- Page 1 Analog ALL IN ONE DVR Series Product Manual Digital Video Recorder Analog All-in-one 16 CHANNEL DVR Analog All-in-one 8 CHANNEL DVR Analog All-in-one 4 CHANNEL DVR Product Manual (EN Rev 1.3)
- Page 2 Product Manual Thank you for purchasing our Digital Video Recorder. Before installation or operation please become familiar with the user manual and other referenced manuals mentioned in the booklet. User manual, software and hardware described here are protected by copyright by law. With the exception of copying for general use within fair use, copying and reprinting of the user manual, either partially or in entirety, or translating it into any another language without the consent of our Corporate office is strictly prohibited.
-
Page 3: Table Of Contents
Contents Introduction 3 Warning 3 Main Specification by Models 4 Key Features 5 Components 7 Product Description 8 Installation 11 Connecting other devices 14 Appendix 19 Problem solving [FAQ] 19 Compatible HDD 20 Factory default set-up values 21... -
Page 4: Introduction
Introduction Warning Warning Please do not bend or press power cord by force which could lead to fire. Be careful not to pull or plug with wet hands to avoid fire or electric shock. In case of changing built-in lithium battery, it should be replaced with same brand or similar one to prevent a danger of explosion. -
Page 5: Main Specification By Models
Main Specification by Models Analog All-in-one Analog All-in-one Analog All-in-one Function 16 CHANNEL DVR 8 CHANNEL DVR 4 CHANNEL DVR HAC1630F HAC830F HAC430F SATA*2 SATA*1 SATA*1 HD-TVI HD-A Video Format SD/960H IP Camera Onvif, WESP Onvif, WESP Onvif, WESP SENSOR... -
Page 6: Key Features
Key Features Various video format of HD-TVI (1080P/720P), HD-A (1080P), 960H, NTSC/PAL, IP Camera (Onvif Profile-s) cameras can be SD : D1 displayed simultaneously. It supports real-time live monitoring and record/playback on various format and it records from 5 seconds before event and HD : 720p record up to 30fps per channel. - Page 7 SD 960H, NTSC/PAL 960H, NTSC/PAL cameras can be working with DVR. CoC (Control over Coax) PoC type camera can be controlled over coaxial cable using CoC function. PoC type camera of WEBGATE can be controlled and upgraded over coaxial cable without additional RS-485 cabling from DVR using CoC function.
-
Page 8: Components
Others User friendly GUI and mouse Easy and simple firmware upgrade, and recorded video back up function using USB stick Using Ac the PC Playback function, replay the DVR’s HDD on a PC (HDD set as RAID could not be played on the PC, even if HDD is connected to PC) ... -
Page 9: Product Description
Product Description Analog All-in-one 4 CHANNEL / 8 CHANNEL DVR Front view function description part name Shows record status while recording Blinking when network is used. It turns on when power is ON IR receiver Remote’s signal receiver USB port USB port for flash memory or mouse. - Page 10 Analog All-in-one 8 CHANNEL DVR Rear view Input and Output name Function Description Audio Input/output Audio Input : Audio input connection terminal Audio Output : Speaker output terminal ALARM IN (Sensor) ALARM IN: External sensor input terminal ALARM OUT (RELAY) ALARM OUT: Relay connection port Channel Input BNC input port for HD-TVI 1080p/720p, HD-A, SD 960H and NTSC/PAL video.
-
Page 11: Front View
Analog All-in-one 16 CHANNEL DVR Front view function description part name Shows record status while recording Blinking when network is used. It turns on when power is ON IR receiver Remote’s signal receiver USB port USB port for flash memory or mouse. Rear view Input and Output name Function Description... -
Page 12: Installation
Installation Check settings This DVR is high quality security device with a high capacity built-in HDD and important circuits. Before installation, please read carefully below recommendations as high internal temperature of the product can lead to damages and shorten product life cycle. Power ground Must connect the power cord to the grounded outlet. -
Page 13: Hdd Installation
HDD installation Analog All-in-one 4 CHANNEL / 8 CHANNEL DVR Loosen all screws on the rear panel Prepare a SATA type HDD Place the HDD on the DVR body Connect power and data cable to HDD Fasten the HDD with screws Place the cover and lock the screws <Note>... - Page 14 Analog All-in-one 16 CHANNEL DVR Loosen screws on the rear/side panel Place the HDDs on the DVR body Fasten the HDD with screws Connect power and data cable to HDD Place the cover and lock the screws <Note> It is highly recommended to use an DC 12V 5A adapter (option) to use a high capacity HDD with a power consumption of 6W or more.
-
Page 15: Connecting Other Devices
Connecting other devices VIDEO Output connection Support HDMI monitor having 1920X1080 and UHD/4K (3840X2016) resolution. Also, DVR can automatically detect the max resolution of HDMI monitor when the HDMI resolution is set to “UHD/4K (Preferred)”. So, if the monitor supports only FHD, the video output resolution will be FHD. If the monitor supports UHD/4K, the video output resolution will be UHD/4K. -
Page 16: Remote Control
Remote control Can use every function of the DVR. A type remote controller can control several DVRs with only one remote control. To be able to use the remote control, please create a user ID on the remote control ID section of system settings. - Page 17 Remote controller Type B...
-
Page 18: Connecting A Camera
Connecting a Camera Connect HD-TVI (1080P/720P), HD-A (1080P), 960H, NTSC/PAL camera using recommended cable. Please refer ‘Product Manual’ about supporting video formats for each models. Connecting a power cord When power cord is connected, DVR starts booting automatically. Connecting an audio RCA cable to connect audio input/output devices to DVR Connecting external device Connecting USB Device... - Page 19 Changing Booting Logo and Empty Channel Logo User can change the logo image for booting logo and empty channel (inactivated channel/unauthorized channel/unassigned channel) logo. Changing Booting Logo Copy the jpeg image file with the name “wgi_boot_logo.jpg” to USB memory. (Only 720x480 resolution supported) Insert USB memory to DVR and reboot after buzzer sounds.
-
Page 20: Appendix
Appendix Problem solving [FAQ] problem & symptom solution If system power isn’t on, LED on the Check the power of system system front won’t operate Check power voltage in out Check or replace power supply if power doesn’t turn on after above procedure No video on some channels with black ... -
Page 21: Compatible Hdd
manufacturer. Network setup using router is difficult. Please refer to product manual for details Please refer to UPnP section under “Network connection and setup” if a user is using router for network connection. Lost password. Please contact CS team of manufacturer. Copied data is not played in the PC. -
Page 22: Factory Default Set-Up Values
Factory default set-up values System Time Current time Time zone UTC +09:00 Seoul Date/time Daylight Saving Time (DST) Date Format Month/Day/Year Sync with NTP Overwrite Disk Block Playback Off / 5Day User admin Password 12345 User Setup Auto Login On / admin Additional User Setup Auto Log-Out Off / 1 Min... - Page 23 Restore after Event popup Edit Spot Auto Sequence Channel Cam 1~16 SEQ Rotation 1~16 Interval 5 (Sec) Edit “MULTI" Key Sequence “MULTI” Key Sequence VGA/CVBS output VGA output HDMI + VGA duplicate CVBS output Resolution HDM resolution UHD/4K(Prefered) VGA resolution 1920x1080 Event Activate...
- Page 24 Manufacturer might service at user’s cost for following request made by customer. Customer notice. Please make regular schedule to check unit status (Daily check is recommended). Manufacturer will not take any responsibility on the physical/human damage caused by robbery, natural disaster.
- Page 25 For requesting service? Please inform details of malfunctions correctly. Free or non-free repair will be decided based on details of warranty card. WebGate, Daemyung Corporation Co., Ltd. 6F Hanlim Venture Town B/D 284 Gongdanro Gunpo Gyeonggido, 435-862 Korea Main : TEL: +82-31-428-9300 Client Service: TEL: +82-1644-3421 The damage coming from following condition will be repaired at customer’s cost.
- Page 26 The W HDcctv Alliance Premium to your HD-CCTV W E B G A T E WEBGATE Daemyung Corporation Co., Ltd. 6F,Hanlim Venture Town B/D, 284, Gongdan-ro, Gunpo-si, Gyeonggi-do, Korea (15809) Tel +82. 31. 428. 9383 Fax +82. 31. 455. 3955 sales@webgateinc.com...
