Summary of Contents for Digga Torque Logic
- Page 1 MORE THAN JUST TORQUE INSTALLATION MANUAL PM-000121 Digga Torque Logic Installation Manual PM-000121...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Tools Required for Installation.…………………………………………………..…...3 Personal Protective Equipment………………...…………………………………..3 Digga Torque Logic Installation Kit Contents…..…………………………………...3 Installation Directions…………………………………...…………………………..4 Removing OEM pin Remove Knuckle/Wishbone Inserting the Digga Torque Logic Leveling Marking Placement Stopper…….………………………………..…………………………………………..5 Replacing Knuckle/Wishbone Using The Pull Rod…..…………………………………….………………………..6 Pull Rod... -
Page 3: Tools Required For Installation
THE DIGGA TORQUE LOGIC HAS A COMPUTER PROCESSOR BOARD INSERTED IN THE END OF THE PIN THESE ACTIONS WILL VOID THE WARRANTY! • HITTING THE DIGGA TORQUE LOGO WITH A HAMMER OR ANY OTHER OBJECT. • GROUNDING TO THE DIGGA TORQUE LOGO WHILE WELDING. -
Page 4: Installation Directions
Fasten the drive in a sturdy position and remove the OEM pin out from the top of the drive. Once the OEM Pin is removed from the drive, remove the Knuckle/Wishbone. Insert the Digga Torque Logic into the holes of the bails/ears to align pin placement. - Page 5 Bolt or weld a stopper into place. WARNING Do not ground to the Digga Torque Logic. Tack the sides of the stopper, then remove the Digga Torque Logic before solidly welding the stopper in place. Too much heat may affect the “CPU” board.
-
Page 6: Replacing Knuckle/Wishbone Using The Pull Rod
Assemble rod as shown. Position the 2 end nuts on the rod and adjust according to the amount of rod you will require to effectively pull the Digga Torque Logic through the bails. Using 2 wrench’s tighten the end nuts against one another. -
Page 7: End Cap
END CAP SOCKET HEAD CAP SCREW To apply the end cap to the Digga Torque HIGH COLLAR LOCK WASHER Logic, insert the provided dowel into the unthreaded hole in the end of the End Cap. Line up the dowel hole and the... -
Page 8: Cabling
CABLING A Jib cable is recommended between the Digga Torque Logic and the disconnect of your drive. Using a jib cable in this area will prevent damage to the main cable and is easier to replace in the event it does get damaged. -
Page 9: Attaching The Pran Harness
Never disconnect the power by pulling the plug from the power source. This can result in corruption of data stored in your Display. Do not tap on the screen of the Digga Torque Logic Display with any object other than your finger. Hard or pointed objects may damage the screen. -
Page 10: General Safety Precautions
OEM. • Turn off the power supply and apply the parking brake. • Use your knees, not your back when picking up and placing heavy Digga Torque Logic • Wear approved welding shield when welding stopper into place. -
Page 11: Spare Parts
SPARE PARTS For further information on spare parts please contact your nearest Digga Dealer AUSTRALIA Head Office - Brisbane 4 Octal St, Yatala QLD 4207 info@digga.com Phone: (07) 3807 3330 Fax: (07) 3807 1499 NORTH AMERICA DIGGA NORTH AMERICA 2325 Industrial Parkway SW... - Page 12 DYERSVILLE, IA 52040 YATALA QLD 4207 AUSTRALIA PH: +1 563 875 7915 PH: +61 (0) 7 3807 3330 CELL: +1 563 845 9177 MOBILE: +61 (0) 418 343 241 EMAIL: INFO@DIGGAUSA.COM EMAIL: INFO@DIGGA.COM WWW.DIGGAUSA.COM WWW.DIGGA.COM PM-000121 PM-000121 Digga Torque Logic Installation Manual...
