Onkyo RC-374M Quick Start Manual

Programming remote controller codes

Universal Programmable Remote Controller RC-374M
If you are using another manufacturer's product that has a remote controller, you can memorize that component's codes into the RC-374M.
NOTE:
•
The commands of Onkyo cassette tape decks and the CD player are already stored at the TAPE and CD positions of the remote controller.
•
This remote controller uses infrared rays. Most remote controller codes can be memorized using the infrared system; however, depending
on the degree to which the system differs, there may be some rare occasions when memorization is not possible.
SUBROOM
SENDING/
A B LEARN
LEARNED
SUR
TEST
POWER SLEEP DIMMER
TONE MODE
SOURCE SELECTOR MULTI-CH
DVD VIDEO-1 VIDEO-2 INPUT
TAPE-1 TAPE-2 TUNER PHONO C D
PROGRAMMABLE AREA TV/VIDEO
POWER C H VOLUME
POWER TV/VCR
TUNER
GROUP
PRESET
Symbol
POWER
C H
VOLUME
TV/VCR
1. SENDING/
LEARNED
indicator
2. A/B-SUB ROOM/
LEARN selector
switch
3. PROGRAMMABLE
AREA
VDP
POWER
PLAY
STOP
–
–
–
–
–
–
Displays and switches
1. SENDING/LEARNED indicator
This indicator acts as a guide when commands are programmed
into or sent by the remote controller. It also warns the user when
an error is made or battery power is low.
2. A/B-SUB ROOM/LEARN selector switch
A: Select MAIN to operate the system from the main room,
such as when playing a sound source using a Surround mode.
B-SUBROOM: Select SUB to operate the Onkyo Multi-Room
Remote System, the TX-DS555, and other brands' components
from the sub-room.
LEARN: Select LEARN to store another remote controller's
signal code.
3. Programmable button area
See the table below.

Device commands

VCR
POWER
PLAY
STOP
–
FAST REWIND
FAST FORWARD
–
Rec/Pause
–
TV
POWER
–
–
CHANNEL UP, DOWN
–
–
VOLUME UP/DOWN
–
TV/VCR switching
35
