- Page 2 NOTE: If you remove the Ferrites to shorten cable length of the reader please replace Ferrites back onto the cable. 6. Each iEvo reader needs its own network cable, as each reader has its own IP address. Ensure this has been taken into consideration before commencing with installation.
- Page 3 Please read this manual, It will help guide you through installing the iEvo reader and software INTRODUCTION: This Manual will cover the following areas in detail: · Installation · Support The minimum specs for your PC should be: CPU: Dual Core 2.0+ GHz (or equivalent)
-
Page 4: Table Of Contents
INSTALLATION Page5: Assembly Page6: Surface mount Page7: Flush mount Page8: Wiring Diagram Page9: Turnstile Example – iEvo Wiring Page10: Example – Network Page11: Page12: Wiegand Diagram (Paxton Net2) Page13: Wiegand Diagram (ACT) Page14: Installing iEvo software Page15: Installing USB Drivers... - Page 5 Installation...
- Page 6 Do not exceed 5 meters For mounting in cable length from the through wall reader to the iEvo control board. You are provided with 2.95 meters. Ensure good quality connectors if cable is extended. Do not remove any of the...
-
Page 7: Installation
Installation SURFACE MOUNTED INSTALLATION Ensure you use the correct fixing plug for the type of wall you are fixing the reader to. Incorrect usage The reader should be placed within the DDA will result in the reader being unsecure. Plaster board will standard height of approximately 1 meter require correct brackets for installation. -
Page 8: Flush Mount
Installation FLUSH MOUNTED INSTALLATION NOTE: The reader should be placed within the DDA standard height of approximately 1 meter Attach the reader back plate and the flush mounting plate to the back of the reader using the six (6) screws provided. -
Page 9: Wiring Diagram
) ievo ) reader Network ) Cable to PC Buzzer / LED / Wiegand Warning: When installing the iEvo control box, follow ESD Safety Procedures. Power Button / Heat Output Ground yourself to prevent damage to the any electronic component. system... -
Page 10: Turnstile
Installation Router TURNSTILE 2amp 2amp Network ievo ievo net2 net2 KEY: iEvo cable Relay Wiegand TCP/IP RS485 12vdc Ievo controller is ievo NOT IP rated. Please secure inside an IP65 secure box. - Page 11 Wiegand (3 core) CAT5 (Network Laptop cable) IEvo controller is NOT IP ievo rated. Please secure inside an IP65 secure box. Please refer to manufacturer ACU manual for correct installation of ACU board. iEvo and ACU must be installed internally...
- Page 12 Front Door Office Door Side Door 192.168.1.101 192.168.1.102 192.168.1.103 Port: 5005 Port: 5005 Port 5005 Network Network Router iEvo Software Anywhere in the world 94.4.193.234 Front IN Front OUT Stock Room 192.168.0.101 192.168.0.102 192.168.0.103 Port: 5005 Port: 5006 Port: 5007...
-
Page 13: Wiegand Diagram (Paxton Net2)
Installation WIEGAND DIAGRAM FOR PAXTON NET2 ievo BOARD Net2 Classic/Plus/ Nano Controller You can connect iEvo into reader 1 or reader 2 port. KEY: iEvo Paxton Please use Belden 9534 (4 Core Data/D0 Data/D0 shielded) twist 2 pairs for clock and data... -
Page 14: Wiegand Diagram (Act)
Installation WIEGAND DIAGRAM FOR ACT iEvo BOARD ACT-1000/2000/3200 Door Controller KEY: Please use Belden 9534 (4 Core shielded) twist 2 pairs for clock and data and use iEvo shield for GND for long cable runs. Data/D0 Data RS Part number: 382-510... -
Page 15: Installing Ievo Software
Click Next Click Next Click Install Click Finish iEvo will now be installed. To open the software please go to your desktop. NOTE: To use iEvo you must first install your Third party software...unless you are running iEvo Standalone version. -
Page 16: Installing Usb Drivers
Installation INSTALLING USB DRIVERS Please first insert the iEvo disk into your computer Please run “usb drivers.exe”... - Page 17 Installation Please follow these steps Click Next Tick “Accept” and then Next Choose which operating system you are running and click Next Click Install Installation is now complete, now click Finish...
-
Page 18: Support
Support HELP AND SUPPORT iEvo Contact support: Tel: 0845 643 6632 Email: support@ievoreader.com Web: www.ievoreader.com Help & Support: For Support please click Menu on the user list and click Help & Support iEvo address: Address: iEvo Ltd. Henson House, George Stephenson Ind. Est,...
