Inhaltsverzeichnis / Table of Contents 3 / 7 1. Montage- und Sicherheitshinweise / Mounting and safety instructions 2. Allgemeine Funktionsbeschreibung, Gerätevarianten und Applikationsbeispiel General functional description, device variants and application example 4 / 8 5 / 9 3. Funktions- und Bedienelemente / Function and control elements 6 / 10 4.
Page 4
2. Allgemeine Funktionsbeschreibung Der ONR 201 ist ein optischer Rückkanalempfänger speziell für HFC Netzwerke sowie für die Datenübertragung für digitale CMTS-Dienste in CATV-Netzen. Durch den Einsatz von Power-Doubler-Verstärker-Modulen bietet das Gerät eine rauscharme und leistungsstarke Performance und ist flexibel an verschiedene Anforderungen anpassbar. Der optische Rückkanalempfänger ONR 201 bietet die Möglichkeit der Aufrüstung mit bis zu 3 unabhängigen opti- schen Empfängermodulen ONR-M 200 in einem 19“...
3. Funktions- und Bedienelemente Frontansicht HF Testpunkt -20 dB Anzeige optisches Eingangssignal Anzeige Betriebsstatus An/Aus Rückweg-Empfänger- Einschub 2 (optional) Rückweg-Empfänger- Einschub 3 (optional) Power (rot) LED an Gerät eingeschaltet Signal ON (grün) LED an Signal am Eingang erkannt Rückansicht Erdungsanschluss Netzanschluss / Netzsicherung Netzschalter HF-Ausgang...
Page 6
4. Blockschaltbild ONR 201 bestückt mit 3x ONR-M 200 Verstärker Dämpfer Opt. Empfänger Verstärker Entzerrer ONR-M 200 Opt. RF OUT IN 1 RF Test -20 dB LED Indikator ONR-M 200 Opt. RF OUT IN 2 RF Test -20 dB LED Indikator ONR-M 200 Opt.
Page 8
2. General functional description The ONR 201 is an optical return path receiver especially for HFC networks, as well as data transmission for digital CMTS services in CATV networks. By using power doubler amplifier modules, the device offers low noise and high performance and is flexible for adapting to different requirements.
Page 9
3. Function and control elements Front view RF Test point -20 dB Optical input signal status (on/off) Operating status (on/off) Return path receiver module 2 (optional) Return path receiver module 3 (optional) Power (red) LED on Device is activated Signal ON (green) LED on Signal detected at input Rear view...
4. Block diagram ONR 201 assembled with 3x ONR-M 200 Amplifier Attenuator Opt. receiver Amplifier Equalizer ONR-M 200 Opt. RF OUT IN 1 RF Test -20 dB LED Indicator ONR-M 200 Opt. RF OUT IN 2 RF Test -20 dB LED Indicator ONR-M 200 Opt.
6. Technische Daten / Technical data Typ / Type ONR 201 Artikel-Nr. / Article no. 9417012 Anzahl der Rückkanalmodule / Quantity of return channel modules (erweiterbar bis 3 Module pro Chassis / upgradeable up to 3 modules per chassis) Optischer Bereich / Optical Section 1000 …...
