BEFORE YOU BEGIN
BEFORE YOU BEGIN
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation . This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
·
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
·
These instructions contain important care, cleaning, and
warranty information-
consumer.
·
Before installation carefully inspect the new fixture for any
signs of damage.
·
This product complies with GB/T10357.4-2013,
GB/T10357.5-2013 and GB24977-2010.
WARNING:
Don't use acidic or alkalic cleaners or
alcohol to clean the surface. Use a dampened cloth to
clean.
CAUTION: Risk of property damage.
(not provided) rated for the loaded weight of this
product. Refer to the anchor manufacturer's
instructions.
ACCESSORIS LIST
ACCESSORIS LIST
Shelf Glass
255*115*6mm
2PCS
Tissue Box Assy
1PCS
ZHONGSHAN KOHLER SHOWER CO., LTD.
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA
1312244-T01-A
please leave instructions for the
Use anchors
Top Clips
Wall Anchors
4PCS
2PCS
·
·
·
·
·
GB/T10357.4-2013
GB24977-2010
Screw ST3.5X35
ST3.5X35
4PCS
NO13-1, XINYE ROAD, ZHONGSHAN TORCH
13-1
©
Copyright Kohler China Investment Co., Ltd. 2017
-1-
©
MAXISPACE
INSTALLATION INSTRUCTIONS
OPEN SHELF
GB/T10357.5-2013
Shelf Clip
Mounting Bar
1PCS
12PCS
POST CODE: 528437
528437
K-77217T
-
2017
