For Straight-Blade and
HTX/Sport Plows
Model MSC09215 and MSC09249
1.
Assemble the casters as shown in
1. Nut (5/16 inch)
2. Washers
3. Small caster shoe base
4. Kickstand caster base
5. Carriage bolt
2.
Park the machine on a level surface, raise the
plow fully, and place 2 safety jack stands under
the plow cutting edge.
3.
Shut off the engine, wait for all moving parts to
stop, engage the parking brake, and remove
the key.
4.
Slide the small caster shoes into the shoe
holders on the plow and secure them with a
quick pin
(Figure
Note:
Adjust the number of washers above and
below the shoe holder as needed.
© 2019—BOSS Products
P.O. Box 787
Iron Mountain, MI 49801
Caster and Dolly Kit
Part No. MSC01141
Part No. MSC09215
Part No. MSC09216
Part No. MSC09235
Part No. MSC09249
Figure
Figure 1
6. Nut (3/8 inch)
7. Large caster
8. Small caster
9. Bolt (5/16 inch)
2).
Register at www.bossplow.com.
1.
1. Quick pin
2. Shoe holder
5.
Remove the existing kickstand and replace it
with the kickstand caster shoe
g038527
1. Kickstand spring pin
Form No. MSC09482 Rev C
Installation Instructions
Figure 2
3. Small caster shoe
4. Washers
(Figure
Figure 3
2. Kickstand caster shoe
Original Instructions (EN)
All Rights Reserved *MSC09482* C
Printed in the USA
g038528
3).
g038529
