Remark
Please follow the user manual for correct installation and testing, if
there is any doubt please call our tech-supporting
and customer
center.
Our company applies ourselves to reformation and innovation of our
products. No extra informing for any change. The illustration shown
here only used for reference, if there is any difference please take the
actual product as standard product.
Commercial in Confidence
WWW.ACTIVEONLINE.COM.AU
+61 (0)7 5551 0306

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D-A1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Active Online D-A1

  • Page 1 Remark Please follow the user manual for correct installation and testing, if there is any doubt please call our tech-supporting and customer center. Our company applies ourselves to reformation and innovation of our products. No extra informing for any change. The illustration shown here only used for reference, if there is any difference please take the actual product as standard product.

  • Page 2: Table Of Contents

    CATALOG Pictures..............1 Basic Function ............3 Technology Parameters ..........3 Basic Settings ............3 Web Settings ............12 Basic Operation ............18 System Configuration ..........19 System Diagram ............20 Installation ..............21 Notes................23 Commercial in Confidence WWW.ACTIVEONLINE.COM.AU +61 (0)7 5551 0306...

  • Page 3: Pictures

    Pictures Model: D-A1 WWW.ACTIVEONLINE.COM.AU +61 (0)7 5551 0306 Camera Infrared LEDs Display screen Microphone Swiping card area Digital keyboard Speaker Model: D-A3 Speaker Infrared LEDs Camera Display screen Digital keyboard Microphone Swiping card area...
  • Page 4 Model: D-X1 (with touch screen) Camera Infrared light Speaker Display(3.5"LCD) Digital keyboard Microphone Card reader area Model: D-X5 (with keyboard) Speaker Camera Infrared LEDs Display screen Digital keyboard Swiping card area Microphone WWW.ACTIVEONLINE.COM.AU +61 (0)7 5551 0306...

  • Page 5: Basic Function

    Basic Function 1. Intercom with indoor monitor and management center. 2. Support IC/ID card. 3. Register IC/ ID card and backup the card information, store ten thousand IC/ID cards at most. 4. Unlock by password, exit button, with door magnetic inspection. 5.
  • Page 6 Press “2” button to page up, press “8” button to page down; press “#” button to confirm; press “*” button to go back. Input 6 digits password (the default password is 123456) to enter the following outdoor panel settings: 1. Application #OK *Cancel 2Up 8Down Main interface includes the following contents: Application——...
  • Page 7 1.1 Reg. card Select this item, then press “#” button to enter into the following interface: Register card Room No.-[ *Cancel Press room No. firstly, then get the access card closed to swiping card area, the system will display “ Success”, now this card registration is successful. 1.2 Unlock Select this item, then press “#”...
  • Page 8 1.4 Password Select this item, then press “#” button to enter into the following interface: New Password *Cancel Input the password you want to change, the password has 6 digits at most. Press “#” button to confirm after setting, the system will display “ Success”, now the setting is successful.
  • Page 9 Press any digit from 1～4, different digit refers to different ring tone. Press “#” button to confirm after setting, the system will display “ Success”, now the setting is successful. 1.7 Language Select this item, press “#” button to enter into the following interface: Language Value-[ 1: CN...

  • Page 10: System Setup

    1.9 Panel Mode Select this item, then press “#” button to enter into the following interface: Panel Mode Value-[ Unit-[ 0 ] Wall-[ 1 ] *Cancel This device is used as the outdoor panel and wall station. The panel mode can be set through this item.
  • Page 11 Address No. Address No. Unit: [ Unit: [ Build: [ *Cancel *Cancel The address No. is the device address. when the device is used as outdoor panel, input unit and building No.; when the device is used as wall station, the item will be invalid. Press “#”...
  • Page 12 2.5 Gateway Select this item, then press “#” button to enter into the following interface: Gateway [ 192.168.68.1 ] *Cancel The gateway is refer to the address of the network segment that device IP exits. The default is 192.168.68.1. Input gateway, then press “#” button to confirm after setting, the system will display “...

  • Page 13: System Information

    2.8 Reboot Select this item, then press “#” button to enter into the following interface: Reboot Value- [ 1-OK 0-Cancel *Cancel *Cancel Press “1” to indicate that system restart, input “0" to indicate that give up the system restart. Then press “#” button to confirm. 3.

  • Page 14: Web Settings

    WWW.ACTIVEONLINE.COM.AU +61 (0)7 5551 0306 Web Settings Connect the outdoor panel with the computer through the switch, then change computer IP , the outdoor panel IP and computer IP should be in the same network segment, input IP address in the web browser of the computer after that, then input the user name and password(the default name is admin, the password is 123456) to enter into the following interface: 1.
  • Page 15 should be made in the same LAN usually; if they are not in the same LAN, the call will be made on the internet, now SIP server should be set. Click“Submit” after setting, it will come into effect. 2. Device setting: Click “Device”...
  • Page 16 The range of unlock timeout is 1~9 seconds. Unlock delay is used for controlling the unlocking time, the range is 0~9 seconds. Unlock password is used for unlocking the door, the default is 0000. Elev refer is used for setting the floor that the outdoor panel exits, the parameter is 01~99.
  • Page 17 Room No. can be bounded with phone No., the specific operating steps is as follows: 1. Input room No., then input the Account No. you want to bound; 2. If want to delete the Account No., check “Remove” in the frame; 3.
  • Page 18 4. DTMF of FXO port in voice gateway is set as RFC2833, i.e. set as “#” button on the phone to unlock. 5. Click “Submit” after setting, it will come into effect. 7. Advanced Setting (only for outdoor panel) Advanced setting is invalid. 7.
  • Page 19 8. User Logout: Click “Logout” icon on the interface to enter into the following interface: Click “Submit” to logout the system. WWW.ACTIVEONLINE.COM.AU +61 (0)7 5551 0306 -17-...

  • Page 20: Basic Operation

    Basic Operation 1. Unit outdoor panel/ Wall station calls management center Press “0000” or button to call management center directly. Calling ------------Call User------------- *Cancel 2. Calling indoor monitor (the digit of indoor monitor is 1~4) 2.1 Unit outdoor panel Press the floor and room No. of indoor monitor (the digit is 3 at least). For example: if the floor and room No.

  • Page 21: System Configuration

    System Configuration Flat Camera Adapter Next Network Switch Smart home control module (optional) CAT 5e CAT 5e Alarms(optional) Adapter Siren(optional) Network CAT 5e CAT 5e Switch Adapter Indoor monitor Indoor monitor Adapter CAT5e Indoor monitor CAT 5e CAT 5e Network Switch CAT 5e Adapter...

  • Page 22: System Diagram

    System Diagram Exit button Door contact Lock Network interface RS485 interface (optional) WWW.ACTIVEONLINE.COM.AU +61 (0)7 5551 0306 -20-...

  • Page 23: Installation

    Installation Model:A1 Wall mounted type Built-in size: 118*285*50 (mm) Outdoor panel Dig a hole wall Break through the Screws cord hole on the bottom of the build-in box firstly for water draining. Built-in box Please don’t cover the drain hold with the glass cement.
  • Page 24 WWW.ACTIVEONLINE.COM.AU +61 (0)7 5551 0306 Model:D-X1 Wall mounted type Built-in size: 350*139*52 (mm) holes Break through the cord hole on the bottom of the build-in box firstly for water draining. Please don’t cover the drain hold with the glass cement. Model: X5 Wall mounted type Built-in size: 192*320*55 (mm)

  • Page 25: Notes

    Notes Maintenance of devices 1. Keep the clearance of the surface and use soft dry cloth to clean the dust of the product. 2. Please turn off the power of indoor unit when clean the indoor device. 3. If there is hard dirty which cannot be cleaned with dry cloth, please use the soft towel dipped in the neutral diluted detergent to clean the machine and then clear it with dry cloth.
