TQC DI0035 Manual

LED POCKET FLASHLIGHT
DI0035

1 SAFETY PRECAUTIONS

WARNING: The light from this flashlight is very powerful and should not be
shone directly into anyone's eyes, as this may cause short term blindness. If
the beam does shine in your eyes, close them and look away immediately.

2 PRODUCT DESCRIPTION

This powerful TQC LED pocket flashlight produces a very impressive 200 lumens
and provides a projection distance of 250 meters. Small, portable and light weighted (73gr)
2.1 Specifications
Light Source : LED
Chip : Cree Q4 LED
Max. Output : 200 lumens
Batteries : 3xAAA alkaline batteries
Net. weight : 72 grams excl. batteries
Beam distance : 250 meters
Burning time : 73 hours
IP No. : IP67
Contacts : gold-plated
Size : 26 x 118mm
Shockproof : From a height of one meter
Certification : ROHS, CE
Material : Aerospace-grade 6061-T6 aluminum
3 WHAT'S IN THE BOX?
LED pocket flashlight
3 x AAA alkaline battery
Wrist strap
Pouch

4 PERFORM A MEASUREMENT

4.1 installing the batteries

Hold the aluminium casing firmly in one hand
and turn the end cap in a counter clockwise
direction until fully unscrewed (see figure) Pull
the end cap away from the casing and this will
reveal the battery cartridge. Place each battery
within the cartridge ensuring that the polarity
marks (+ and -) on the battery match that of
