- Page 1 HEINE iC2 Funduscope ® HEINE Optotechnik GmbH & Co. KG Kientalstr. 7 · 82211 Herrsching · Germany Tel. +49 (0) 81 52 / 38 - 0 Fax +49 (0) 81 52 / 38 - 2 02 E-Mail: info@heine.com · www.heine.com...
- Page 2 Connecting the mounting case with the iC2 Insert the guide pins, attached to the mounting case, into the guide rails of the iC2 so it is firmly seated. Make sure that the mounting case is securely attached to the iC2.
- Page 3 If the device does not react, it can be reset by pushing the release button for 30 seconds. This procedure has no influence on the data of the iC2 app. Application duration The iC2 is intended for a transient application of less than < 5 minutes with a 15 minutes break until the next application. Charging Charging via USB Please connect the USB cord, which is attached to the power supply, to the micro USB charging port (3).
- Page 4 Apart from the charge indicator LED, the charging status can also be seen in the settings via the submenu ”iC2 Connection“. In addition, the charge status is indicated by a bar graph display in the picture capture mode. Charge the device outside of the patient environment (1.5 m).
- Page 5 Light exposure hazard Because prolonged intense light exposure can damage the retina, the use of the device for ocular examination should not be unnecessarily prolonged, and the brightness setting should not exceed what is needed to provide clear visualization of the target structures. The retinal exposure dose for a photochemical hazard is a product of the radiance and the exposure time.
