LK 6120 MIC
User Manual
Version: 09/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LK 6120 MIC and is the answer not in the manual?

Questions and answers

Related Manuals for McGrey LK 6120 MIC

Summary of Contents for McGrey LK 6120 MIC

  • Page 1 LK 6120 MIC User Manual Version: 09/2019...
  • Page 2 © 2019 This manual is protected by copyright. Any copying or reprint, even in excerpts, is only allowed with written consent of Musikhaus Kirstein GmbH. The same applies to reproduction or copying of images, even in altered form. Contents 1.Panel Control ...................... 1 2.External Ports .....................

  • Page 3: Table Of Contents

    Stop rhythm ......................4 Metronome ......................4 Adjust Tempo ....................... 4 8. Accompaniment function (chord mode) ............4 Single Chord ......................4 Fingered Chord ....................5 9. Memory function ....................6 10. Effects....................... 6 Transpose function ....................6 Sustain function ....................6 Vibrato function ....................
  • Page 4 Thank you for purchasing this musical Instrument. To ensure you will be completely satisfied with this product, read and understand this manual carefully before use. Keep the manual in a safe place. The Operating Manual must be passed on to all subsequent users.
  • Page 5 Attention Please observe the following basic information in order not to endanger yourself or others and to avoid damage on external equipment. Warnings Do not disassemble the instrument and do not modify it. This could result in electric shock. Entrust a specialist workshop with any necessary service and maintenance or contact your dealer.

  • Page 6: Panel Control

    1. Panel Control 2. External Ports This portable device is designed for indoor use. The warranty does not apply to equipment used for professional use.

  • Page 7: Performance Preparation

    3. Performance Preparation Battery mode: The instrument requires six 1.5V AA batteries. Open the battery compartment cover on the bottom and insert the batteries one after the other with the correct polarity. Replace the cover when the batteries are installed. (Batteries are not included.) Energy or voltage losses lead to loss of volume and distortion.

  • Page 8: Microphone Jack

    Microphone jack: Connect the included microphone here to join in your performance. Using a microphone may cause some noise such as hissing or feedback. Please keep the microphone at a reasonable distance from the speakers. It is recommended to unplug the microphone when not in use to avoid background noise.

  • Page 9: Stop Rhythm

    Play demo songs: Press the [DEMO One] button. The keyboard now plays the current demo song repeatedly. Press the button again to play the next demo song. Press the [DEMO All] button. The keyboard plays all demo songs one after another. During playback of a demo song, the voice (TIMBRE) can be changed.

  • Page 10: Fingered Chord

    Fingered Chord: When the rhythm is activated, press [FINGERED]. After "Fin" is displayed on the screen, you can play a full chord on the keys in the chord section of the keyboard. If you press [FINGERED] again, "OFF" will be displayed on the screen and finger chord function will be disabled.

  • Page 11: Memory Function

    9. Memory function The Direct Memory feature allows you to save the voice, rhythm, tempo, and other parameters that you want to change during playback for quick customization. This instrument is equipped with 3 direct memory buttons. Set the instrument to the desired values, press the [Memory] button and select [Memory 1] to [Memory 4] to save the current status.

  • Page 12: Rhythm Programming

    Press the [PLAY] button to play the recorded sounds for one time. The screen will show "PLy". When playback is complete, the recording mode is called up and "rEC" is displayed on the screen. You can now record again or press [PLAY] to replay the recorded sound.
  • Page 13 Press [Follow] to activate the Follow function, then press the "+" / "-" button to select the song to learn. This training [Follow] aims at learning the right pitch. Follow the tones shown on the display and through the illuminated keys on the keyboard. You must first play the correct note before the instrument continues to play.

  • Page 14: Appendix

    APPENDIX Timbre...

  • Page 15: Rhythm

    Rhythm...

  • Page 16: Weee Declaration (Waste Of Electrical And Electronic Equipment)

    WEEE Declaration (Waste of Electrical and Electronic Equipment) Your product has been designed and manufactured using quality materials and components that are recyclable and reusable. The symbol means that your product must be disposed separately from household waste at the end of its service life. Dispose of this equipment at your local collection point or recycling center.
