Lucci Fresco SENTINEL ADJUSTABLE WALL SPOT Installation Instructions

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.

Warranty

•
This luminaire is covered by a 12 month warranty. The warranty is from date of purchase, not the date of installation.
•
If the luminaire is not assembled and installed by a licensed electrician it will void the warranty.
•
Please retain proof of purchase and evidence of installation by a licensed electrician for any warranty enquiries.
•
Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
•
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the warranty

Installation Requirements

• Must be assembled and installed by a licensed electrician.
• All wiring and installation of the luminaire must adhere to the latest local and national wiring rules.
eg. AS/NZS 3000 Electrical installations.
• This luminaire is a Class I product and must be earthed during wiring and installation.
• Do not exceed the maximum wattage rating.
• Select a suitable location for installation:
−
The mounting point must be able to support 2 times the weight of the luminaire.
−
This This luminaire is protected against water penetration to IP65 standards, which is against low pressure jets
of water from all practicable directions. This must be maintained during wiring and installation.
• Take care not to pull any electrical wires during unpacking as this may damage the connection.
• Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or replacement.
• Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
• Ensure power to the circuit you are working on has been switched OFF before commencing any electrical work.

Installation Directions

1. Remove all packaging material from the product and be careful not to throw away accessories that may be hidden
within the packaging material. (Fig. 1)
2. Remove the back plate from luminaire by loosening the nuts on the front of the luminaire. (Fig. 2)
3. Use the back plate as a template to mark the screw positions on the wall. (Fig. 3)
4. Install the back plate on the wall by using appropriately sized mounting screws and anchors. Ensure the mounting
screws and anchors used are suitable for the mounting surface and the surrounding environment. (Fig. 4)
NOTE: A non-corrosive bead of silicon MUST be applied before installation onto the wall ensuring that no
water can run down into the cabling.
5. Connect the mains supply wire to the terminal block. Ensure the wires are secure and no bare wires are exposed.
Mains Supply Wire
Earth – Yellow/Green
Neutral – Blue or Black
Live – Brown or Red
6. Take note of the directional label and install the luminaire onto the back plate and secure by tightening the nuts at
the front of the luminaire. (Fig. 5)
7. Install a globe (not included) into the lamp holder. Do not exceed the maximum wattage rating. (Fig. 6)
8. Make any final adjustments to the luminaire and check that all parts are secured tightly before turning on. (Fig. 7)
1 | P a g e
SENTINEL ADJUSTABLE WALL SPOT
SKU# 230310, 230311, 230312, 239450
Rated Voltage 220-240V~ 50Hz
Luminaire Wire / Terminal label
Yellow/Green or
Blue or N
Brown or L
.
v 1 . 4 ( 1 0 / 2 0 1 9 )
