IMPORTANT

Read this entire installation manual

to ensure proper installation, then

file these instructions with the

owner or maintenance department.

Flush all the water supply lines

before making connections.

Wall anchors used must have a

minimum pull-out rating of 1,000

lbs.

Product warranties may be found

under "Product Information" on our

web site at www.bradleycorp.com.

215-1469 Rev. B; EN 08-805

Page 1 of 17

4/24/08

Installation

Instructions

OBSOLETE

SS-3/BIR/WH97TAS

Express® Lavatory

System SS-Series

Express® Lavatory Systems

are ADA compliant.

Pre-Installation Information . . . . . . . . . . . . . . . .2

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Installation Instructions . . . . . . . . . . . . . . . . 4-11

Cleaning and Maintenance Instructions . . . . . .12

Soap Dispenser Maintenance . . . . . . . . . . .13-14

Check Valve Troubleshooting . . . . . . . . . . . . . .14

Assembly of Components . . . . . . . . . . . . . .15-16

Vernatherm™ Thermostatic Mixing Valve . . . .17

P.O. Box 309, Menomonee Falls, WI 53052-0309

TEL. 1-800-BRADLEY

http://www.bradleycorp.com

FAX 262-251-5817

Need help?

Do you have a question about the Obsolete Express SS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Bradley Obsolete Express SS Series

Page 1: Table Of Contents
Product warranties may be found under "Product Information" on our web site at www.bradleycorp.com. P.O. Box 309, Menomonee Falls, WI 53052-0309 215-1469 Rev. B; EN 08-805 TEL. 1-800-BRADLEY FAX 262-251-5817 © 2008 Bradley Corporation http://www.bradleycorp.com Page 1 of 17 4/24/08...
Page 2: Pre-Installation Information
• (10) 3/8" wall anchors, bolts and washers to mount frame and bowl (minimum pull-out rating of 1,000 lbs.) and bowl to wall • 1/2" NPT tempered supply piping • 1-1/2" NPT drain piping • (18) “AA” alkaline batteries 4/24/08 Bradley Corporation • 215-1469 Rev. B; EN 08-805...
Page 3: Dimensions
Express® Lavatory System SS-Series Installation - Obsolete SS-3/BIR/WH97TAS SS-3/BIR/WH97TAS Express® Lavatory System Dimensions Standard Height Mounting Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
Page 4 Express® Lavatory System SS-Series SS-3/BIR/WH97TAS Installation - Obsolete Dimensions continued . . . Juvenile Height SS-3/BIR/WH97TAS Grades Pre-K thru 5 or 6 Juvenile Height SS-3/BIR/WH97TAS Grades 6 thru 8 or 9 4/24/08 Bradley Corporation • 215-1469 Rev. B; EN 08-805...
Page 5: Installation Instructions
Figure 1a below or Figure 1b on page 6. SS-3/BIR/WH97TAS Express® Lavatory System Dimensions Juvenile Height Mounting (Grades Pre-K thru 5 or 6) Figure 1a Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
Page 6 Express® Lavatory System SS-Series SS-3/BIR/WH97TAS Installation - Obsolete SS-3/BIR/WH97TAS Express® Lavatory System Dimensions Juvenile Height Mounting (Grades 6 thru 8 or 9) Figure 1b Figure 2 4/24/08 Bradley Corporation • 215-1469 Rev. B; EN 08-805...
Page 7 3/8" bolts and washers to mount the frame to the wall (see Figure 4). FRAME (9) TORX-HEAD SCREW (bit size T25) PANEL Figure 3 BOWL AND SPRAYHEAD SHOWN FOR REFERENCE ONLY Figure 4 Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
Page 8 3. Attach the front of the bowl assembly to the frame using the four 1/4"-20 pan-head screws and washers provided. Do not tighten screws at this time. BACK VIEW Figure 5 4/24/08 Bradley Corporation • 215-1469 Rev. B; EN 08-805...
Page 9 9. Tighten the screws installed to secure the bowl assembly to the frame. Do not overtighten. COVER SCREWS (4) FLEX HOSE WASHER Figure 6a FILTER Figure 6b Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
Page 10 Figure 7a 1/2" CROSS VERNATHERM™ THERMOSTATIC MIXING VALVE FLEXIBLE SUPPLY HOSE STOP/CHECK FIBER WASHER CONNECT TO CONNECT TO 1/2" NPT COLD 1/2" NPT HOT WATER SUPPLY WATER SUPPLY Figure 8 Figure 7b 4/24/08 Bradley Corporation • 215-1469 Rev. B; EN 08-805...
Page 11 4. After testing is complete, reinstall panel to frame. Fasten panel with seven Torx-head screws provided (see Figure 3 on page 7). NOTE: For Express® units with optional soap dispensers, see pages 13 and 14 for soap dispenser maintenance instructions. Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
Page 12: Cleaning And Maintenance Instructions
Brite pad or with an abrasive cleaner. • Repair kit: In the unlikely event your Terreon® surface becomes damaged, it can easily and inexpensively be repaired. Contact your Bradley representative to order a repair kit and be sure to specify color when ordering.
Page 13: Soap Dispenser Maintenance
4. After each soap tank is filled, position the soap tanks in the sprayhead openings and push into place. Figure 9a (3) ACTIVATION LABEL 204-476 (one above each activation zone) FILLER HOLE SOAP TANK 133-107 (GRAY) 133-131 (PUTTY) 133-131A (COAL) SOAP DISPENSER VALVE S09-007 (qty. 2) Figure 9b Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
Page 14: Check Valve Troubleshooting
3. Remove the flexible hoses from the stop/check valves and clean the strainers, if necessary. 4. Inspect mixing valve for proper installation (see Vernatherm valve on page 17). • A red marking indicates the hot inlet. 4/24/08 Bradley Corporation • 215-1469 Rev. B; EN 08-805...
Page 15: Assembly Of Components
Vernatherm™ Thermostatic Mixing Valve Assembly S67-571 VERNATHERM VALVE (S01-116B) Optional Stop/Strainer/Check Valve 90° ELBOW FLEX HOSE WITH 169-639 SWIVEL END FILTER 269-653 WASHER 269-1188 STOP/CHECK VALVE BRASS PIPE S27-102 NIPPLE STOP/STRAINER/CHECK VALVE 113-006DH S60-003 Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
Page 16 SINGLE OPERATION DRAIN ASSEMBLY CONTROL BOX S67-219 SENSOR ASSY. SCREW COMPONENTS 160-120 110-115 1/4" ELBOW 145-090 AERATOR HOUSING INFRARED 115-133 WINDOW 269-1241 O-RING 125-001CK DIFFUSER 269-508 STREAMFORMER SCREW 115-125 160-289 4/24/08 Bradley Corporation • 215-1469 Rev. B; EN 08-805...
Page 17 No Water Cold Valve shuts off or drips Correct Correct Cold Cold Cold Reversed Cold Cold/below 107° Hot/above 107° Reversed No Water Reversed No Water Cold Cold Reversed Reversed Cold Cold Cold Bradley Corporation • 215-1469 Rev. B; EN 08-805 4/24/08...
