FRENZEL UFG0100BEU User Manual

Frenzel Video Goggles
MODEL UFG0100BEU
USER MANUAL
INTRODUCTION
Thank you for purchasing the μFrenzel​ ® ​ video goggles.
The μFrenzel video goggles are designed for daily use in hospitals
and clinics. This reusable medical device allows precise, real-time
visualization of eye movements in complete darkness. The
removal of eye-fixation is critical to aid professional medical
doctors diagnose the following syndromes:
● Acute Vestibular Syndrome;
● Benign Paroxysmal Positional Vertigo (BPPV);
● Ménière's Disease;
● Migrainous Vertigo.
This manual contains several important health and safety
considerations, as well as important usage instructions.
Please read the latest version of this manual thoroughly before
using this medical device. You can find the latest version of this
manual in the ​ μ Frenzel​ site at www.ufrenzel.com.
INTENDED USE
The μFrenzel​ video goggles are intended EXCLUSIVELY:
● for professional medical doctor use;
● to aid diagnose the syndromes described above;
● to be used in hospitals or in medical clinics;
● for adult patients.
KEY FEATURES
Figure A​ -​ ​ F renzel video goggles (front).
A.1​ - Single use disposable comfort Foam Pad
A.2​ - Fixation strap
A.3​ - Status LED
A.4​ - Right LCD Screen
A.5​ - Left LCD Screen
B.1​ - 3.5mm Jack for Dual Analog Video Output
B.2​ - 3.5mm/1.5mm 5V DC Charger Input
B.3​ - ON/OFF switch
Page 1
© 2016 μRoboptics®. All Rights Reserved.
Figure B​ - Frenzel video goggles (side).
Figure C​ -Frenzel video goggles with comfort foam pad.
