FRENZEL UFGP0100BEU User Manual

Frenzel Video Goggles - Medical
REF: UFGP0100BEU
USER MANUAL
INTRODUCTION
Thank you for purchasing the μFrenzel® Video Goggles - Medical.
The μFrenzel® Video Goggles - Medical are designed for daily use
in hospitals and clinics. This reusable medical device allows
precise, real-time visualization of eye movements in complete
darkness. The removal of eye-fixation is critical to aid professional
medical doctors diagnose the following syndromes:
● Acute Vestibular Syndrome;
Benign Paroxysmal Positional Vertigo (BPPV);
●
● Ménière's Disease;
Migrainous Vertigo.
●
This manual contains several important health and safety
considerations, as well as important usage instructions.
Please read the latest version of this manual thoroughly before
using this medical device. You can find the latest version of this
manual in the μFrenzel site at www.ufrenzel.com.
INTENDED USE
The μFrenzel® Video Goggles - Medical are intended EXCLUSIVELY:
● for professional medical doctor use;
to aid diagnose the syndromes described above;
●
● to be used in hospitals or in medical clinics;
for adult patients.
●
KEY FEATURES
Figure A - Frenzel video goggles (front).
© 2018 μRoboptics®. All Rights Reserved.
A.1 - Single use disposable comfort Foam Pad
A.2 - Fixation strap
A.3 - Status LED
A.4 - Right LCD Screen
A.5 - Left LCD Screen
Figure B - Frenzel video goggles (side).
B.1 - 3.5mm Jack for Dual Analog Video Output
B.2 - 3.5mm/1.5mm 5V DC Charger Input
B.3 - ON/OFF switch
Figure C - Frenzel video goggles with comfort foam pad.
