Dr. Neil Presents
Install Your Own
Home Loop System
with
Confidence

Advertisement

loading
Need help?

Need help?

Do you have a question about the DLS-50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Univox DLS-50

Summary of Contents for Univox DLS-50

  • Page 1 Dr. Neil Presents Install Your Own Home Loop System with Confidence...
  • Page 2 This presentation teaches you how to install the wonderful Univox DLS-50 home loop system in your home or apartment...
  • Page 3 A loop system consists of two parts: 1. The transmitting section 2. The receiving section...
  • Page 4 Transmitting Section The transmitting section consists of 4 components...
  • Page 5 1. Sound Source (TV)

  • Page 6: Audio Cable

    2. Audio Cable To connect the audio output of your TV to the loop amplifier...

  • Page 7: Loop Amplifier

    3. Loop Amplifier Univox DLS-50 Loop Amplifier...
  • Page 8 4. Room Loop or Loop Pad Red arrow points to loop pad Red arrow points to room loop wire...
  • Page 9 Receiving Section The loop system receiving section consists of a single component. There are two choices, depending whether you wear hearing aids with t-coils or not. These components are:...
  • Page 10 Hearing Aid with T-coil...
  • Page 11 Loop Receiver Univox Listener Loop receivers are useful for people who do not wear hearing aids, or do not have t-coils in their hearing aids.
  • Page 12 Setting up your Univox DLS-50 Loop System is a simple four-step process 1. Plug in the power adapter 2. Attach the audio cable to your TV (or other audio device) and the loop amplifier 3. Hook up the room loop or loop pad...
  • Page 13 Univox DLS-50 (power plug) Plug in the power adapter plug to the power jack on the left...
  • Page 14 Locate the red and white audio output RCA jacks on the back of your TV Note: make sure you use the audio OUT jacks, not the audio IN jacks...
  • Page 15 Plug the red and white RCA plugs of your audio cable into the corresponding audio output RCA jacks Some audio cables just have a red and white band on them...
  • Page 16 Plug the mini-phone plug on the other end of the audio cable into the Line jack on the back (center) of the Univox DLS-50...
  • Page 17 Choose whether to install a Loop Pad Room Loop...
  • Page 18 Advantages of a Loop Pad • Fast and easy to install • Portable—easy to move...
  • Page 19 Disadvantages of a Loop Pad • Have to sit in one specific chair in order to hear on the loop • Typically only one person can hear at a time...
  • Page 20 Advantages of a Room Loop • Can sit anywhere or move around freely anywhere inside the looped area • As many people as can fit inside the looped area can hear via the loop...
