next page to finish payment process, after that to process download, install and open app. -
Page 26: Account
APP STORE Account:Use the remote controller to select Account and click OK will lead to account interface, you can set Nickname, Date of birth and Country. Click "log out" will pop up "click on the current account?", please Click OK to exit.Click "Change password"... -
Page 27: Uninstall
APP STORE If shows number 1, it means only 1 app need update. Use remote controller to choose Update, click OK and enter into next interface to select the app need to be updated, click OK will pop up another interface, click Update, it will update and present progress bar in the main interface, Installation, will replace the local installation of the application. -
Page 28: Quit
APP STORE Log In If you have registered account, you can directly enter into mail and password to login.Password requires 6-20 characters; If you had forgotten password, you need to click "Forget your password?" and put in mailbox to get info for reactive. Quit Click return button will pop-up "Are you sure you want to exit the program?", please click ok button to exit. -
Page 29: Trouble Shooting
TROUBLE SHOOTING Trouble phenomenon Picture Audio Inspection antenna position, direction Snow Noise or connection antenna position, direction Ghost or connection Normal audio electronic equipment,car/ Interfere Noise motorcycle,fluorescent light Volume(inspect wether the mute function on the remote Normal Picture Mute control are started , or audio system are correct or not) Power cord is not inserted Power switch is not opened... - Page 30 4 0 3 1 Q6 5 6 Z 1 8...
