User Manual

Floor distributor CMD-404FU/CMD-404FUD

• Thank you for purchasing COMMAX products.

• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Table of Contents

Need help?

Do you have a question about the CMD-404FU and is the answer not in the manual?

Questions and answers

Summary of Contents for Commax CMD-404FU

Page 1: User Manual
User Manual Floor distributor CMD-404FU/CMD-404FUD • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. • The company is not responsible for any safety accidents caused by abnormal operation of the product.
Page 2: Table Of Contents
Contents 1. Introduction ...............2 2. Important Safeguard ............3 3. Product Concept and Features .........4 4. Wiring diagram ..............6 5. Configuration of DEVICE ID & mode .......9 6. Specification..............15...
Page 3: Introduction
The model number is located on the bottom and record the serial number in the space provided below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product. Model No.
Page 4: Important Safeguard
2. Important Safeguards ▲ Damage Requiring Service : This equipment from the power source and source and refer servicing to qualified service per- sonnel under the following conditions ⓐ when the power is damaged. ⓑ if liquid has been spoiled or objects have hallen into the unit ⓒ...
Page 5: Product Concept And Features
3. Product Concept and Features ● CMD-404FU(D) building distributor is used to interlock with floor distributor (CMD-101BU) and is developed for interlocking Modum system monitor with lobby and security. CMD-404FU(AC TYPE) is limited to the following devices that can be ●...
Page 6 ※ with one power supply r per one CMD-404FUD. (Required) ● CMD-404FU(D) Notes on wiring (It doesn't guarantee the quality of product for connec-tion if you do not keep the following) - Wire the "IN" of CMD-404FU(D) with distributor or, CMD-404FU(D) installed with "OUT"...
Page 7 - CMD-404FU(D) distribute wires up four houses on one floor and output common 6 lines after receiving common 6 lines (DATA/GND/LB-TALKA,B/VD_P,N) from Distributor(CMD-101BU) - Maximum 79 CMD-404FU(D) can be operated within 300 meter from lobby or CCTV. - The distant from floor di stributor (CMD -404 FU(D)) to Mo dum System within 30m.
Page 8 (Caution: When interlocking or expanding with external device, do connect two or more video phone. AC-TYPE CMD-404FU: (AC TYPE) The video phone for 4-wire way Modum system.(Required) (CMV-43A/CMV-77K/CMV-43S/CMV-70S) Adapter (Power): RF-2A Power(DC24V / 1A) input basically should be advised to be installed with one ※...
Page 9: Wiring Diagram
4. Wiring diagram ● CCTV LOBBY Building distributor(CMD-101BU)   CMD-404FU(D)(1 FLOOR) CMD-404FU(D)(1 FLOOR)   CMD-404FU(D)(2 FLOOR)  ... MODUME VIDEO PHONE : UTP CABLE [CAT.5e] - MAX 300m...
Page 12 ● OPTION (Use for easy connection: CMD-101BU/CCU-204AGF LINE BOARD) CASE : MODUM SYSTEM + AUDIO GATE SYSTEM...
Page 13: Configuration Of Device Id & Mode
5. Configuration of DEVICE ID & MODE for Household Unit Number registration ※ The following CMD-404FU(D) Configuration must be done before setting MODUM SYSTEM Lobby Camera Phone. - When configuring the Device ID, set up Dip switch on the back panel of the product.
Page 14 ● Functions for each switches ● # 1 (Select MANUAL /AUTO) : OFF= MANUAL / ON=AUTO # 2 ~4 (ID configuration: 10 digit figure) : Composed of BCD code (Refer to picture below) # 5~6 (ID configuration: single digit figure) : Composed of BCD code (Refer to picture below)
Page 15 ● Number description method by switches (There are three 10 digit figure switches which can be used to seven) [''Enter ten digit number : 0~7] ['Enter single digit number: 0~9] ** ID configuration range: 1 ~ 79(MAX) room number can be entered. **...
Page 16 ● Auto / Manual mode function Auto Mode (ON): When booted with number one switch on, it operates with auto mode. Room numbers are allocated sequentially by the ID number configured. (Building # is fixed as #101, designated ID X '4' will be final channel of room #) Ex) When ID = 1 configured Channel 1 (Line1) = Block 101 unit 1 Channel 2 (Line2) = Block 101 unit 2...
Page 17 Channel 2 (Line2) = Block 101 unit 314 Channel 3 (Line3) = Block 101 unit 315 Channel 4 (Line4) = Block 101 unit 316( 79(ID#) X 4 = 316 [Last channel unit number is designated as 316]) ** Reference: On Auto Mode block number is fixed as 101.** Manual Mode (OFF): When booted with number 1 switch off, it operates on MANUAL mode.
Page 18 When you register the lobby information to floor distributor from the lobby phone, this floor distributor will be set with the building No. of lobby phone. After that, the household unit which is connected with this floor distributor can check the image of lobby phone during monitoring mode ●...
Page 19: Specification
1. MODUM System building distributor(CMD-404FU(D))  CMD-404FU(D) IN (Input) Wiring Sequence 2. CMD-404FU(D) OUT(Output)  Upstairs CMD-404FU(D) IN (Expansio 3. CMD-404FU(D) LINE1,2,3,4  Monitor (MODUM System video phone) Maximum 300m : Main entrance  monitor, the distance from each floor Wiring distance distributor to each monitor is limited by 30m.
Page 20 MEMO...
Page 21 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2016.11.105 PM99404FU010...
