HD-CCTV DVR
Full HD Digital Video Recorder
Hybrid DVR Series
User's Manual
(EN Rev 3.0)
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Webgate Hybrid DVR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Daemyung Webgate Hybrid DVR Series

Summary of Contents for Daemyung Webgate Hybrid DVR Series

  • Page 1 HD-CCTV DVR Full HD Digital Video Recorder Hybrid DVR Series User’s Manual (EN Rev 3.0)
  • Page 2 HD-CCTV DVR Install & User Guide HD-CCTV DVR Manual. Thank you for purchasing a Digital Video Recorder. Before installation or operation please become familiar with the user manual and other referenced manuals mentioned in the booklet. User manual, software and hardware described here are protected by copyright by law. With the exception of copying for general use within fair use, copying and reprinting of the user manual, either partially or in entirety, or translating it into any another language without the consent of our Corporate office is strictly prohibited.

  • Page 3: Table Of Contents

    Contents Introduction 4 Warning 4 Specification by Models 5 Key Features 6 Components 9 Product Description 11 Installation 19 Connecting other devices 23 Setup Wizard 30 Usage 32 FUNC Menu 32 Menu structure 32 Monitoring 34 Remote monitoring & control 39 Playback, Search and Copy 41 Playback 41 Screen composition/names of the functions 42...
  • Page 4 System Requirements 82 Login 82 Monitor 82 Playback 84 JAVA Viewer 86 System requirement 86 Installation 86 Login 86 Monitor 87 Playback 88 Mobile Application 89 registration method for iOS app 89 register method for Android app 90 Mobileviewer 90 Appendix 91 Problem solving [FAQ] 91 Compatible HDD 92...

  • Page 5: Introduction

    Introduction Warning Warning  Please do not bend or press power cord by force which could lead to fire.  Be careful not to pull or plug with wet hands to avoid fire or electric shock.  In case of changing built-in lithium battery, it should be replaced with same brand or similar one to prevent a danger of explosion.

  • Page 6: Specification By Models

    Specification by Models Product Name of Model Name EX-SDI EX-SDI Flame PoC/ Hybrid DVR Detection SPOT 16 Channel Full Case HS1620F-PD SATA*5 + PoC DVR eSATA 8 Channel Middle Case HSC821F-PD SATA*2 + PoC DVR eSATA 4 Channel Small Case HDC420F-PD SATA*2 PoC DVR...

  • Page 7: Key Features

    Key Features Hybrid Various video format of HDSDI (1080P/720P), AHD(1080P/720P)*, 960H*, NTSC/PAL*, EX-SDI (DoubleReach), IP Camera(Onvif SD : D1 Profile-s) cameras can be displayed simultaneously. It supports real-time live monitoring and record/playback on various format and it records from 5 seconds before event and HD : 720p record up to 30fps per channel.
  • Page 8 AHD * Products having AHD transmission technology where HD quality image can be transmitted over coaxial cable in analog signal format can be connected. NVR(Network Video Recorder)* Products support NVR function, so they support live monitoring, recording, playback, backup, remote control, push alarm and audio of connected IP camera (Onvif profile-S).
  • Page 9 Save and Backup You can record video data into the internal HDD, and image can be copied to USB memory.  Backup device : USB stick  External storage device : e-SATA HDD or NS04R (exclusive storage device)  Supports file system with up to max 128TB in case DVR and 8 x NS04R is connected in cascade Network Supports LAN, xDSL, and etc., and key functions can easily be controlled by web browser or customized CMS program.

  • Page 10: Components

    Components Please check the below to make sure you have every part. 16 CHANNEL FULL CASE POC DVR / 16 CHANNEL FULL CASE DVR / 16 CHANNEL FULL CASE RAID DVR Remote Control & Batteries Mouse power cord Rack bracket SD video input extension SW &...
  • Page 11 4 CHANNEL SMALL CASE POC DVR / 4 CHANNEL SMALL CASE DVR Remote Control & Batteries Mouse adaptor & power cord SW & Manual CD screw Quick guide...

  • Page 12: Product Description

    Product Description 16 CHANNEL FULL CASE POC DVR / 16 CHANNEL FULL CASE DVR / 16 CHANNEL FULL CASE RAID DVR Front view function description part name Power turns ON/OFF the power It turns on when power is ON Shows record status while recording EVENT Turns on if event is triggered Shows network connection status and it flickers if network is connected...
  • Page 13 part name function description HDMI Output HDMI monitor connection output port Ethernet, Storage Ethernet : network connecting terminal (RJ-45) VGA Output VGA monitor connection output port. PoC power input Socket for PoC adaptor connection. SD channels input BNC input port for 960H, NTSC/PAL cameras. 16 CHANNEL FULL CASE DVR / 16 CHANNEL FULL CASE RAID DVR Rear view part name...
  • Page 14 8 CHANNEL MIDDLE CASE POC DVR / 16 CHANNEL MIDDLE CASE DVR / 8 CHANNEL MIDDLE CASE DVR Front view function description part name Power turns ON/OFF the power It turns on when power is ON Shows record status while recording. EVENT Turns on if event is triggered Shows network connection status and it flickers if network is connected...
  • Page 15 part name function description eSATA port For connection with external eSATA HDD. Channel Input HD-SDI(1080P/720P), 960H, NTSC/PAL, EX-SDI (1080P/720P) cameras HDMI Output HDMI monitor connection output port Ethernet Ethernet : network connecting terminal (RJ-45) VGA Output VGA monitor connection output port. PoC power input Socket for PoC adaptor connection.
  • Page 16 8 CHANNEL MIDDLE CASE DVR Rear view part name function description Power Input Connection socket for DC 12V power code Ground Connection Connection terminals that connects DVR to an outside device SPOT Connection port for SPOT monitor Audio Input/Output Audio Input : Audio input connection terminal Audio Output : Speaker output terminal Sensor, Relay,...
  • Page 17 4 CHANNEL SMALL CASE POC DVR / 4 CHANNEL SMALL CASE DVR Front view part name function description It turns on when power is ON Shows record status while recording. Shows network connection status and it flickers if network is connected USB Port USB port for flash memory or mouse.
  • Page 18 4 CHANNEL SMALL CASE DVR Rear view part name function description Power Input Connection socket for DC 12V power code Ground Connection Connection terminals that connects DVR to an outside device SPOT Connection port for SPOT monitor Audio Input/Output Audio Input : Audio input connection terminal Audio Output : Speaker output terminal Sensor, Relay,...
  • Page 19 Remote control Can use every function of the DVR and control several DVRs with only one remote control. To be able to use the remote control, please create a user ID on the remote control ID section of system settings. (See the right picture for working angle of a remote control) Remote controller...

  • Page 20: Installation

    Installation Check settings This DVR is high quality security device with a high capacity built-in HDD and important curcuits. Before installation, please read carefully below recommendations as high internal temperature of the product can lead to damages and shorten product life cycle. Recommendations on installing a DVR in a rack.
  • Page 21 HDD installation 16 CHANNEL FULL CASE POC DVR / 16 CHANNEL FULL CASE DVR / 16 CHANNEL FULL CASE RAID DVR 1. Unscrew bracket screws that are fixing it to a DVR.. 2. Push HDD bracket to a direction shown in the right picture and separate from fixtures.
  • Page 22 5. Place HDD bracket fastened with screws in DVR and fasten it on the bottom with screws. <Note> Below is SATA cable socket sequence of a mainbaord. Up to 5 HDDs can be installed inside DVR. Main Board Disk Manager INT A INT A INT B...
  • Page 23 4 CHANNEL SMALL CASE POC DVR, 4 CHANNEL SMALL CASE DVR 1. Install HDD and hold HDD using screw. <Note> Arrange of SATA cable socket is as follows. 2ea of HDDs can be installed in DVR. Main b’d socket Disk manager INT A INT A INT B...

  • Page 24: Connecting Other Devices

    Connecting other devices Basic connections HDMI Monitor connection 1920X1080p resolution is suppoeted. Please check if monitor can support this resolution before connection.  DVR output resolution : 1920 x 1080p <Note> We strongly recommend using HDMI certified cable when connecting to DVR. VGA Monitor connection VGA output supports main monitor output (HDMI duplicate) or SPOT monitor output.
  • Page 25 <Note> PoC models need additional “SD input video extension cable” in case 960H, NTSC/PAL type cameras are connected and viewed. Transmission Distance Table by Cable types * Cable Types HD-SDI EX-SDI 1.0 EX-SDI 2.0 5C-HFBT(7) (CW/AL) ~ 200M ~ 600M ~ 700M 5C-HFBT(4) (CW/AL) ~ 150M...
  • Page 26 Connecting eSATA Device If external eSATA storage is used, it can be connected to a rear eSATA port. Additional power for eSATA device will be required as DVR doesn’t supply power.. <Note> 1. Check compatibility of eSATA with DVR as not all eSATA are compatible with DVR. 2.
  • Page 27 Connecting relay specifications Please see the below table for alarm output requirements. Output Ch. * 4ch relay output Output type Dry Contact Specifications Connection Connect the trimmed wire to terminal block method 24V / 1A Performance 125V / 0.5A * Varies between different models Connecting relay Please refer to the below picture in regards to connecting R1~R4 output.
  • Page 28 Connecting Serial Port for Transparent device Keyboard Device Text Device Dome Camera COM1 Keyboard Device COM2 PTZ Receiver Connecting PTZ & Keybaord up to 255 DVRs can be connected using keyboard and PTZ control is possible for all channels connected to DVR. Also, multiple keyboards extension as Slave can be used limitless with Master Keyboard.
  • Page 29 The below diagram represents configuration of multi DVRs with PTZ(DOME). To control PTZ(DOME) using keyboard, please select DVR ID then select camera for control. control device connection device Keyboard (Master/Slave) All DVRs can be controlled, all PTZ(DOME) can be controlled PTZ(DOME) directly connected to DVR can be controlled Confituration using 1 serial ports When using 1 serial port, user can connect both of PTZ(DOME) and Keyboard to a port, and user can select a...
  • Page 30 Changing multiple channel names using USB memory Please make new text (*.txt) file using PC and describe the names of channels in the following format. You can skip channels you don’t want to change. CH1:Door CH3:Exit Please save the text file with the name “wgi_channel_name.txt” and MUST select the letters encoding as UTF-8.

  • Page 31: Setup Wizard

    Setup Wizard Setup Wizard can help user setup “language, network, DDNS, time, harddisk, record mode” with ease. It runs automatically when DVR boots initially. User can run Setup Wizard on “Menu > System > Tool > Setup Wizard”. Start Select language and choose whether to use Setup Wizard or not. Network Set up IP address of DVR or skip network setup.
  • Page 32 Time and time zone Setup time, standard time zone and daylight saving time(DST). Network(NTP) autotime synchronizing 1) In case DVR is connected to internet – In use 2) In case DVR is not connected to internet – Not in use Daylight saving time(DST, summer time) 1) DST saving time is used –...

  • Page 33: Usage

    Usage FUNC Menu All DVR functions can be controlled by using Mouse. To open FUNC menu, click the mouse’s right button at live or playback screen. FUNC menu at Live screen Search - Recording data Search/Playback  Copy – Copy recorded data ...
  • Page 34 Menu Structure Press [MENU] key on front panel or click [Main Menu] button under FUNC menu to enter the setup menu. To exit menu, press “X”. Main menu The selected tab is shown in bright color and the sub-menu box will show the chosen Sub-menu Selected sub-menu will disply the chosen item and the related setting will be shown.

  • Page 35: Monitoring

    Monitoring Basic screen The basic screen will be maximum multi screen DVR supports and if rebooted after multi-screen mode has been modified, previous multi-screen mode will be shown. (DVR default account admin / 12345) <Note> The default password is very weak for security. It is highly recommended that user must change the password periodically.
  • Page 36 Auto switch mode(Sequence) Auto switch screen mode is a feature in which the selected channel or multi screen division switches in sequence with the time interval of 1 – 60 seconds. (Please refer to “Monitor setup” for further configuration method). Auto Switch mode can be set in every division mode by pressing the [SEQ] button.
  • Page 37 Enlarged screen Using D-Zoom on a single screen, users can enlarge the section they want to view.. Click on [Zoom] button or icon in single / full screen or [FUNC] button then select Zoom button to activate Zoom mode. To expand or reduce, please use +, - button or use mouse wheel drag.
  • Page 38 When PTZ is on, through PTZ button on front or PTZ buttons under FUNC menu, users can use pan/tilt, zoom, focus, aux, preset functions and Patrol. Pan/Tilt pan/tilt function for PTZ configuration channel Use “Up”, “Down”, “Left”, “Right” to control pan/tilt. Zoom Click “In”, “Out”...
  • Page 39 Camera Setup This menu is used to enter the menu of connected PTZ device. Please control PTZ device menu using up, down, left, right. <Note> OSD can not be controlled for IP camera (Onvif) channel. Please use webpage of IP camera to control OSD. Bookmark Add / Edit bookmark No, Time, Channel and Memo in [Tool-Bookmark] of FUNC menu while live or playback.

  • Page 40: Remote Monitoring & Control

    Remote monitoring & control Users can connect DVRs, control and monitor it remotely by using Control Center (CMS program) Installation of Control Center Execute “Control Center Setup vx.x.x.exe” to install the Control Center. Start of Control Center After installation is completed, click “Control Center Monitor” icon and execute it. (ID : admin / Password : admin) Screen configuration of Control Center Item...
  • Page 41 Add Unit Click [Add] icon on the toolbar or execute [Add Unit] by clicking mouse right button at “My Units”. 1) Select “URL/IP Adress” 2) Enter proper IP address and Port, then click [Find] button. If the DVR is located inside local network, you can easily find the DVR by clicking [Auto Detect] button.

  • Page 42: Playback, Search And Copy

    Playback, Search and Copy Playback Playback with Basic Screen  In monitoring mode, Remote control Press [◀/▶] button to playback the recorded video in full screen  If [PLAY] button is pressed, the last playback will run at 1x speed. ...

  • Page 43: Screen Composition/Names Of The Functions

    Screen composition/names of the functions Screen composition name function description Playback button Use buttons to control the playback. screen Displays the playback videos. log viewer Displays the log seen on timeline Calendar/time Select a date on the calendar to view the data of the date. search timeline Displays the info of the unit and search the playback sections.
  • Page 44 Time search If the user enter a date and time and click , DVR’s playback time moves to that time. Calendar search When calendar search is run, it marks the dates on which there were recordings. Select a date from calendar you want to search, and it moves to that date.

  • Page 45: Copy

    Copy This is for copying recorded videos. There are 2 types of copying, EXE, and AVI. Only authorized users by security settings can use the Copy function. For more about authority settings, please refer to (user setup) section. To run copy function, press [COPY] on the Remote control or Click Copy button under Function menu. If a user runs copy menu during playback, playback time will be set as backup start time.

  • Page 46: Configuration

    Configuration System configuration Please set time/disk/authority. Date/time menu  system  date/time Before recording setting, DVR has proper time information. DVR has ‘UTC +09:00 Seoul’ as default time zone. <Note> 1. To search DVR’s recording data properly, DVR should have exact time zone information.

  • Page 47: Disk

    menu  system  date/time  Network Time Protocal(NTP) NTP (Network Time Protocol) synchronizes the time of all connected device. To set DVR time to standard time open server which offers standard time on the network and client which is connected to open server to receive time and synchronize it with standard time.
  • Page 48 Recorded part for 2 days. Record during 10 days. Record during 10 days. Start record In progress of record Start record In progress of record [Picture 1] [Picture 2] Data deletion This function allows only recordings of preassigned date to be viewed. For example, if playback block is set at 3 days, then DVR will only save data for 3 days and will delete data more than 3 days old even if auto-deletion isn’t on.
  • Page 49 Recommended network configuration (1) In case of NS04R is being used, we recommend customized hub(or switch) used only for DVR and NS04R’s connection. Hith bandwidth is required for communication between DVR and NS04R so to secure stable operation it will be good to separate connection from normal network. (2) In case of multi NS04Rs connection to single DVR, rest of NS04R is recommended to be connected in Cascade method to NS04R initially connected to DVR.
  • Page 50 name Function description type Displays the location and types of a disk. Int A (internal A HDD), Int B (internal B HDD), eSATA (external HDD), USB model Displays HDD model. BAD block Highlights the HDD with BAD block. 0 is shown when there is none. For HDDs not in use, no bad block is displayed.
  • Page 51 Refer to the below table for supported RAID level.  HDD # Possible Level Actual # for recording Capacity * RAID 1 100% (480fps) RAID 5 66% (320fps) RAID 10 100% (480fps) RAID 5 66% (320fps) * To use RAID without lowering performance of DVR, configure RAID only with NS04R How to deal with a problem occurred? If a problem was occurred during RAID operation, RAID manager will appear, and the faulty HDD state ...
  • Page 52 ID & password change For User 1~10, max 20 and 8 characters are allowed for ID and Password. <reference> Default manager Password is “12345” and for user 1 ~ 10, password will take a pattern of “11111” for user 1, “22222” for user 2 and so on. So user 10 will have a password of “00000”.
  • Page 53 System Information It shows DVR system’s information. System information includes model name, firmware version, hardware version, U-boot version, serial number, MAC address, camera type, HDD capacity, remaining HDD capacity. System log System log shows the log list of system booting, user login, setting changes.
  • Page 54 Video Status It shows status of record per channels of DVR. Factory reset Change all set up values to default values. Only a manager can use this function. <Note> Only a DVR system manager can use this function. Refer to the (supplement – factor default value) for the factory reset. Configuration Import/Export Export –...
  • Page 55 NTSC/PAL Setup NTSC/PAL mode of the DVR. • NTSC-DVR is running on NTSC(60/30Hz) fixed mode • FAL-DVR is running on PAL(50/25Hz) fixed mode • Auto-DVR can recognize input format of camera Then DVR is set NTSC or PAL mode automatically <Note>...

  • Page 56: Network

    Network Configure network info when DVR is connected to a network. Network settings menu  network  network  Ethernet Select DVR’s network type between Ethernet or XDSL. Ethernet Select ‘Ethernet’ when the DVR is connected with dedicated line, cable modem or LAN environment. xDSL Select ‘xDSL’...
  • Page 57 Port Register port # in DVR and use it to connect to control center or webviewer. <Notice> Default port is 80 and be careful in entering the port # when used with PPPoE modem and router. To use port forwarding & UPnP port forwarding, network port change (e.g. 8000) might be necessary. Please ask this information to network administrator.
  • Page 58 P2P * Input UID of P2P connection information in mobile application (Android or i-phone) or scan QR code. Remote network connection can be made easily without further configuration. Adopted differently based on product specification DDNS DDNS setting at a DVR Menu ...
  • Page 59 Custom DDNS Also, users can use public DDNS sites such as www.dyndns.org or www.no-ip.org. Users should refer to those sites directly to get the registration process. <Note> Connection will be enabled in about 10 minutes after domain creates. Menu  Network  WRS If a DVR is connected to cable modem or xDSL modem, ISP(Internet Service Provider) may change DVR’s IP address unexpectedly .
  • Page 60 xDSL menu  network  network  xDSL DVR is connected to xDSL line and use PPPoE type, please change type by xDSL and configure user ID and Password. User ID and Password should be same as xDSL. User ID/Passwor Configure user ID and Password when DVR is connected to xDSL.

  • Page 61: Devie Settings

    Devie Settings In Device setup, user can configure camera, monitor, audio, text, serial which are connected to DVR. Camera menu  device  camera Conditions on camera connected to DVR can be set. Name Naming per channels. <Note> To disable channel for live/recording, please make check box blank Type Image through coaxial cable is selected.
  • Page 62 IP Configuration IP camera or other DVR’s channel can be configured. To register IP camera: 1. Select Protocol. 2. Click “Search Local IP Camera” button. It will show the list of IP camera and DVR connected in the same network. 3.
  • Page 63 Menu  Device  PTZ Port Choose one of COM2/COM3/CoC* Device Select a device that is connected to the port. Address Select the device’s address that is connected to the port. Baudrate Select the device’s baudrate that is connected to the port. <Note>...
  • Page 64 Patrol Config • Preset: Set the sequence of presets. • Interval(Sec): Set the interval of each preset. After interval time, PTZ is moved to the next preset position. The range of interval time is 1 ~ 255 sec. • Preset Rotation: Setting the preset number to rotate. If you set "5", patrol will be operated from "preset"...
  • Page 65 Multi set-up Select multi screen order through multi set-up. Maximum of 16 screens can be set-up. VGA/Analog output* VGA(HDMI duplicate) + Analog(Spot) VGA output is the same with the HDMI output and analog output is used as Spot. VGA(HDMI duplicate) VGA output is the same with the HDMI output.
  • Page 66 Spot Sequence User can edit the sequence of Spot. It support max. 16 sequence rotation. Sequence interval can be set as 5~60 sec. To excute the Spot Sequence function, click [FUNC Menu – Tools – Spot] and check the “Turn on SPOT” box. Audio menu ...
  • Page 67 Text menu  device  Text Configures text info and click “Text” to configure the text. Max 5 text can be connectable using USB to serial cable. Recording Set On/Off of recording of Text input. Video Ch Select channel to synchronize with text. Device Choose from Manual, Star Finger 007, VSI Pro, VSI Hydra for text input device.

  • Page 68: Event Configuration

    Event Configuration Event menu  event  event Event set up has 4 set up procedures, event, motion, sensor, and preset. event configures time range with event synchronization and can be configured as off, always, and custom “always” recognizes and reacts to event when it is configured. “custom”...
  • Page 69 Sync event Configuration for Event synchronization Relay When events that have been selected in “Event Sources” occur, event notification by relay goes on for the time period set in “Action time” Buzzer Event notification by buzzer goes on for the time period set in “Action time”.
  • Page 70 EVENT SOURCES Check Sensor, Motion detection, Text or systems for activating event. System event sources of HDD Fail, RAID fail, fan fail, password fail, WRS registration fail, power on and recording fail can be checked (some or all) HDD Fail Event notification for HDD performance problems or connection status problems.
  • Page 71 Authentification There are a few ways to send email (No authentification, SMTP server authentification and TLS authentification.) • No authentification: sends email to the recipient address without server authentification • SMTP authentification: sends email to the recipient after SMTP server authentification. The recipient address must support SMTP authentification •...
  • Page 72 User area When selecting a channel, user area can be configured. 1 grid size is 15x10 and factory default value is “All grid selected”. Press “change area” button to open motion detector enabled area set up window. Users can set motion detection area in screen. The motion detection zone by setting is indicated in translucent green.

  • Page 73: Recording Set Up

    Recording Set Up Record mode has 3 types as normal/event, schedule/event, emergency record. Normal/Event record – Record start up upon bootup according to defined program.  Schedule/Event record – Record start up upon defined schedule’s program and time.  Emergency record – Record at max setup regardless of record mode and program. It can be turned on ...
  • Page 74 • Program : Set recording program(A~I) • Time : Set time to apply • Add : Schedule registration • Delete Selected : Delete a schedule • Delete All: Deletes the all schedules deletion • Delete selected schedule – Select schedule to be deleted then click on delete button. Click on delete button without select item, previously selected item will be deleted first and deletion will be achieved in reverse of time set up.
  • Page 75 Event Record Select frame rate (number of frame per second) and quality that are applied when event occurs. When event occurs DVR starts to record by the frame rate and quality of Event Record. FPS (frames per second) users can select 1 to 30fps per second. Max. Frame can be changed according to the configuration.

  • Page 76: Webviewer

    WebViewer WebViewer is Web application program loaded to monitor real-time image or to monitor the images recorded through Web browser to PC located remotely. System requirement Recommendation Items Core i5 3.0GHz Main Memory 512MB or higher Video Memory 1024MB PCI-E Graphic Card Support AGP Accelerate (AMD Radeon HD 7000 Series or Display Higher) Support PCI-E 16X or higher...

  • Page 77: User Set Up

    User set up To access WebViewer, user authority and password can be changed in DVR or the account menu of Control Center configuration. Monitor When it is authorized with User ID & Password input at Login page, it moves to monitor page. At Monitor page, monitor real time image of cameras connected to DVR, or it can control PTZ camera, Relay, and use Microphone function according to user’s authorization.
  • Page 78 At division screen, it can change screen location using mouse drag If Ch3 image moves to Ch1, drag Ch3 image and drop on Ch1 location so as to exchange between 3ch and 1ch image. Press the very front icon on the upper screen on multi screen mode to switch to a full screen mode. To go back to normal screen mode from full screen mode, press ESC key Move to Playback Click the...
  • Page 79 video recording & save video recording Select by clicking “Rec Start” in right button of Mouse after selecting channel user wants to record during monitoring. It can record max. 10 minutes of video During Quick Recording, recording time is indicated on video. If “Rec Stop”...

  • Page 80: Playback

    Using Audio In case of Channel setup sync with Audio, press right mouse button on the image to activate pop- up menu to “Listen” and uncheck Mute. Audio Volue adjustment is available using slide bar. Playback This page is to playback recorded images, and user who has authority of ‘HDD’...
  • Page 81 Print Select image with mouse for the channel to print image saved, and then click ‘Print’ button. Window comes to input Memo, and click ‘OK’ button to print the image through the printer connected. Print material includes ‘Printing Date’, ‘Channel name’, ‘Recording Date’...
  • Page 82 Calendar search Recorded date is enabled in black color, and others unrecorded date disabled in grey. Click [Go to] button after select date & time so as to playback images on the date & time selected. ‘When clicking the ‘Go To’ button, it indicates for 24hours from the time selected at left bottom.

  • Page 83: Html5 Webviewer

    HTML5 Webviewer HTML5 is the new technology which does not require any active-x or plug-ins and is not depend on OS. DVR supports HTML5 webviewer which can monitor the DVR with web browsers supporting HTML5. System Requirements Items Recommended Core i5 3.0GHz Main Memory Video Memory 512MB or higher...
  • Page 84 Screen Division At initial monitor page, all video channels will be shown with the maximum division. The number of video channels will be depend on the DVR model. You can change the screen division mode by clicking Icon. Single Division Double click the video channel to see with single division mode.

  • Page 85: Playback

    Playback By clicking icon at the top, user can playback the DVR’s recorded video. Note that only authorized users for playback/search can use playback function. At initial playback page, all video channels will be shown with the maximum division. The number of video channels will be depend on the DVR model.
  • Page 86 Timeline Timeline shows the recording status including event information. Timeline with grey means ‘no event’. Timeline with yellow means that motion is detected. Timeline with red means that sensor is input. <Note> Only x1 forward playback and pause are supported. Backup User can backup by clicking icon.

  • Page 87: Java Viewer

    JAVA Viewer Jave Viewer supports DVR monitoring function regardless of operating system. System requirement Recommendation Items Core i5 3.0GHz Main Memory Video Memory 512MB or higher Display 1024MB PCI-E Graphic Card Support AGP Accelerate Support PCI-E 16X or highter Network 100/1000 Ethernet NIC Windows 7 / Windows 8 / Windows 10 / OS X Mavericks (version 10.9) Installation...

  • Page 88: Monitor

    Monitor When it is authorized with User ID & Password input at Login page, it moves to monitor page. At Monitor page, monitor real time image of cameras connected to DVR, or it can control PTZ camera, Relay, and use Microphone function according to user’s authorization.

  • Page 89: Playback

    Playback Click [ ] to run playback. Playback is page, where only Authorized or user account assigned with right for [playback/search] can use. Playback can be controlled by search, time shift button or click on time line. Calendar search Recorded date is enabled in black color, and others unrecorded date disabled in grey.

  • Page 90: Mobile Application

    Mobile Application Mobile application is supported for Smart Phone (Android and iOS). It is available to serach and install as free of charge in Apple App store & Google Android Store. (Please refer 5 page to find out the name of application.) ...

  • Page 91: Register Method For Android App

    register method for Android app URL register 1. Touch “+” button after application installed. 2. Select URL in category. 3. Touch “Find” button then there’s unit name and IP address shown. Touch save button to finish unit register. 4. Touch unit created to enter unit’s screen. WRS register 1.

  • Page 92: Appendix

    Appendix Problem solving [FAQ] solution problem & symptom If system power isn’t on, LED on the  Check the power of system system front won’t operate  Check power voltage in out  Check or replace power supply if power doesn’t turn on after above procedure No video on some channels with black ...

  • Page 93: Compatible Hdd

    “HDD FAIL” icon and error message  Please check HDD connection status. pops up. Please contact local dealer if this message continues to pop up even if there is no problem in connection. There is no added information of HDD ...
  • Page 94 Daylight Saving Time (DST) Date Format Month/Day/Year Sync with NTP Overwrite Disk Block Playback Off / 5Day User admin Password 12345 User Setup Auto Login On / admin Additional User Setup Auto Log-Out Off / 1 Min Auto Lock Off / 1 Min DVR Alias DVR0 Language...
  • Page 95 Event Check Always Check Event Synchronization Buzzer Email Video Popup System Alarm Always on event Motion Detection Inactivate Video Loss Inactivate System All check Camera Preset Alarm Push E-mail Setup Recipient Address 1 receiver@gmail.com Recipient Address 2 Recipient Address 3 Sender Address dvr1@dvr.com Subject...

  • Page 96: Product Specification

    Product specification 16 CHANNEL FULL CASE POC DVR VIDEO INPUT AUDIO HD-SDI (SMPTE 292M), EX-SDI Input/output 4 RCA input / HDMI & RCA output Video input / Format D-SUB Analog 960H/SD Compression ADPCM (32Kbps, 8KHz, 16bit sampling) Onv if Prof ile-S Direction Both 1920x1080 / 25, 30f ps...
  • Page 97 8 CHANNEL MIDDLE CASE POC DVR VIDEO INPUT HD-SDI (SMPTE 292M), EX-SDI 41 models including C1080(D1080), C1080PT-Z20, Pelco-D, Protocols Video input / Format D-SUB Analog 960H/SD Pelco-P, Samsung, Panasonic and others Onv if Prof ile-S NETWORK 1920x1080 / 25, 30f ps Interf ace 1 Gigabit Ethernet (10/100/1000Mbps) HD-SDI/EX-SDI...
  • Page 98 4 CHANNEL SMALL CASE POC DVR VIDEO INPUT NETWORK HD-SDI (SMPTE 292M), EX-SDI 1 Gigabit Ethernet (10/100/1000Mbps) Video input / Format Interf ace Onv if Prof ile-S Static IP, Dy namic IP, xDSL, UPnP, RTSP 1920x1080 / 25, 30f ps DDNS WNS, Dy nDNS, NoIP, WRS HD-SDIEX-SDI...
  • Page 99 16 CHANNEL FULL CASE DVR VIDEO INPUT HD-SDI (SMPTE 292M), EX-SDI 41 models including C1080(D1080), C1080PT-Z20, Pelco-D, Protocols Video input Format AHD 2.0, Analog 960H/SD Pelco-P, Samsung, Panasonic and others Onv if Prof ile-S NETWORK 1920x1080 / 25, 30f ps Interf ace 1 Gigabit Ethernet (10/100/1000Mbps) HD-SDI/EX-SDI...
  • Page 100 16 CHANNEL MIDDLE CASE DVR VIDEO INPUT HD-SDI (SMPTE 292M), EX-SDI 41 models including C1080(D1080), C1080PT-Z20, Pelco-D, Protocols Video input Format AHD 2.0, Analog 960H/SD Pelco-P, Samsung, Panasonic and others Onv if Prof ile-S NETWORK 1920x1080 / 25, 30f ps Interf ace 1 Gigabit Ethernet (10/100/1000Mbps) HD-SDI/EX-SDI...
  • Page 101 8 CHANNEL MIDDLE CASE DVR VIDEO INPUT HD-SDI (SMPTE 292M), EX-SDI 41 models including C1080(D1080), C1080PT-Z20, Pelco-D, Protocols Video input Format AHD 2.0, Analog 960H/SD Pelco-P, Samsung, Panasonic and others Onv if Prof ile-S NETWORK 1920x1080 / 25, 30f ps Interf ace 1 Gigabit Ethernet (10/100/1000Mbps) HD-SDI/EX-SDI...
  • Page 102 4 CHANNEL SMALL CASE DVR VIDEO INPUT HD-SDI (SMPTE 292M), EX-SDI 41 models including C1080(D1080), C1080PT-Z20, Pelco-D, Protocols Video input Format AHD 2.0, Analog 960H/SD Pelco-P, Samsung, Panasonic and others Onv if Prof ile-S NETWORK 1920x1080 / 25, 30f ps Interf ace 1 Gigabit Ethernet (10/100/1000Mbps) HD-SDI/EX-SDI...
  • Page 103 16 CHANNEL FULL CASE RAID DVR VIDEO INPUT NETWORK HD-SDI (SMPTE 292M), EX-SDI Interf ace 1 Gigabit Ethernet (10/100/1000Mbps) Video input Format AHD 2.0, Analog 960H/SD Ty pe Static IP, Dy namic IP, xDSL 1920x1080 / 25, 30f ps DDNS WNS, Dy nDNS, NoIP, WRS HD-SDI / EX-SDI 1280x720 / 25, 30, 50, 60f ps...

  • Page 104: Product Dimension

    Product Dimension 16 CHANNEL FULL CASE POC DVR...
  • Page 105 8 CHANNEL MIDDLE CASE POC DVR...
  • Page 106 4 CHANNEL SMALL CASE POC DVR...
  • Page 107 16 CHANNEL FULL CASE DVR / 16 CHANNEL FULL CASE RAID DVR...
  • Page 108 16 CHANNEL MIDDLE CASE DVR...
  • Page 109 8 CHANNEL MIDDLE CASE DVR...
  • Page 110 4 CHANNEL SMALL CASE DVR...
  • Page 111 7. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or Open Source License Report on the Product otherwise) that contradict the conditions of this License, they do not excuse you from the conditions of this License.
  • Page 112 A “covered work” means either the unmodified Program or a work based on the Program. be in a format that is publicly documented (and with an implementation available to the public in source To “propagate” a work means to do anything with it that, without permission, would make you directly or code form), and must require no special password or key for unpacking, reading or copying.
  • Page 113 THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT any medium, provided that you conspicuously and appropriately publish on each copy an appropriate WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE copyright notice and disclaimer of warranty;...
  • Page 114 explicit geographical distribution limitation excluding those countries, so that distribution is permitted only origin of the Work and reproducing the content of the NOTICE file. in or among countries not thus excluded. In such case, this License incorporates the limitation as if written 7.
  • Page 115 Permission to use, copy, modify, and distribute this software and its documentation for any purpose and The implementation was written so as to conform with Netscapes SSL. without fee is hereby granted, provided that the above copyright notice appear in all copies and that both This library is free for commercial and non-commercial use as long as the following conditions are that copyright notice and this permission notice appear in supporting documentation, and that the name aheared to.
  • Page 116 Manufacturer might service at user’s cost for following request made by customer. Customer notice.  Please make regular schedule to check unit status (Daily check is recommended).  Manufacturer will not take any responsibility on the physical/human damage caused by robbery, natural disaster.
  • Page 117 For requesting service? Please inform details of malfunctions correctly. Free or non free repair will be decided based on details of warranty card. WebGate, Daemyung Corporation Co., Ltd. 6F Hanlim Venture Town B/D 284 Gongdanro Gunpo Gyeonggido, 435-862 Korea Main...
  • Page 118 The W HDcctv Alliance Premium to your HD-CCTV W E B G A T E WEBGATE Daemyung Corporation Co., Ltd. 6F,Hanlim Venture Town B/D, 284, Gongdan-ro, Gunpo-si, Gyeonggi-do, Korea(15809) Tel +82. 31. 428. 9383 Fax +82. 31. 455. 3955 sales@webgateinc.com...
