UNPACKING, ASSEMBLY, HANDLING AND POSITIONING
1. Where applicable remove the packing taking great care in not damage the appliance.
2. Use protective gear (gloves) for the positioning and assembly.
a. Fix the handle (No.2) on the fan by tighten screw (No.1)
b. Fix the foot (No.4) on the fan by tighten screw (No.3).
c. Fix the wheel (No.6) on the fan by tighten screw (No.7) and nut (No.5).
1 - Screw
2 - Handle
3 - Screw
4 - Foot
5 - Screw
6 - Wheel
7- Screw
surface.
3 SPEED OSCILLATING WALL FAN
MODEL: TANK-3076
SPECIFICATION
Watts (W)
Volts
Low
Medium
110V / 50Hz
191
217
230V / 50Hz
174
196
READ AND SAVE THESE INSTRUCTIONS
Amps (A)
High
High
Low
Medium
276
1.83
2.24
241
0.82
0.93
3.46
1.35
