  • Page 1 SMART W-LAN IP VIDEO DOORBELL HD/SERIES USER MANUAL V1.0...

  • Page 2: Table Of Contents

    Important Safety Instructions .................. 4 Product Introduction ....................5 Items Included ......................7 Before Installation ....................9 Installation of Mounting Bracket ................12 Connection To Old Chime AC Power Source ............13 Connection To DC Power Source ................15 Connection Between Wireless Doorbell & Indoor RF Bell ........16 Introduction Of Android/iOS App Interface ............
  • Page 3 8.Record ......................24 9.Settings ......................25 System Setting.................. 25 User Setting ..................26 Alarm Setting ................. 26 Lock Setting ..................27 Device Time Setting ................. 27 Wi-Fi Setting ..................28 Push Setting ..................28 Answer the Call ...................... 32 Tech Support ......................34 Care and Maintenance...................

  • Page 4: Important Safety Instructions

    Important Safety Instructions Please read through all the instructions before using this wireless doorbell. This is an electronic device and care should be taken when using this low voltage electronic device. The following basic safety precautions should be taken into consideration when operating and installing this doorbell, 1.

  • Page 5: Product Introduction

    Product Introduction Wireless Doorbell 1. Camera 2. Built-in microphone 3. Call button with indicator light 4. Built-in speaker 5. IR LEDs (for night vision) 6. Relay connector (for electrical door lock) 7. Power connector 8. LAN connector 9. Reset (use pin to press and hold for approx. 10 seconds) 10.
  • Page 6 Indoor RF Bell The drawing based on EU type, US/UK plug is optional, please refer to the final product. 11. Volume button (press repeatedly to adjust the sound volume) 12. Music button (press repeatedly for totally 36 melody options) Mounting Bracket 13.

  • Page 7: Items Included

    Items Included Wireless doorbell x 1 pc Indoor RF bell x 1 pc DC Power adaptor x 1pc (The drawing based on EU type, US/UK plug is optional, please refer to the final product.) LAN interface connector (RJ45) x 1 pc Relay interface connector x 1 pc (for electrical door lock) AC power input join cable x 1 pc...
  • Page 8 Mounting bracket x 1 pc Simple mounting bracket x 1 pc Screw driver x 1 pc Screw (C) x Screw (A) Screws set for screws (A) & (C) --Screw (A) x 2 pcs (1 pc is as spare) --Screw (C) x 3 pcs (1 pc is as spare) --Plug for screw (C) x 3 pcs (1 pc is as spare) Screws (B) Screws set for screws (B)

  • Page 9: Before Installation

    Before Installation IT IS STRONGLY SUGGESTED TO PERFORM A TEST BEFORE THE WIRELESS DOORBELL IS INSTALLED. Note: Download the “WiFi Doorbell HD” app from Google Play Store or App Store to your android or iOS device. Make sure your android or iOS device connected to the local Wi-Fi successfully. Step 1: Power-on the wireless doorbell with an external 12V DC adaptor.
  • Page 10 Step 6: Once hear the voice prompt “Successful” means the Wi-Fi SmartLink setup successfully. “Refresh” and click the UDID of the doorbell to add it to the device list automatically, “Refresh” and it will be online. If the wireless doorbell performs as described, please proceed to do the installation. If not, please double check and repeat the step 1 to step 6.
  • Page 11 Step 7: When the doorbell is online, press the call button of the doorbell, the App will pop-up as follow, Pickup icon Hangup icon Reject: Click the red hang up icon to reject the call, the doorbell will keep calling until somebody else to answer it, or until a call action is completed.

  • Page 12: Installation Of Mounting Bracket

    Installation of Mounting Bracket Free choose to install the wireless doorbell with either the mounting bracket or the simple mounting bracket. Installation with the mounting bracket Please refer to the “Connection To Old Chime AC Power Source”. Installation with the simple mounting bracket (It is recommended to use the mounting bracket instead of the simple mounting bracket) Step 1: Fix the simple mounting bracket with two screws (C) to the wall.

  • Page 13: Connection To Old Chime Ac Power Source

    Connection To Old Chime AC Power Source Step 1: Remove the existing doorbell. Step 2: Check the voltage of the power by using a multimeter. Make sure the power voltage/current is 12~24V AC / 1.0A before proceeding to step 3. Step 3: Connect the power cables of the old doorbell to the wireless doorbell (via the power input join cable, screws (B), plugs &...
  • Page 14 Step 4: Complete the installation by tightening screw (A). Screw (A) Note: When hooking up the new doorbell to an existing doorbell transformer be sure to test the connection first before installing the unit. Some older doorbell transformers may be dead or the wrong voltage. Do not exceed 24 Volts AC to the doorbell or damage may occur and void warranty.

  • Page 15: Connection To Dc Power Source

    Connection To DC Power Source If there is no old chime with AC Power Source, please use the 12V DC power adaptor to connect with the wireless doorbell. To extend the power cable, use 2 conductor 18 AWG cable. Do not extend beyond 100ft. The AC/DC adaptor: input 100 to 240VAC, output 12VDC, 1A.

  • Page 16: Connection Between Wireless Doorbell & Indoor Rf Bell

    Connection Between Wireless Doorbell & Indoor RF Bell Music button Volume button Call button The wireless doorbell and indoor RF bell are already paired. After power-on, press the call button, the RF bell should ring. If they lost connection, please do the follow steps to pair the wireless doorbell with indoor RF bell: Step 1: Connect the wireless doorbell and the indoor RF bell to power source.

  • Page 17: Introduction Of Android/Ios App Interface

    Introduction Of Android/iOS App Interface Only the “admin” user has the authority to make adjustment or change to most of the settings. : Additional options. : Delete/Edit the listed doorbell information. : Add new doorbells. : Refresh the doorbell connection status. : Main interface of doorbell list.

  • Page 18: Additional Options

    1.Additional Options : Show the Ring Setting, Local Setting and About. Ring Setting: Set the App Ringtone, choose “None” will be in silent mode. Local Setting: To show or not show “HD / Smooth” text on the online video. About: Show the App information.

  • Page 19: Edit

    2.Edit :Delete/Edit the listed doorbell information. Can change the doorbell name/password here. After setting the changes, click “Done” to enable it.

  • Page 20: Add Device

    3.Add Device : Two options to add device, SmartLink / Networked Devices. 3.1 SmartLink Mode SmartLink mode is only for setting the Wi-Fi of the doorbell at the first time. The default factory settings is the doorbell will be under SmartLink Mode when power-on at the first time. Check the details of SmartLink Mode on chapter “Before Installation”.

  • Page 21: Input The Doorbell Information Manually

    To add a new doorbell, 3 options as below: 3.2.1 Input the doorbell information manually Name: The default name is “Doorbell”, change a new name here if needed. ID: The P2P ID can be found on the rating label of the doorbell, scan the QR code will get the ID too. User: The default user name is “admin”...

  • Page 22: Local Search

    3.2.3 Local Search Click “Local Search” and the list of available doorbell(s) will be shown. Note: It works only when the Android/iOS device and the Doorbell connected with the same network. Android Click the UDID of the doorbell, input the correct user name and password, click “Done” to complete the settings, the doorbell will be connected to the Android or iOS Device and show online.

  • Page 23: Refresh

    4.Refresh Click to refresh the doorbell connection status, online/offline/connection failed etc. 5.Doorbell Click it to go to the main interface of doorbell list. 6.Log Click it to check the Call Log or Alarm Log.

  • Page 24: Snapshot

    7.Snapshot Click it to check the snapshots. 8.Record Click it to check the recorded video. The video file is in AVI format, please check the video with the software/app which supports AVI format.

  • Page 25: Settings

    9.Settings Click it to check or change the settings of doorbell. System Setting Voice Prompt: Turn On/Off the doorbell voice prompt feature. The Max. monitor time(s): 10~300 seconds, This is to set up the monitor time when you visit the doorbell online video initiative. The Max.

  • Page 26: User Setting

    User Setting Only administrator can add or edit a user. Click “Edit” to set the users and password, click “OK” to close the interface. Click “Done” to enable the settings. Note: 1. The doorbell supports 3 users totally. 2. Different devices can login the doorbell with the same user/password at the same time. 3.

  • Page 27: Lock Setting

    Lock Setting Lock Type(Relay Type): Please keep the relay type at NO. Monitor Lock/Unlock: Allow(On) means you can unlock the lock actively at any time; Forbid(Off) means you can only unlock the lock when you answered the call. Lock Delay (S): It represents the duration time of the relay type status. Unlock Password Setting: To set the 6 digits unlock password.

  • Page 28: Wi-Fi Setting

    Manual Setup: Manually set up the doorbell time. Device Time Zone: Select the corresponding time zone. NTP Server/NTP Port: Please keep the default. Note: It’s very important that the push notification function works properly only when the device time and time zone is sync with the local time.
  • Page 29 If the app is active and running in the background, when the call button on the doorbell is pressed, or a motion detected, there would be push notification sent to your smart device such as mobile phone. For iOS: Please make sure allow push notification for the app “WiFi Doorbell HD” in iOS device settings. For Android: Please do the following settings before the push notification works in the Android devices.
  • Page 30 2. Enable the “WiFi Doorbell HD ” in Protected apps to allow the app to keep running after the screen is turned off. 3. You can exit the “WiFi Doorbell HD ” app and keep it running in the background, Step 2: Select Exit Step 1:...
  • Page 31 4. But please make sure that the “WiFi Doorbell HD ” app progress is not cleared, If it’s cleared, the Android device will not be able to receive the push notification. If the upon 4 steps are done, the app will be running in the background, the power consumption of this app in Android device is low.

  • Page 32: Answer The Call

    Answer the Call When somebody pressed the call button of the doorbell, there are 2 options to answer the call, Option 1: When the app is active and running (Not in the background). You will receive a call from the doorbell, click the blue icon to answer the call, the red icon to reject the call. Option 2: When the app is active and running in the background.
  • Page 33 Tap the ID of the doorbell : Press and hold Mic icon to talk, loosen to hear the visitor’s voice. : Start/Stop video recording. : Click it to mute. : Unlock the electronic door lock. : Take snapshot. : Hang up, click to stop and exit the live feed video. : Click to prolong the monitoring time.

  • Page 34: Tech Support

    Tech Support Thank you for using our product. Please feel free to contact us if you have any questions. Care and Maintenance Wi-Fi doorbell HD does not require any service fees to operate. It does not require any special care. It requires a reliable Network Connection to operate.

  • Page 35: Specifications

    Specifications **Specifications are subject to change without prior notice. Model: Wi-Fi Doorbell HD Chipset Chipset Solution HiSilicon 3518E Image Sensor Color CMOS sensor Image Sensor Display Resolution 1280*720/704*576/320*240 Lens Type Glass Lens Focal Length 2.5mm Lens Aperture F2.5 Angle of view 135°...
  • Page 36 Indoor RF BELL 80(L)*76(W)*52(H)mm (US Type) Dimension 80(L)*76(W)*75(H)mm (EU Type) Physical Weight Approx 90g Shell ABS Plastic Power Power Supply AC 110-240V, 50/60HZ -------------------------------------------------------------------------------------------------------------------------------------------------- Thank you for purchasing our smart W-LAN IP video doorbell. We hope you enjoy the unique features of our modern day doorbell.
