- Page 1 Mounting instruction for RF link amplifier RF link amplifier 1405266 RF link amplifier with return path 1405366 Galvanic isolator 8039004...
- Page 2 Cautions! – Make sure that the RF link CAUTION amplifier is placed and RISK OF ELECTRIC SHOCK DO NOT OPEN connected in accordance with the instructions in this Guide. To CAUTION: To reduce the risk of prevent injury, use Bang & electric shock, do not remove Olufsen approved wall brackets cover (or back).
- Page 3 - Mount bracket on wall Only use screws / wall ankers suited for your wall material - Place the RF link amplifier on the bracket - Mount all cables on RF link amplifier (See the following pages) - Connect power (230V)
-
Page 4: Galvanic Isolator
Amplifier Galvanic Isolator Mod. IN TAP 2 Cable from system modu- Cables to mainroom TV or Cable from Cable Network lator on mainroom TV TV in link rooms Aerial IN TAP 4 Ground Cable from antenna or Cables to mainroom TV or connection cable network TV in link rooms... - Page 5 Local aerial connection Signal from Amplifier 40-860 MHz TAP 2 TAP 4 6 dB 10 dB Aerial +8 dB Mod. IN Aerial IN aerial 0 dB 0 dB Mod. +5 dB Rev. 0 dB 3 dB 5 dB TAP 1 TAP 3 Modulator attenuator Aerial attenuator...
- Page 6 Important! Wichtiger Hinweis! Galvanic separation Galvanische Trennung When the RF link amplifier is used in connection with a cable Wenn der RF Link Amplifier bei Anschluss an einem Kabelnetz be- network the Galvanic Isolator (Part no. 8039004) - must always be nutzt wird, muss stets der galvanische Isolator (Bestellnr.
- Page 7 Important ! Importante Séparation galvanique Separazione galvanica Lorsque le RF Link Amplifier est utilisé en relation avec un réseau de Se l’RF link amplifier viene utilizzato insieme a una rete cablata, câbles, l’isolateur galvanique (Pièce n° 8039004) doit toujours être l’isolatore galvanico (numero di serie 8039004) deve essere sempre inséré...
- Page 8 ¡Importante! Vigtigt! Separación galvánica Galvanisk adskillelse Al utilizar el RF Link Amplifier en conexión con una red de cableado, Når RF link amplifier benyttes sammen med et kabelnet, skal der el Galvanic Isolator (Código 8039004) se debe insertar siempre en- altid indsættes en galvanisk isolator (delnr.
- Page 9 Belangrijk! Внимание! Galvanische scheiding Гальваническая развязка Als de RF link amplifier wordt gebruikt in verband met een kabel- Если при организации кабельной сети используется усилитель netwerk moet de Galvanische Isolator (Onderdeelnummer 8039004) RF Link Amplifi er, то, во избежание появления заземляющих контуров, altijd tussen de kabelnetwerkuitgang en de RF link amplifier worden между...
- Page 10 !ﻫﺎم 重要！ اﻟﻔﺼﻞ اﻟﺠﻠﻔﺎﻧﻲ 电隔离 在有线网络中使用 �� ���� �������� 时，有线网络插座和 َ ﻓﻲ اﻟﺘﻮﺻﻴﻞ ﻣﻊ ﻛﺎﺑﻞ ﺷﺒﻜﺔ ﻳﺠﺐ ﺗﺜﺒﻴﺖ اﻟﻌﺎزل َ ﻓﻲ اﻟﺘﻮﺻﻴﻞ ﻣﻊ ﻛﺎﺑﻞ ﺷﺒﻜﺔ ﻳﺠﺐ ﺗﺜﺒﻴﺖ اﻟﻌﺎزل َ ﻋﻨﺪ اﺳﺘﺨﺪام وﺻﻠﺔ ﻋﻨﺪ اﺳﺘﺨﺪام وﺻﻠﺔ RF link amplifier RF link amplifier RF link amplifier ��...
