- Page 1 A M18 08 EV M QuickStart Guide www.logicpd.com...
- Page 3 ZOOM AM1808 EVM QuickStart Guide We fast forward the evolution of new products.
-
Page 4: Table Of Contents
Table of Contents Introduction 1.1 Scope of Document 1.2 Zoom AM1808 EVM Development Kit Contents 1.3 Unpack the System 1.4 Baseboard Connection Diagram Development Kit Set-up 2.1 Connect the SOM-M1 to the Baseboard 2.2 Connect 4.3” WQVGA LCD 2.3 Ready for Demo Mode Next Steps 3.1 Register your Development Kit... - Page 5 Figure 2.4 – Proper SD Card Positioning Figure 2.5 – Insert SD Card Figure 2.6 – Connect Power Supply and Adapter Figure 2.7 – Connect Power to the Baseboard Figure 2.8 – Switch Power On ZOOM AM1808 EVM QuickStart Guide...
-
Page 6: Introduction
Congratulations on your purchase of the Zoom™ AM1808 EVM Development Kit. This Zoom Development Kit provides a product-ready hardware and software platform for evaluating the functionality of the Texas Instruments™ (TI) Sitara™ AM1808 processor and the Logic System on Module (SOM). -
Page 7: Unpack The System
Regulated 5 volt Null-modem Crossover Cable shown) Power Supply Serial Cable 4.3” WQVGA LCD User Interface (UI) Board Blackhawk USB100v2 JTAG Controller AM1808 SOM-M1 Application Baseboard Not shown: Software DVDs, SD Card, Screws & Nuts ZOOM AM1808 EVM QuickStart Guide... -
Page 8: Baseboard Connection Diagram
1.4 Baseboard Connection Diagram Figure 1.2 – Connection Diagram for the Baseboard ZOOM AM1808 EVM QuickStart Guide... - Page 9 R – General purpose user DIP switches (S2) S – Expansion connector T – JTAG header for TI processor U – Expansion connector V – JTAG header for ARM core (used with the Blackhawk USB100v2 JTAG Controller) ZOOM AM1808 EVM QuickStart Guide...
-
Page 10: Development Kit Set-Up
Align the SOM-M1 over the three BTB socket connectors in the center of the baseboard. See Figure 2.1. Figure 2.1 – Align the SOM-M1 over the Baseboard Press straight down on the SOM-M1, applying even pressure over the baseboard BTB socket connectors. See Figure 2.2. ZOOM AM1808 EVM QuickStart Guide... -
Page 11: Connect 4.3" Wqvga Lcd
To remove the LCD board from the baseboard, pull back on the ejector levers until the connector on the LCD board moves up and disengages from the baseboard 60-pin LCD connector. ZOOM AM1808 EVM QuickStart Guide... -
Page 12: Ready For Demo Mode
SD card should face up when viewing the top side of the EVM. See Figure 2.4. Figure 2.4 – Proper SD Card Positioning ZOOM AM1808 EVM QuickStart Guide... -
Page 13: Figure 2.5 - Insert Sd Card
Figure 2.6 – Connect Power Supply and Adapter Plug the power adapter into an electrical outlet and the 5V line output connector into the power-in connector on the baseboard. See Figure 2.7. ZOOM AM1808 EVM QuickStart Guide... -
Page 14: Figure 2.7 - Connect Power To The Baseboard
Move the power switch to the “ON” position. After a few moments, the 4.3” WQVGA LCD will display the demo. If the demo does not play, please refer to our "Troubleshooting" Section for common issues and their resolutions. Figure 2.8 – Switch Power On ZOOM AM1808 EVM QuickStart Guide... -
Page 15: Next Steps
3 Next Steps 3.1 Register your Development Kit Registration on Logic’s website provides you access to the latest revision of this QuickStart Guide, as well as other documentation and software tools. In addition to downloads access, registration provides future notifications when Logic releases documentation and software updates for your product. -
Page 16: Support & Product Ordering Information
Development Kit. These additional resources are available as downloads from the “My Account” section of the Logic website. Click on the “Log In” link at the top of any www.logicpd.com web page and enter your username and password to access the downloads available for your product. -
Page 17: Additional Support Services Available From Logic
Visit www.logicpd.com/product-support for complete descriptions, prices, and purchase options. Product Development Services Logic offers innovative product solutions covering every point in the product lifecycle, from product design and engineering to electronic manufacturing services. Please visit our website at www.logicpd.com for more information. -
Page 18: Product Notices
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user indemnifies TI and Logic from all claims arising from the handling or use of the goods. Due to the open construction of the product, it is the user's responsibility to take any and all appropriate precautions with regard to electrostatic discharge. -
Page 19: Troubleshooting
See Figure 2.4 and Figure 2.5 for pictures of the proper positioning. How do I contact Logic Technical Support? The best method for contacting Logic technical support is to fill out our “Ask a Question” web-based form: http://support.logicpd.com/support/askaquestion.php ZOOM AM1808 EVM... - Page 20 +Internal release 02/26/10 PN 1015143 +Official release 03/17/10 Please check www.logicpd.com for the latest revision of this QuickStart Guide and other documentation. AM, Sitara, and Code Composer Studio are registered trademarks of Texas Instruments Incorporated. ZOOM AM1808 EVM QuickStart Guide...
- Page 22 Logic Product Development makes no warranty for the use of its products. The Company assumes no responsibility for any errors which may appear in this document, reserves the right to change devices or specifications detailed herein at any time without notice, and does not make any commitment to update the information contained herein.
