RHINO HO3608 Manual

Local air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Local Air Conditioner
FEATURES AND PARTS LIST
1. Features
• Self evaporative system, no water tank.
• Storage solution for plug at rear of machine.
• Handle designed for ease of use.
• LCD display, indicating temperature and operation status.
• Exhaust hose position designed to remove air quickly and efficiently.
• Sophisticated oval design.
• Four in one function (heating, cooling, dehumidifying and fan).
• Electronic control with LED display, timer function and remote control.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HO3608 and is the answer not in the manual?

Questions and answers

Related Manuals for RHINO HO3608

Summary of Contents for RHINO HO3608

  • Page 1 Local Air Conditioner FEATURES AND PARTS LIST 1. Features • Self evaporative system, no water tank. • Storage solution for plug at rear of machine. • Handle designed for ease of use. • LCD display, indicating temperature and operation status. •...

  • Page 2: Important Safeguards

    Thank you for selecting this new model portable air conditioner. Please safely keep this user manual for you later reading, and be sure to read this manual carefully before using the unit. IMPORTANT SAFEGUARDS • The appliance is for indoor use only. •...

  • Page 3: Parts List

    2. PARTS LIST:     1. Top cover 9. Up fi lter frame 2. Air outlet grille 10. Protective net 3. Control panel 11. Down fi lter frame 4. Front cover 12. Water plug 5. Caster 13. Remote control 6. Handle 14.

  • Page 4: Installation

    INSTALLATION 1. Installation Warning: Before using this unit, please keep it upright at least 2 hours. The unit can be moved easily among the rooms, but please note the following: 1.1 Assemble hose adaptor (picture 1)   Picture 1 Align the both hose adapters and secure together. 1.2 Assembly of the exhaust hose (picture 2)  ...
  • Page 5   1.4 Ensure the unit is upright during operation. The unit should be only used on a level surface ensuring a minimum distance of 50cm is maintained from all other objects/surfaces. Picture 5   Fix the other end of the heat-exhausted hose to the air-outlet window kit (picture 6, 7) Picture 6 Picture 7 Important safeguards...

  • Page 6: Control And Setting

    CONTROL AND SETTING This portable air conditioner is cool and heat model, it has four functions cooling, heating, dehumidifying and fan Fan has three speeds: high speed, middle speed and low speed, Setting temperature is 18--30°C, 24 hours timer, sensor and water-level protective function. 1.Control Instruction: Control panel:  ...

  • Page 7: Remote Control

    1.6 Up and Down button: can set temperature and timer . Under cooling or heating mode, the operating temperature ranges from 18~30°C/64~86°F. If press Up and Down button simultaneously, the unit will shift between °C to °F. 1.7 Sleeping key Under cooling or heating mode, press the key can make unit into sleeping mode, LCD will show , press again to cancel.

  • Page 8: Multi Protective Function

    24 hours, time interval is 1 hour. Once set number will flash 5 times as confirmation . 10. Max cool : Under cooling mode, press this key to achieve maximum output. 11. Keypad lock: Once set, press this key in use of something like a pin to lock all the button, as the screen will show image: , press this key again to unlock (This function can prevent kid from playing with the unit).

  • Page 9: Water Drainage

    WATER-DRAINAGE 1. Manual drainage: 1.1 When water plate is full and unit stops working, please shut off the unit and unplug Please do not move the unit when full, or the water will spill 1.2 Use a water container to take water under the water plug. 1.3 Screw off the water plug and unplug the water blocker, drain into a suitable container.
  • Page 10 MAINTENANCE Cleaning. Please note: Turn off and unplug the unit before cleaning or maintenance. Clean the surface Clean the housing with a duster or a soft wet cloth. Do not use a chemical solvent as this could cause damage. Air fi lter cleaning 1.1 Clean the air fi lters every 2 weeks.

  • Page 11: Troubleshooting

    TROUBLE SHOOTING Don’t repair or disassemble the unit by yourself. Please take to an authorized dealer. Failure to do so may affect the warranty. Trouble Reason Solution The unit doesn’t work No power supply Power-on and turn on the unit. Water-full indicator illuminate Drain out the inner stored water...
  • Page 12 APPENDIX Fuse Parameter Type: FSD or 50F Voltage: 250V Current: 3.15A   The working principium diagram of the unit: Capillary   t ube   Condenser   Compressor   Evaporato r   There is no further notice for the change of the parameters above, the exact parameters base on the rating plate.
