RadioPRO RP4.2-HY12 Quick Start Manual

Introduction & Features
The RP4.2-HY12 interface allows the replacement of a factory radio in the Hyundai Veloster. Using this interface will
retain factory features such as: steering wheel controls (SWC), secondary screens, reverse camera and factory SPDIF
audio amplifier (seperate part required, part # RPA-SPDIF) whenever the original radio is removed. Use of this interface
also allows you to program two radio functions to each SWC button by using short press long press dual command
functionality. The RP4.2-HY12 also provides data bus driven outputs such as vehicle speed sense (VSS), illumination,
reverse trigger and parking brake.

Important Notes

1. Does not retain Blue Link. You must use the RP5.2-HY12 to retain Blue Link.
2. The AUX connection in the RP4 harness will only provide sound if the aftermarket radio has a USB port. This is because the
USB port provides the power to make the factory USB/AUX port work. If you have connected the USB plug to your aftermarket
radio and it is still inoperable, this means that the aftermarket radio's USB port is not supplying enough current.
3. When using the RPA-SPDIF in factory amplified vehicles, you can adjust factory amplifier settings such as Bass, Mid, Treble,
Fader, Balance and Gain with the RadioPRO app found at www.pac-audio.com. Please refer to page 6 for detailed instructions
on the app and the functionality of this wire.
4. In vehicles equipped with auto climate controls, you will lose the fan mode, fan speed, auto status and temperature display.

Wiring Connection Chart

Interface Connector 1
Red Accessory Output
(10 amp)
Yellow
Black
Red Accessory Output
Pacific Accessory Corporation
Interface Connector 2
3.5mm Jack
Pink
12v+
Pink/Black
Ground
Blue/Yellow
Red/White
Orange/White
Pink
Violet/White
White/Black
White/Red
White
Orange/Black
Light Green
Blue/White
Pacific Accessory Corporation
SWC Output
MS-CAN + Input
MS-CAN - Input
SWC Output
12v+ Programmable
Output (1 amp)
Illumination Output
Vehicle Speed
Sense Output
Reverse Output
HS-CAN + Input
HS-CAN - Input
Analog SWC
Illumination Input
Parking Brake
Output (-)
Amp Turn On Input
| Ph. 866-931-8021 | support@pac-audio.com
®
©2015 Pacific Accessory Corporation
www.pac-audio.com
RP4.2-HY12
Radio Replacement &
Steering Wheel Control Interface
for Hyundai Veloster
Vehicle Connector
Yellow Battery +12v
Black Ground
Blue Power Antenna
Turn On Input
White Front L + input
White / Black Front L - input
Grey Front R + input
Grey / Black Front R - input
Green Rear L + input
Green / Black Rear L - input
Purple Rear R + input
Purple / Black Rear R - input
Yellow RCA Factory Reverse
Camera Video (if
equipped)
Rev. 101515
Page 1
