2015/6/25
Ver3.16.0
Kyocera USB Modem Driver
[kc02us_setup_x64.msi/kc02us_setup_x86.msi installer]
Installation/Uninstallation Procedure
Contents
*The messages described in this manual are based on WINDOWS 7 x64 SP1.
Therefore, the messages may be not coincident with some devices.
1
Advertisement
Related Manuals for Kyocera KC02US
Summary of Contents for Kyocera KC02US
-
Page 1: Table Of Contents
2015/6/25 Ver3.16.0 Kyocera USB Modem Driver [kc02us_setup_x64.msi/kc02us_setup_x86.msi installer] Installation/Uninstallation Procedure Contents 1. Supported OS 2. Supported devices 3. Before Installation 4. Installation Procedure 5. Uninstallation Procedure 6. Attention 7.Trouble Shooting *The messages described in this manual are based on WINDOWS 7 x64 SP1. -
Page 2: Supported Os
You must not connect the handset to the PC which old USB drivers were installed. If you already installed the old USB drivers for Kyocera devices (See “2. Supported devices”), please uninstall them as follows. A) Disconnect the handset from USB port on the PC. -
Page 3: Installation Procedure
4. Installation Procedure A) Disconnect the handset from USB port on the PC. B) If your PC is 32bit OS, press kc02us_setup_x86.msi. If your PC is 64bit OS, press kc02us_setup_x64.msi. C) Install Driver dialog will be launched, and then press [Next] button. - Page 4 D) Press [Install] button. E) Installation is completed when the dialog "InstallShield Wizard Completed" is displayed. Press [Finish] button to continue procedure.
- Page 5 F) Connect the handset to USB port on the PC. The handset will be recognized automatically by plug-and-play. G) Installation is now completed. *Confirm if the driver is working properly by Device Manager. Press "Control panel"/"System"/"Hardware"/"Device Manager".
-
Page 6: Uninstallation Procedure
A) Disconnect the handset from USB port on the PC. B) Uninstall Driver Press "Control Panel"/"Add or Remove Programs" If either "Kyocera USB Modem KC02US Driver" exists, press [Change/Remove]. C) Press [Yes] button when "Uninstall Driver" dialog is displayed. D) When uninstallation is completed, the message to restart PC will be displayed, then press [Yes] button. -
Page 7: Attention
6. Attention *Please disconnect the handset from USB port on the PC before execute Installation/Uninstallation procedure. Error could occur, if handset is connected to USB port. -
Page 8: Trouble Shooting
7. Trouble Shooting Case 1) The "!" mark does not disappear from the configuration of the device 1) Open "Device Manager" 2) Open “Universal Serial Bus controllers”... - Page 9 3) Please follow the following steps...
