- Page 1 Infrared barrier for perimeter protection range 250 m SMA technology and RS485 output. Installation Manual. 1.1.1.1.1.1.1.1...
- Page 2 Pag. 22 WALK TEST Pag. 22 SENSITIVITY Pag. 23 DELAY Pag. 23 INSTALLATION GUIDE Pag. 24 sections Pag. 24 Particular conditions Pag. 25 MW TECHNICAL CHARACTERISTICS Pag. 25 Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 3 Do not install multiple beams where the transmitter beam can interfere with other receiver beams. It is always better place either transmitter or receivers back to back. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 4 N° Top cap IR cover Aluminium profile Aluminium base Motherboard IR Optics TX/RX Motherboard MW TX/RX Parable TX/RX Heather 10 Terminal block Supply board 12Vcc/24 Vac 12 DT3 Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 5 2. ASSEMBLING THE CABLEPIT Insert the highlighted edge into other section and fix with screws Insert the third section in the same way and fix with screws. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 6 Enlarge the two opposite walls of cable pit to allow the positioning of last section. Insert and well fix the missing screws. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 7 On the side that must be corrected loosen the insert in order to get the right inclination. CORRECT POSITIONING WRONG POSITIONING BY ADJUSTING INSERTS EXAMPLE OF SETTING Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
-
Page 8: Transformer Mounting
Place the plate in the cavity, especially left, so you can screw tighten the screws to the column and have enough space for the battery. Screw the 4 screws Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... - Page 9 Insert the sheath, the transformer then again the sheath and plate and fix everything with the nut. Follow the wiring instruction in the manual. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 10 13.8 Vdc Output for power infrared Power Connectors (terminal 8) 24 Vac Input to be connected to the transformer 24 Vac Output to be connected to the heaters Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 11 Output high impedance if the voltage supplied from the transformer terminals "24Vin" is <18Vac. 120Ω output if the voltage supplied from the transformer terminals "24Vin" is> 18Vac. Not connected Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
-
Page 12: Cables And Wiring
The cable dimension depends on the columns consumption and on the same cable resistance, taking care about installation distances. Cable 12Vcc (sync + signal) Cable 230Vac (culomn power) Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... -
Page 13: Connection To Power Supply
18/19 V ~ 1 A Secondary 24 V ~ 6 A Minimum power 160 VA In the case of greatly disturbed network add an effective filter - power supply 230V 1 A. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... - Page 14 Inside each column is provided space to house a rechargeable Lead up to 12V-7Ah. The battery is normally recharged by the internal supply, via a current limiter. FUSE A: 5A-24Vac FUSE B: 0,8A-13,8Vac Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 15 For more information, refer to "Manual ADEBUS EXPLORER" 7.1 Connection to serial port for each column MES9C MES9C column 1 column 2 ADEBUS Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
-
Page 16: Power Supply
The "channel selector" allows you to select the desired channel by DIP SWITCH switching to "ON". NB The selected channel must be the same as that of the Circuit "Rx”. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... - Page 17 LED CHANNEL indicates that the channel is tuned with the transmitter. indicates that the system is not in alarm (when there is the alarm LED goes LED ALARM off). Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
-
Page 18: Configuration Dip Switch
Display Value Sensitivity (0 to 9) SENS Display 0.2 ± 5V supply Display 0.2 ± 9V supply Display 13.8 ± 0.3 supply Input Voltmeter (to display items 5 ÷ 9) VOLT Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... - Page 19 L’altezza consigliata per installazioni di tipo classico è di circa 70 cm dal centro dell’antenna al suolo, con la sensibilità media impostata. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 20 70 cm from the center of the antenna to the ground, with the sensitivity set to medium. H equipment ground (cm) Maximum Minimum sensitivity sensitivity Length of the dead zone in meters Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 21 Vertical orientation: Loosen the screws of the handling system of the parable, and rotate. Verify that on the board RX the leds alarm and Channel are on. Otherwise proceed with the electronic alignment, however, be made to obtain a precise alignment. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 22 Test of the acrossing, making sure the intermittent sound of the buzzer and then the long beep and shutdown "LED Alarm" column on the Rx. Buzzer no signal Intermittent signal Fixed signal buzzer buzzer Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 23 The potentiometer adjustment of the delay (see page. 11, 12) affect the crossing speed. To verify the delay is necessary to experiment crossing at reduced speed. Remember that setting too high or low could cause false alarms Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
-
Page 24: Installations Guide
The following pictures show some typical cases for which the most correct solution is given. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... - Page 25 24 Ghz in K band CHANNEL 4 Exchengeable MODULATION ON-OFF SENSIBILITY ADJUSTMENT Trimmer. DELAY ADJUSTMENT Trimmer. ALIGNMENT Eletronic with instruments on motherboard OUTPUTS Alarm Relè (NC: 40 Ohm) Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 26 (TX=>RX) Negative sync input Negative sync - S IN 20 - S OUT (TX=>RX) output (TX=>RX) Not in use Not in use Not in use Not in use Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 27 The power of the heaters is by default set to 24 V (ac or dc), but you can set it to 12 VDC repositioning the jumper on MES9C and on each optical as shown. Heaters supply MES9C BOARD OPTICAL Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 28 2x0, 22, to connect the sync and the screens to negative Vdc of power supply on both columns. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 29 (terminal numbers are related to the image of p. 11). Canal RX 1 2 3 4 Canal TX 1 2 3 4 DIP4 in OFF 1 2 3 4 5 6 7 8 9 10 11 12 Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 30 4; the selected channel must be the same on both TX and RX boards. Note: for information and for other configuration of MES9012, please check page 27. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 31 COLUMN 2 COLUMN 1 Canal TX Canal TX 1 2 3 4 1 2 3 4 Canal RX Canal RX 1 2 3 4 1 2 3 4 Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
-
Page 32: Power On Led
The power of the heaters is set by default to 24V; you can use 12V by changing the configuration of the jumper (SW4). The voltage can be both AC and DC. Note: The settings and relative addresses are already set by Default. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... - Page 33 The voltage can be both AC and DC. In jumper J4 is possible to read the signal value in volts. Note: The settings relating to addresses are already set to Default. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 34 1 2 3 4 5 6 7 1 2 3 4 5 6 It should be set to ON the DIP on the motherboard RX exclusion 1 + 2 Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 35 Vertical adjustment Horizontal adjustment SCREW N.B.: FASTEN THE UNLOCKED SCREW AFTER THE ADJUSTMENT Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 36 3) Place the filter in front of the optic Transmitter you are aligning. It is recommended that the calibration with the use of the filter over long distances and then search for the maximum signal. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 37 (TX-RX) making sure that the orange LED TEST is shown in original condition. NB: you can SEE the calibration value through the multimeter on each optical receiver. For this procedure, you must have the pair of lenses (T-RX) in TEST. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 38 RX4 and proceed with the calibration as explained N.B.: during the testing phase of an optical transmitter the other TX not in test are switched off automatically. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 39 RX1 and proceed with the calibration as explained on p. 13 and 14. REPEAT the setting of RX2, RX3 and RX4. Make sure that it still aligned with RX1. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 40 HEATINGS LED Yellow SYNCHRONISM SYNC Yellow Response time TRIMMER adjustment TEST Function selector DIP SWITCH 12 (pag. 23) 10 TAMPER 11 DIP SWITCH TX 12 DIP SWITCH RX Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 41 Normally off, when turned on the heater is on. LED SINC The LED SINC continuously flashing indicates the proper operation Indicates the functioning of the and wiring of sync both outgoing and incoming. synchronism Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 42 In the ON position closes the RS485 communication. To finish you need to put in ON RS485 only the switches of the column as far as the entire line. LEDS In the ON position activates the LEDs. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 43 OFF Optical sync: operation with transmission frequency 4, only 2 transmitter active JUMPER J7 If the disqualification function is activeted, you can increase the sensitivity of the disqualification by jumper J7 Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
- Page 44 (ex. animals). Adjusting the potentiometer clockwise decreases the trip time until 50ms. In this condition ensures the alarm of a person crossing the barrier running at maximum speed Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
-
Page 45: Detection Area
AND Random / AND 1° + 2° beam / exclusion 1° o 1° e 2° 10. DT3 SECTION 10.1 DETECTION AREA Regolando opportunamente la sensibilità è possibile coprire completamente le zone morte immediatamente sottostanti e sovrastanti la parabola MW. Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... -
Page 46: Dip Switches
MW, by implementing crossover trials. The LED signaling GREEN will help to verify the detection of the passage in different areas (example. 1 m, 4 m, 8 m). Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... -
Page 47: Pet Immunity
Pet Immunity MW Digital signal processing Technology MW operation Self-diagnosis Programming Dip-Switches Microwave 24 Ghz MW adjustable range from 1m to 8m RF immunity up to 2Ghz Pet Immunity MW Digital signal processing Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2... - Page 48 24Vac Tx e Rx = 200W per column OUTPUT Alarm relay and Tamper relay OPERATING TEMP. - 25°C / + 65°C. SUPPLY 230Vac 50hz HEATERS 24 Vac (Internal supplier) ASSISTENZA TECNICA: +39 039 9081616 Politec Srl | Manual MANA DT SMA + DT3 – Ver 2.5.2...
