Parts List
Part Number
Qty.
11431
1
Cord
15531
4
Grommet
91443
1
Strain Relief
91553
2
10/16 x 3/4" Self Tapper
D1736
4
10/32 Bolt
N0107
4
10/32 Nut
N0109
4
N0050
16
1/4-20 Nylock Nut
N0052
8
1/4 Washer
H0084 or H0085
120V or 240V Motor Brush Set
H0234
2
Locator Pad Bumper
H0236
1
3/8-16 x 15" All Thread Rod
H0237
1
3/8-16 Rivet Nut
N0050
4
1/4-20 Nut
H0244
4
1/4-20 x 9" Rod
H0246
1
3/8-16 Wing Nut
H0263
1
Hex Nut
H0291
3
10/24 x 1/2" Screw
H0292
4
10/24 x 3/4" Screw
H0293
3
10/24 Nylock
H0297
4
5/16-18 x 1/2" Screw
H0952
1
Foam Float
H0953
1
Filter
H0955
1
Shroud
H0956
1
Lid
H0957
1
H0958 or H0940
1
120V or 240V Motor
H0960
2
Handle
H0961
1
Filter Mounting Cage
H0963
1
Filter Support
H0964
2
Locator Pads
H0108
1
Lid Seal
H0968
1
Switch
H0972
1
Motor Support Plate
H0974
1
Intake Port
OM037_1016
Description
#10 Washer
Cap
H0292
N0052
H0968
N0050
H0244
N0050
H0972
H0084
or
H0085
H0964
N0107
N0109
D1736
H0291
H0974
H0293
H0956
H0108
H0263
H0952
H0961
H0957
N0050
H0955
91443
11431
91553
15531
H0958
or
H0940
N0050
H0237
H0963
H0234
N0052
N0050
H0960
H0297
H0236
H0953
H0246
Advertisement
Table of Contents
Related Manuals for Dustless Slurry Vacuum Series
Summary of Contents for Dustless Slurry Vacuum Series
- Page 1 Parts List H0292 H0957 Part Number Qty. Description 11431 Cord N0050 N0052 15531 Grommet 91443 Strain Relief 91553 10/16 x 3/4” Self Tapper H0968 H0955 D1736 10/32 Bolt N0107 10/32 Nut N0109 #10 Washer 91443 N0050 1/4-20 Nylock Nut N0052 1/4 Washer H0084 or H0085 120V or 240V Motor Brush Set...
- Page 2 WARRANTY: THREE-YEAR LIMITED WARRANTY – At Dustless Technologies, we stand behind what we build. We warranty this product, to the original retail purchaser, against defects in materials or workmanship for a period of (3) three years after date of purchase.
-
Page 3: Save These Instructions
IMPOrTanT saFeTY InsTruCTIOns IMPOrTanTes Mesures De seCurITe IMPOrTanTe Para su seGurIDaD SAVE THESE INSTRUCTIONS CONSERVER CES INSTRUCTIONS GUARDAR ESTA INSTRUCTIONES NOTE: The reading and understanding of the Owner’s Manual is imperative prior to operating this machine. If you or your operator(s) cannot read English, have this manual explained fully before attempting to operate this machine. - Page 4 Place vacuum on drum. Push hose onto the Remove entire contents of box. Check each item against the Parts List. (pg. 4) intake port. Plug in vacuum. Notify Dustless Technologies immediately if any parts are damaged or missing. ® The on/off switch is located on the shroud below the cap.
