ENFORCER ST-BD01Q Manual

ENFORCER LOW-VOLTAGE BATTERY CUT-OFF

Troubleshooting:

• Power indicator LED not lit
• Voltage selector switch set at 12VDC but
dual-color DC LED is blue
• Voltage selector switch set at 24VDC but
dual-color DC LED is red
• No voltage present on DC connector
(male spade terminals)
• Dual-color DC LED is off
Also Available from SECO-LARM:
Voltage Converter Power Supply / Charger
Series
ST-LA110-TTQ
(shown)
Voltage Boosters Open-Frame Transformers
ST-HB105-TTQ
(shown)
WARRANTY This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM's obligation is
limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect,
repair, or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines
that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only,
at SECO-LARM's option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential
personal or property damages of any kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right
to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2012 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in
whole or in part, without the written permission of SECO-LARM.
®
SECO SECO- - - - LARM SECO SECO LARM LARM LARM U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
4
• Check to make sure AC power is on
• Check AC power input and output connections
• Check the main switch if it is on
• Voltage selector switch set at wrong setting
• Must have initial voltage from DC power supply or
Control Panel at DC connector to activate latching relay
Programmable Timer
Series Series
ST-2406-7A
SA-025Q
(shown)
Switching Power Supply
Series
ST-UV28-T350Q ST-UV12-S3.0Q
(shown)
Website: www.seco-larm.com
@
E-mail: sales seco-larm.com
SECO-LARM U.S.A., Inc.
(shown)
The ENFORCER ST-BD01Q Low-Voltage Battery Cut-Off prevents the deep discharge
of the backup batteries. The ST-BD01Q ties directly into most 12 or 24 VDC power
(shown)
supplies or alarm panels for easy plug-and-play installation. A Master ON/OFF switch
easily connects or disconnects the battery and AC power supply from the control panel.
• Selectable input 12/24VDC
• Adjustable voltage cut-off and restore point
• Master ON/OFF switch
PITSW1
MiST-BD01Q_1112.docx
Order Part# 763-163-2%
NOTE: Products with model numbers that end with "Q" or have a round green "Q" sticker are RoHS compliant.
ST-BD01Q
Low-Voltage Battery Cut-Off
Manual
• Green LED AC power indicator
• Dual-color DC LED indicator
• Includes double-sided tape
