DAW-3
(Receiver),
Thank you for buying this RITS-N Wireless Touch Switch. This product is a set of wireless transmitter/receiver switches to be installed in the
equipment requiring relay contact input
1 Component & Specifications
Double-sided adhesive tape
Two kinds of screws (3*8, 4*16)
Batteries 3V(COIN BATTERY) CR2450
User's Manual
Power supply
Rated frequency
Operating temp.
Distance
Power consumption
Thickness
2 How to Install Wireless Touch Transmitter Switch
Double-sided
adhesive
Wireless touch switch
(DAW-5)
DAW-5
(Transmitter)
to control motor e.g., of automatic
DAW-5(Transmitter)
3V *2 (TYPE : CR2450)
FM 447.600MHz
-10℃ ~ 60℃
10m
9mA
13mm
Double-sided
adhesive
RITS-N CO., LTD.
door.
1EA
Power connection wire(black, red)
2EA each
Output contact wire(green, green)
2EA
Fixing screws (4*16)
1 copy
User's Manual
Power supply
Relay contact capacity
Reception sensitivity
-
-
-
Wireless touch switch
(DAW-5)
☞ Procedures
Tempered
Type Registration Certificate No. : R-LARN-02-0264
DAW-3(Receiver)
AC220V or AC/DC12V~40V
0.5A / 125VAC , 2A / 30VDC
-100 dBm (TEM CELL)
(DAW-5)
① Input DAW-5(wireless touch switch) into your
receiver. (Input method: while pressing and
holding the S/W Input Button on the receiver,
press and hold the Wireless Touch Switch for
about six seconds.)
② Attach double-sided adhesive tape to the
assembled wireless touch switch.
③ Fix the wireless touch switch on the tempered
glass or on the desired place to be installed.
2 pieces
2 pieces
2EA
1 copy
-
-
-
